基于动态吸振器的高超声速复合材料壁板颤振抑制及其优化设计

赵海; 曹登庆; 龙钢

基于动态吸振器的高超声速复合材料壁板颤振抑制及其优化设计

1.
哈尔滨工业大学航天学院, 哈尔滨 150001
2.
西安现代控制技术研究所陆航装备发展处, 西安 710065

基金项目: 国家自然科学基金(91216106);国家基础研究(2011CB711102)

计量
- 文章访问数: 1288
- HTML浏览量: 3
- PDF量: 1089
- 被引次数: 0
出版历程
- 收稿日期: 2012-10-22
- 刊出日期: 2013-10-28

Suppression of supersonic flutter of laminated composite panel using dynamic absorber device and its optimal design

1.
School of Astronautics, Harbin Institute of Technology, Harbin 150001, China
2.
Development Office for Army Aviation's Armament, Xi'an Modern Control Technology Research Institute, Xi'an 710065, China

摘要

摘要: 研究了动态吸振器对高超声速流中复合材料壁板颤振的抑制作用.将壁板和动态吸振器的相互作用力描述为两者相对位移和相对速度的函数,利用von-Karman非线性应变-位移关系和3阶非线性活塞理论,根据哈密顿原理和牛顿第二定律分别建立了壁板和动态吸振器的运动微分方程.采用模态假设法对系统进行离散并进行数值模拟,对动态吸振器的安装位置进行了优化设计.数值计算结果表明:合理选择动态吸振器参数可使壁板临界颤振动压提高51.7%,同时可降低颤振后极限环振动的幅值.
- 颤振抑制 /
- 动态吸振器 /
- 优化设计 /
- 活塞理论 /
- 气动弹性
Abstract: The problem of suppression of supersonic flutter of laminated composite panel using dynamic absorber device was investigated.The interaction forces between the panel and the dynamic absorber device were expressed as the functions of relative displacement and velocity of the panel and the absorber.Based on the von-Karman nonlinear deflection panel theory and the 3rd-order nonlinear piston theory,the equations of motion of the panel and the absorber were established according to the Hamilton principle and the Newton second law of motion.Then the assumed modal method was adopted in the discrete procedure,and the numerical simulation was conducted.The coordinate of the absorber was optimized.The simulation results indicate that the critical flutter dynamic pressure can be enhanced by 51.7% under certain parameters of the absorber,and the amplitude of the limit cycle oscillation can also be suppressed.
- flutter suppression /
- dynamic absorber device /
- optimal design /
- piston theory /
- aeroelastic

HTML

参考文献(17)

[1]	Park J S,Kim J H,Moon S H.Thermal post-buckling and flutter characteristics of composite plates embebded with shape memory alloy fibers[J].Composite Part B:Engineering,2005,36(8):627-636.
[2]	Cao D Q,Zhao N.Active control of supersonic/hypersonic aeroelastic flutter for a two-dimensional airfoil with flap[J].Science China:Technological Sciences,2011,54(8):1943-1953.
[3]	Dowell E H.Nonlinear oscillations of a fluttering plate[J].AIAA Journal,1966,4(7):1267-1275.
[4]	Dowell E H.Panel flutter:a review of the aeroelastic stability of plates and shells[J].AIAA Journal,1970,8(3):385-399.
[5]	Ibrahim H H,Yoo H H,Lee K S.Supersonic flutter of functionally graded panels subject to acoustic and thermal loads[J].Journal of Aircraft,2009,46(2):593-600.
[6]	Lee J J,Choi S.Thermal buckling and postbuckling analysis of a laminated composite beam with embedded SMA actuators[J].Composite Structures,1999,47(1/2/3/4):695-703.
[7]	张晓梅,任勇生,李磊.埋入SMA纤维的复合材料壁板的气动稳定性研究[J].太原科技大学学报,2012,13(6):497-501. ZHANG Xiaomei,REN Yongsheng,LI Lei.Aeroelastic stability of shape memory alloy hybrid composite panels[J].Journal of Taiyuan University of Science and Technology,2012,13(6):497-501.(in Chinese)
[8]	孙伟,胡海岩.基于多级磁流度阻尼器的操纵面振动半主动抑制-阻尼设计与实验建模 [J].振动工程学报,2005,18(1):13-18. SUN Wei,HU Haiyan.Semi-active flutter suppression for wing aileron system using stepped MR damper-numeric simulation and tunnel experiments[J].Journal of Vibration Engineering,2005,18(1):13-18.(in Chinese)
[9]	Li F M.Active aeroelastic flutter suppression of a supersonic plate with piezoelectric material[J].International Journal of Engineering Science,2012,51:190-203.
[10]	李凤明,陈照波,崔玉波.采用压电材料提高超声速飞行器壁板结构的颤振特性[J].固体力学学报,2011,32(suppl.):214-218. LI Fengming,CHEN Zhaobo,CUI Yubo.Improving the aeroelastic flutter properties of supersonic flat panel using piezoelectric material[J].Chinese Journal of Solid Mechanics,2011,32(suppl.):214-218.(in Chinese)
[11]	李道春,向锦武.间隙非线性气动弹性颤振控制[J].北京航空航天大学学报,2007,33(6):640-643. LI Daochun,XIANG Jinwu.Flutter control of aeroe lasticity with freep lay nonlinearity[J].Journal of Beijing University of Aeronautics and Astronautics,2007,33(6):640-643.(in Chinese)
[12]	于明礼,胡海岩.基于超声电机作动器的翼段颤振主动控制[J].振动工程学报,2005,18(4):419-425. YU Mingli,HU Haiyan.Active flutter suppression of an airfoil model using ultrasonic motor[J].Journal of Vibration Engineering,2005,18(4):419-425.(in Chinese)
[13]	张子健,徐敏,陈士橹.机翼颤振的混合灵敏度 H_∞鲁棒控制器设计[J].计算力学学报,2010,27(4):661-666. ZHANG Zijian,XU Min,CHEN Shilu.Mixed sensitivity H_∞ controller designing for active flutter suppression[J].Chinese Journal of Computational Mechanics,2010,27(4):661-666.(in Chinese)
[14]	Lee Y S,Vakakis A F,Bergman L A,et al.Suppressing aeroelastic instability using broadband passive targeted energy transfers:Part Ⅰ theory[J].AIAA Journal,2007,45(3):693-711.
[15]	Lee Y S,Vakakis A F,Bergman L A,et al.Enhancing the robustness of aeroelastic instability suppression using multi-degree-of-freedom nonlinear energy sinks[J].AIAA Journal,2008,46(6):1371-1394.
[16]	Dowell E H.Nonlinear oscillations of a fluttering plate[J].AIAA Journal,1966,5(10):1267-1275.
[17]	舒仲周,张继业,曹登庆.运动稳定性[M].北京:中国铁道出版社,2001.
