一种用于飞机结冰的海绵冰模型及应用
A spongy icing model for aircraft icing and application
-
摘要: 基于两相流理论,采用欧拉法对飞机结冰进行数值模拟,在空气流场速度分布的基础上,求解水滴流场,得到水滴收集率和撞击极限.结果表明:欧拉法比拉格朗日法在计算水滴收集效率和撞击极限方面有优势,尤其是在较大的水滴平均等效直径情况下.对翼型的冰形和圆柱表面的温度预测数据和实验数据进行对比,圆柱冰形厚度误差在15.0%之内,计算结果与实验结果吻合较好,同时表明结冰模型是有效可行的.Abstract: An Eulerian method to simulate aircraft icing was developed based on two-phase flow theory, and the water collection efficiency and impingement limits were solved based on the velocity distribution of air flow. Results show that Eulerian method performs better on water collection efficiency and impingement limit than Lagrangian method, especially under large median volumetric diameter conditions. The predicted ice shape and surface temperature were compared with experimental results, the thickness error of the cylinder ice shape was less than 15.0% and the computational results were in good agreement with the experiment data, showing that the icing model and two-phase flow simulation are feasible and effective.
-
[1] 裘燮纲,韩凤华.飞机防冰系统[M].北京:航空专业教材编审组,1985. [2] Bragg M B.Rime ice accretion and its effects on airfoil performance.Columbus:The Ohio State University,1981. [3] Lozowski E P,Oleskiw M M.Computer simulation of airfoil icing without runback.AIAA 81-0402,1981. [4] Shin J,Bond T.Results of an icing test on a NACA 0012 airfoil in the NASA Lewis icing research tunnel.AIAA 92-0647,1992. [5] Potapczuk M G,Al-Khalil K M,Velazquez M T.Ice accretion and performance degradation calculations with LEWICE/NS.NASA TM-105972,1993. [6] Potapczuk M G,Bidwell C S.Numerical simulation of ice growth on a MS-317 swept wing geometry.NASA TM-103705,1991. [7] Bourgault Y,Habashi W G,Dompierre J,et al.An Eulerian approach to supercooled droplets impingement calculations.AIAA 97-0176,1997. [8] Hospers J M,Hoeijmakers H W M.Eulerian method for ice accretion on multiple-element airfoil sections.AIAA-2010-1236,2010. [9] Cristhian N A,Martin S A,Guido S B,et al.FENSAP-ICE-unsteady:unified in-flight lcing silulation methodology for aircraft,rotorcraft,and jet engines[J].Journal of Aircraft,2011,48(1):119-126. [10] Petrosino F,Mingione G,Carozza A,et al.Ice accretion model on multi-element airfoil[J].Journal of Aircraft,2011,48(6):1913-1920. [11] 杨倩,常士楠,袁修干.水滴撞击特性的数值计算方法研究[J].航空学报,2002,23(2):173-176. YANG Qian,CHANG Shinan,YUAN Xiugan.Study on numerical method for determining the droplet trajectories[J].Acta Aeronautica et Astronautica Sinica,2002,23(2):173-176.(in Chinese) [12] 张强,胡利,曹义华.过冷水滴撞击三维机翼的数值模拟[J].航空动力学报,2009,24(6):1345-1350. ZHANG Qiang,HU Li,CAO Yihua.Three-dimensional numerical simulation of supercooled deoplets impinging on a wing[J].Journal of Aerospace Power,2009,24(6):1345-1350.(in Chinese) [13] 易贤,朱国林,王开春,等.翼型积冰数值模拟[J].空气动力学学报,2002,20(4):428-433. YI Xian,ZHU Guolin,WANG Kaichun,et al.Numerical simulating of ice accretion on airfoil[J].ACTA Aerodynamic Sinica,2002,20(4):428-433.(in Chinese) [14] Messinger B L.Equilibrium temperature of an unheated icing surface as a function of air speed[J].Journal of the Aeronautical Sciences,1953,20(1):29-42. [15] Myers T G,Charpin J P F.A mathematical model for atmospheric ice accretion and water flow on a cold surface[J].International Journal of Heat and Mass Transfer,2004,47(25):5483-5500. [16] Bourgault Y,Beaugendre H,Habashi W G.Development of a shallow water icing model in FENSAP-ICE[J].Journal of Aircraft,2000,37(4):640-646. [17] Otta S P,Rothmayer A P.A simple boundary-layer water film model for aircraft icing.AIAA-2007-902,2007. [18] Karev A R,Masoud F,Laszlo E K.Measuring temperature of the ice surface during its formation by using infrared instrumentation[J].International Journal of Heat and Mass Transfer,2007,50(3):566-579. [19] List R.Physics of supercooling of thin water skins covering gyrating hailstones[J].Journal of Atmospheric Sciences,1990,47(15):1919-1925. [20] Blackmore R Z,Lozowski E P.A theoretical spongy spray icing model with surficial structure[J].Atmospheric Research,1998,49(4):267-288. [21] 张大林,杨曦,昂海松.过冷水滴撞击结冰表面的数值模拟[J].航空动力学报,2003,18(1):87-91. ZHANG Dalin,YANG Xi,ANG Haisong.Numerical simulation of supercooled water droplets impingement on icing surfaces[J].Journal of Aerospace Power,2003,18(1):87-91.(in Chinese) [22] Dukler A E,Bergelin O P.Characteristics of flow in falling liquid films[J].Chemical Engineering Progress,1952,48(11):557-563. [23] Szilder K,Lozowski E P,Gates E M.Modelling ice accretion on non-rotating cylinders-the incorporation of time dependence and internal heat conduction[J].Cold Regions Science and Technology,1987,13(2):177-191. [24] Tirmizi S H,Gill W N.Effect of natural convection on growth velocity and morphology of dendritic ice crystals[J].Journal of Crystal Growth,1987,85(3):488-502. [25] Papadakis M,Rachman A,Wong S C,et al.Water impingement experiments on a NACA 23012 airfoil with simulated glaze ice shapes.AIAA-2004-0565,2004.
