单相液体发汗冷却规律实验
Experiment of transpiration cooling rules of single phase liquid
-
摘要: 以超燃冲压发动机内支板结构的热防护问题为背景,制备了全烧结金属多孔介质支板结构,并对以液态水为冷却工质的发汗冷却特性进行了实验研究.实验结果表明:液态水发汗冷却能有效地减少支板壁面和高温流体之间的换热,当注入率为2%时,冷却效率可以高达93%;随注入率增大,发汗冷却的冷却效率趋近于100%,增幅逐渐减小;在该实验所采用的两种不同主流温度条件下,相同注入率、相同位置的冷却效率近似相等.对发汗冷却的冷却剂停止供应后的支板表面温度热响应特性进行了初步研究,根据支板内液态水蒸发的过程分3个阶段进行了分析.Abstract: Sintered metal porous media strut of the scramjet combustion chamber was manufactured to provide thermal protection for the scramjet.Transpiration cooling using water as coolant was studied experimentally.The experimental results show that the heat transfer between the mainstream and the strut wall can be effectually reduced.The cooling efficiency reaches 93% when blowing ratio of 2%.Cooling efficiency increases with the rising coolant blowing ratio,and tends to be 100%.Under two mainstream temperatures,the cooling efficiency at the same measuring points and blowing ratios varies little.Thermal response of the surface temperature of strut after stopping coolant supply was also studied.Water evaporation process was analyzed in three stages.
-
[1] Tani K,Kanda T,Kudou K.Aerodynamic performance of scramjet inlet models with a single strut[J].Journal of Propulsion and Power,2006,22(4):905-912. [2] Tetlow M R,Doolan C J.Comparison of hydrogen and hydrocarbon-fueled scramjet engines for orbital insertion[J].Journal of Spacecraft and Rockets,2007,44(2):365-373. [3] Masuya G,Komuro T,Murakami A,et al.Ignition and combustion performance of scramjet combustors with fuel injection struts[J].Journal of Propulsion and Power,1995,11(2):301-307. [4] Sullins G,Anderson J,Drummond J.Numerical investigation of supersonic base flow with parallel injection[R].AIAA 82-1001,1982. [5] Pandey K M,Sivasakthivel T.CFD analysis of mixing and combustion of a scramjet combustor with a planer strut injector[J].International Journal of Environmental Science and Development,2011,2(2):102-108. [6] Bayley D,Hartfield R.Experimental investigation of angled injection in a compressible flow[R].AIAA 95-2414,1995. [7] Motoyama N.Mihara K,Miyajima R,et al.Thermal protection and drag reduction with use of spike in hypersonic flow[R].AIAA-2001-1828,2001. [8] Bouchez M,Cahuzac G,Beyer S.PTAH-SOCAR fuel-cooled composite materials structure in 2003[R].AIAA-2003-6919,2003. [9] 孙冰,郑力铭.超燃冲压发动机支板热环境及热防护方案[J].航空动力学报,2006(2):336-341. [KG3]SUN Bing,ZHENG Liming.Research of scramjet strut thermal environment and thermal protection scheme[J].Journal of Aerospace Power,2006(2):336-341.(in Chinese) [10] Kulkarni P S,Ravi B R,Reddy K.Two dimensional Navier-Stokes solutions for transpiration cooling at hypersonic Mach numbers[J].Shock Waves,2004,13(6):497-500. [11] Reddy N M.Numerical simulation of transpiration cooling over blunt bodies at hypersonic Mach numbers[R].AIAA 95-2082,1995. [12] Foreest A V,Sippel M,Klevanski J,et al.Transpiration cooling to handle the aerothermodynamic challenges of the spaceliner concept[R].Brussels,Belgium:The 2nd European Conference For Aerospace Sciences (Eucass),2007. [13] Bellettre J,Bataille F,Lallemand A,et al.Studies of the transpiration cooling through a sintered stainless steel Plate[J].Experimental Heat Transfer,2005,18(1):33-44. [14] Wang J H,Messner J,Stetter H.An experimental investigation on transpiration cooling:Part Ⅱ comparison of cooling methods and media[J].International Journal of Rotating Machinery,2004,9(10):355-363. [15] Schindel L,Driftmyer R.Surface cooling by transpiration of a freezing liquid[J].Journal of Thermophysics and Heat Transfer,1992,6(1):158-160. [16] Van Foreest A,Sippel M,Güelhan A,et al.Transpiration cooling using liquid water[J].Journal of Thermophysics and Heat Transfer,2009,23(4):693-702. [17] Van Foreest A,Sippel M,Gülhan A,et al.Transpiration cooling methods for the spaceLiner[J].Notes on Numerical Fluid Mechanics and Multidisciplinary Design,2008,98(1):170-185. [18] Henry C L,Delametter J E.Scramjet fuel injection system having independent fuel supplies for supersonic and hypersonic operation:United States,5660040[P].1997-08-26. [19] Bulman M J.Transpiration cooling for a vehicle with low radius leading edge:United States,5452866[P].1995-09-26. [20] Chevalier A,Bouchez M.Fuel-injecting apparatus for ramjet engine cooled by transpiration:United States,6164061[P].2000-12-26. [21] Bouchez M,Chevalier A.Transpiration cooled fuel injector bar for a ramjet engine:Europe,EP0846920 B1[P].2003-06-11. [22] Bulman M J,Transpiration cooling for a vehicle with low radius leading edges:United States,5351917[P].1994-10-04.
