用温度修正的<em>k-ε</em>模型研究排气系统红外辐射特性

李喜喜; 额日其太; 朱希娟; 吴盟

用温度修正的k-ε模型研究排气系统红外辐射特性

1.
北京航空航天大学能源与动力工程学院, 北京100191
2.
中国航天科工集团公司第二研究院光学辐射重点实验室, 北京100854
3.
中国航空工业集团公司成都发动机(集团)有限公司, 成都610503

计量
- 文章访问数: 1560
- HTML浏览量: 3
- PDF量: 1038
- 被引次数: 0
出版历程
- 收稿日期: 2012-08-07
- 刊出日期: 2013-09-28

Infrared radiation characteristics of exhaust system using temperature corrected k-ε model

1.
School of Energy and Power Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China
2.
The Second Academy of China Aerospace Science and Industry Corporation, Science and Technology on Optical Radiation Laboratory, Beijing 100854, China
3.
Chengdu Engine(Group)Company Limited, Aviation Industry Corporation of China, Chengdu 610503, China

摘要

摘要: 为研究温度修正的k-ε湍流模型对排气系统红外辐射特性计算精度的改善程度,计算了某轴对称收敛喷管在3~5μm波段的空腔-喷流组合红外辐射特性,并与试验结果对比.喷管流场及温度场采用有限体积法(FVM)求解Navier-Stokes(N-S)方程得到,湍流模型分别采用标准k-ε模型和温度修正的k-ε模型.红外辐射特性的计算采用有限体积法求解吸收-发射性介质条件下的三维辐射传输方程,并考虑大气衰减作用.计算结果表明:温度修正的k-ε模型可有效预测排气系统热喷流的核心区长度,从而获得与试验结果一致的红外辐射强度.与标准k-ε模型相比,采用温度修正的k-ε模型计算得到的红外辐射强度的最大相对误差由64%降至了4.3%,说明温度修正的k-ε模型适用于精确模拟排气系统的红外辐射特性.
- 温度修正 /
- 湍流模型 /
- 排气系统 /
- 红外辐射 /
- 有限体积法
Abstract: The infrared signal in 3~5μm band of an axisymmetric nozzle was calculated to investigate the improvement of the temperature corrected k-ε turbulence model in the infrared radiation(IR) of exhaust system,and compared with the experimental results.The flow fields and temperature fields of nozzle were simulated numerically by using finite volume method(FVM) and solving Navier-Stokes(N-S) equations,and coupled with the standard k-ε model and the temperature corrected k-ε model respectively.The IR signal was calculated by FVM in non-gray absorbing-emitting media to slove the 3-D radiative transfer equation,and the atmosphere attenuation effect on IR was considered.The results show that the temperature corrected k-ε model can predict the potential core length of hot jet,and consequently the IR intensity agrees with the experiment data.The maximum value of relative error for IR intensity obtained using the temperature corrected k-ε model is 4.3%,while that obtained using the standard k-ε model is up to 64%.This shows that the temperature corrected k-ε model is appropriate for accurate simulation of IR characteristics of exhaust system.
- temperature corrected /
- turbulence model /
- exhaust system /
- infrared radiation /
- finite volume method

HTML

参考文献(22)

