喷油杆与凹腔支板稳定器近距匹配雾化特性

罗莲军; 刘玉英; 张文龙; 季鹤鸣

喷油杆与凹腔支板稳定器近距匹配雾化特性

北京航空航天大学能源与动力工程学院, 北京 100191

计量
- 文章访问数: 1385
- HTML浏览量: 2
- PDF量: 1050
- 被引次数: 0
出版历程
- 收稿日期: 2012-11-03
- 刊出日期: 2013-11-28

Atomization characteristics of fuel injector and cavity-based strut flame stabilizer under close-range matching condition

School of Energy and Power Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 以水和煤油为雾化介质,采用马尔文激光粒度仪研究了来流马赫数为0.16~0.24、喷雾压差为0.30~0.90MPa、喷油杆与凹腔支板稳定器间隔为31.5mm且顺喷时液雾在轴向不同位置处的雾化特性.研究结果表明:液滴索太尔平均直径(SMD)随来流马赫数增大而减小,随喷雾压差升高而减小,但凹腔支板稳定器下游远方截面的液滴SMD在主流区对马赫数不敏感,在回流区对喷雾压差不敏感.此外,喷油杆下游液滴SMD沿轴向逐渐减小,沿径向在主流区逐渐增大,在回流区逐渐减小.
- 雾化 /
- 激光粒度仪 /
- 索太尔平均直径 (SMD) /
- 凹腔支板稳定器 /
- 近距匹配
Abstract: Malvern laser particle analyzer was used to study the atomization characteristics along the axial direction of fuel injector and cavity-based strut flame stabilizer under close-range matching condition, with stream Mach number of 0.16 to 0.24, spray pressure drop of 0.30MPa to 0.90MPa, distance of fuel injector and stabilizer up to 31.5mm and spray in the direction of stream flow with water and kerosene. The results show that the Sauter mean diameter(SMD) of liquid drop decreases with increasing stream Mach number and increasing spary pressure drop. But the SMD of liquid drop was not sensitive to spray pressure drop in recirculation zone and to Mach number in main stream zone at the far-field downstream position of cavity-based strut flame stabilizer. Furthermore, the SMD of liquid drop decreases gradually along the axial direction, and decreases gradually in recirculation zone but increased gradually in main stream zone along the radical direction.
- atomization /
- laser particle analyzer /
- Sauter mean diameter(SMD) /
- cavity-based strut flame stabilizer /
- close-range matching

HTML

参考文献(15)

[1]	《航空发动机设计手册》总编委会.航空发动机设计手册:第11册加力燃烧室[M].北京:航空工业出版社,2001.
[2]	侯晓春,季鹤鸣,刘庆国,等.高性能航空燃气轮机燃烧技术[M].北京:国防工业出版社,2002.
[3]	马梦颖,金捷,季鹤鸣.航空发动机加力燃烧室技术及新颖结构方案[J].燃气涡轮试验与研究,2008,21(4):55-59. MA Mengying,JIN Jie,JI Heming.Technology and new configuration of aero-engine afterburner[J].Gas Turbine Experiment and Research,2008,21(4):55-59.(in Chinese)
[4]	孙雨超,张志学,李江宁,等.一体化加力燃烧室方案设计及数值研究[J].航空科学技术,2011(4):71-74. SUN Yuchao,ZHANG Zhixue,LI Jiangning,et al.Design and numerical research of integrated rear frame and afterburner[J].Aeronautical Science and Technology,2011(4):71-74.(in Chinese)
[5]	金如山,索建秦.先进加力燃烧室技术发展.贵阳:中国航空学会第七届动力年会,2010.
[6]	季鹤鸣,樊未军,杨茂林.新型内突扩加力燃烧室方案可行性分析[J].航空发动机,2006,32(1):35-37. JI Heming,FAN Weijun,YANG Maolin. Feasibility analysis of a new inner dumped afterburner concept[J].Aeroengine,2006,32(1):35-37.(in Chinese)
[7]	吴迪,金捷,季鹤鸣.一种加力燃烧室凹腔支板火焰稳定方案研究.贵阳:中国航空学会第七届动力年会,2010.
[8]	吴迪,金捷,季鹤鸣,等.凹腔支板尾缘涡脱落频率试验研究[J].航空发动机,2011,37(4):48-51. WU Di,JIN Jie,JI Heming,et al.Experimental study of vortex shedding frequency at trailing edge of a cavity-based strut[J].Aeroengine,2011,7(4):48-51.(in Chinese)
[9]	吴迪.新型一体化加力燃烧室冷态流场试验研究.北京:北京航空航天大学,2010. WU Di.Experimental research of non-reacting flow fields in a novel integrated afterburner.Beijing:Beijing University of Aeronautics and Astronautics,2010.(in Chinese)
[10]	刘雯佳,金捷,季鹤鸣.带凹腔支板的数值模拟[J].燃气涡轮试验与研究,2010,23(4):35-38. LIU Wenjia,JIN Jie,JI Heming.Numerical simulation on strut with cavity[J].Gas Turbine Experiment and Research,2010,23(4):35-38.(in Chinese)
[11]	Lovett J A,Brogan T P,Philippon D S,et al.Development needs for advanced afterburner designs.AIAA-2004-4192,2004.
[12]	王俭,顾善建,杨茂林,等.直射式喷嘴跨流喷射的雾化特性实验研究[J].航空学报,1990,11(4):157-164. WANG Jian,GU Shanjian,YANG Maolin.Study on atomization features of a plain injector in high speed transverse air stream[J].Acta Aeronautica et Astronautica Sinica,1990,11(4):157-164.(in Chinese)
[13]	徐行,郭志辉,边寿华.直射式喷嘴喷雾特性的实验研究[J].航空动力学报,1997,12(4):341-344. XU Hang,GUO Zhihui,BIAN Shouhua.Experiment on spray characteristics of direct injector[J].Journal of Aerospace Power,1997,12(4):341-344.(in Chinese)
[14]	柳杨,马文杰,李瑞明,等.侧喷挡板式雾化喷油杆喷雾特性实验[J].航空动力学报,2009,24(5):987-993. LIU Yang,MA Wenjie,LI Ruiming,et al.Experiment on spray characteristics of baffle-type injector in cross flow[J].Journal of Aerospace Power,2009,24(5):987-993.(in Chinese)
[15]	杨茂林,黄勇,顾善建,等.燃油在稳定器尾缘的二次雾化研究[J].航空动力学报,1992,7(1):61-64. YANG Maolin,HUANG Yong,GU Shanjiang,et al.Study on secondary atomization of liquid fuel at the lip of the flameholder[J].Journal of Aerospace Power,1992,7(1):61-64.(in Chinese)