[1]	Segalmun I,Semerjian H.Turbine engine infrared signature program[R].AD-A028659,1976.
[2]	额日其太,王强,陈渭鹏.两种涡扇发动机排气系统红外辐射特性的比较[J].推进技术,2003,24(4):334-336. Eriqitai,WANG Qiang,CHEN Weipeng.Comparative investigation of the infrared characteristics for two exhaust systems of a turbofan engine[J].Journal of Propulsion Technology,2003,24(4):334-336.(in Chinese)
[3]	刘友宏,邵万仁,张锦绣.发动机排气系统及尾喷流的流场和红外特征数值模拟[J].航空动力学报,2008,23(4):591-597. LIU Youhong,SHAO Wanren,ZHANG Jinxiu.Numerical simulation of flowfield and infrared characteristics of an aeroengine exhaust system and its plume[J].Journal of Aerospace Power,2008,23(4):591-597.(in Chinese)
[4]	HU Haiyang,WANG Qiang.A numerical simulation on the infrared radiation of hot exhausting nozzles with a coupled flow and heat transfer mode[J].Science China:Technological Sciences,2010,53(10):2699-2707.
[5]	黄伟,吉洪湖,斯仁,等.涡扇发动机排气系统红外特征[J].推进技术,2010,31(6):745-772. HUANG Wei,JI Honghu,SI Ren,et al.Infrared characteristics calculating of turbofan engine exhaust system[J].Journal of Propulsion Technology,2010,31(6):745-772.(in Chinese)
[6]	Nicholas J G,Dennis A Y,William A E.Evaluation of modified two-equation turbulence models for jet flow predictions[R].AIAA-2006-490,2006.
[7]	Nicholas J G,James R D.Navier-Stokes analysis methods for turbulent jet flows with application to aircraft exhaust nozzles[J].Progess in Aerospace Sciences,2006,42(5/6):377-418.
[8]	Dembowski M A,Georgiadis N J.An evaluation of parameters influencing jet mixing using the WIND Navier-Stokes code[R].NASA Paper TM-2002-211727,2002.
[9]	Sarkar S,Erlebacher G,Hussaini M Y,et al.The analysis of and modeling of dilatational terms in compressible turbulence[J].Journal of Fluid Mechanics,1991,227:473-495.
[10]	Sarkar S,Lakshmanan B.Application of a Reynolds stress turbulence model to the compressible shear layer[J].AIAA Journal,1991,29(5):743-749.
[11]	Tam C K W,Ganesan A.Modified k-ε turbulence model for calculating hot jet mean flow and noise[J].AIAA Journal,2004,42(1):26-34.
[12]	Seiner J M,Ponton M K,Jansen B J,et al.The effects of temperature on supersonic jet noise emission[C]//14th AIAA Aeroacous tics Conference.Aachen,Germany:AIAA, 1992:295-307.
[13]	Thomas R H,Kinzie K W,Pao S P.Computational analysis of a pylon-chevron core nozzle interaction[R].AIAA-2001-2185,2001.
[14]	Steven J M,Ressell H T,Khaled S A,et al.Computational and experimental flow field analysis of separate flow chevron nozzles and pylon interaction[R].AIAA-2003-3212,2003.
[15]	Abdol-Hamid K S,Pao S P,Massey S J,et al.Temperature corrected turbulence model for high temperature jet flow[J].Journal of Fluids Engineering,2004,126(5):844-850.
[16]	Jones W P,Launder B E.The prediction of laminarization with a two-equation model of turbulence[J].International Journal of Heat and Mass Transfer,1972,15(2):301-314.
[17]	胡海洋,王强.跨声速条件下轴对称收扩喷管内外流场的数值研究[J].航空动力学报,2008,23(6):1041-1046. HU Haiyang,WANG Qiang.Numerical study on combination flow field of axisymmetric convergent-divergent nozzle under transonic and supersonic conditions[J].Journal of Aerospace Power,2008,23(6):1041-1046.(in Chinese)
[18]	ZHU Xijuan,Eriqitai,LI Xixi,et al.Infrared radiation simulation of exhaust system by coupling FVM with narrow band k-distribution[J].Journal of Aerospace Power,2012,27(1):25-32.
[19]	朱希娟.基于高精度气体模型的飞行器排气系统红外辐射特性研究[D].北京:北京航空航天大学,2011. ZHU Xijuan.Study on infrared radiation of aircraft exhaust system based on high-resolution gas model[D].Beijing:Beijing University of Aeronautics and Astronautics,2011.(in Chinese)
[20]	Back L H,Massier P F,Gier H L.Convective heat transfer in a converging-diverging nozzle[J].International Journal of Heat and Mass Transfer,1964,7(11):549-568.
[21]	黄宏艳,王强.轴对称喷管内外流场与结构温度场耦合计算[J].推进技术,2008,29(2):194-198. HUANG Hongyan,WANG Qiang.Coupled numerical study of flow field and heated structure for axisymmetric nozzles[J].Journal of Propulsion Technology,2008,29(2):194-198.(in Chinese)
[22]	Bridges J E,Wernet M P.Measurements of the aeroacoustic sound in hot jets[R].AIAA-2003-3130,2003.
