双S弯喷管流动特性及红外辐射特性分析

章叶川; 王占学; 史经纬; 方立; 孔德英

双S弯喷管流动特性及红外辐射特性分析

1.
西北工业大学动力与能源学院, 西安 710007
2.
中国航空工业集团公司第一飞机设计研究院, 西安 710089

基金项目: 国家自然科学基金(51176156);教育部博士点基金(20106102110025)

计量
- 文章访问数: 1441
- HTML浏览量: 46
- PDF量: 971
- 被引次数: 0
出版历程
- 收稿日期: 2012-11-01
- 刊出日期: 2013-11-28

Analysis on flow and infrared radiation characteristics of double S-nozzle

1.
School of Power and Energy, Northwestern Polytechnical University, Xi'an 710007
2.
The First Aircraft Institute, Aviation Industry Corporation of China, Xi'an 710089, China

摘要

摘要: 基于分区控制技术,发展了型面易控的双S弯喷管型面设计方法,用CFD数值模拟技术,对双S弯喷管的流动特性进行了数值模拟.采用信息通道界面(MPI)并行算法编写了基于离散传递法的红外辐射特性计算程序,对双S弯喷管红外辐射特性进行了计算,并与具有相同进出口面积的轴对称收缩喷管的红外辐射特性进行了对比.研究表明:双S弯喷管宽边探测面红外辐射强度低于窄边探测面红外辐射强度,最大幅度为80%;与轴对称收缩喷管相比,双S弯喷管红外辐射强度明显降低,尤其在宽边探测面的30°~40°探测方向上,比轴对称收缩喷管的红外辐射强度低大约30%.
- 双S弯喷管 /
- 流动特性 /
- 离散传递法 /
- 红外辐射 /
- 数值模拟
Abstract: Based on partition control technology and CFD numerical simulation,the easily controllable design methods of double S-nozzle type surface were developed,and the flow characteristics of double S-nozzle were simulated.With message passing interface (MPI) parallel algorithm and discrete transfer method,the software of infrared radiation characteristics was programmed.The infrared radiation characteristics of double S-nozzle were computed by the software.The infrared radiation characteristics were compared with those of axisymmetric convergent nozzle with the same inlet and outlet areas.The results show that the infrared radiation intensity of wide detection surface of double S-nozzle is less than that of the narrow detection surface,with the biggest margin up to 80%.The infrared radiation intensity on each probing direction is lower than that of axisymmetric convergent nozzle,especially on the probing direction between 30° and 40° in the wide detection surfaces,and the infrared radiation intensity of double S-nozzle is lower 30% than that of axisymmetric convergent nozzle.
- double S-nozzle /
- flow characteristics /
- discrete transfer method /
- infrared radiation /
- numerical simulation

HTML

参考文献(15)

[1]	刘永昌,朱虹.红外寻的制导的发展现状与新趋势[J].红外技术,1999,21(4):7-12. LIU Yongchang,ZHU Hong.The development and new trend of IR seeking guidance techniques[J].Infrared Technology,1999,21(4):7-12.(in Chinese)
[2]	郑礼宝.全尺寸二元喷管红外辐射特性研究[J].航空学报,2002,23(2):140-142. ZHENG Libao.Infrared emissions from turbojet with two-dimensional nozzle[J].Acta Aeronautica et Astronautica Sinica,2002,23(2):140-142.(in Chinese)
[3]	刘常春,吉洪湖,李娜,等.一种二元S弯喷管的红外辐射特性数值研究[J].工程热物理学报,2010,31(9):1567-1570. LIU Changchun,JI Honghu,LI Na,et al.Numerical simulation on infrared radiant characteristics of 2D S-nozzles[J].Journal of Engineering Thermophysics,2010,31(9):1567-1570.(in Chinese)
[4]	张勃,吉洪湖.大宽高比矩形喷管的射流与外流的掺混特性的数值研究[J].航空动力学报,2005,20(1):104-110. ZHANG Bo,JI Honghu.Numercial study of internal and external flow mixing for rectangular nozzles with large aspect ratio[J].Journal of Aerospace Power,2005,20(1):104-110.(in Chinese)
[5]	Lee C C.Subsonic diffuser design and performance for advanced fighter aircraft.AIAA 85-3073,1985.
[6]	张武生,薛巍,李建江,等.MPI并行程序设计实例教程[M].北京:清华大学出版社,2009.
[7]	张建奇,方小平.红外物理[M].西安:西安电子科技大学出版社,2004.
[8]	潘丞雄,张靖周,邵万仁.齿冠状收敛喷管模型气动和红外辐射特性数值研[J].航空动力学报,2010,25(7):1518-1523. PAN Chengxiong,ZHANG Jingzhou,SHAO Wanren.Numerical research on flow dynamics and infrared radiant on characteristics for scaled chevron convergent nozzle[J].Journal of Aerospace Power,2010,25(7):1518-1523.(in Chinese)
[9]	罗昕,张靖周,单勇.加遮挡板后二元喷管的红外辐射特性数值模拟[J].推进技术,2008,29(6):696-700. LUO Xin,ZHANG Jingzhou,SHAN Yong.Numerical research on infrared radiation characteristics of two dimension nozzle with shelter baffles[J].Journal of Propulsion Technology,2008,29(6):696-700.(in Chinese)
[10]	施小娟,吉洪湖,罗明东.发动机背负式安装无人机的排气系统红外特征的计算研究[J].航空动力学报,2008,23(4):651-656. SHI Xiaojuan,JI Honghu,LUO Mingdong.Numerical simulation of infrared radiation characteristics for exhaust system of an UAV with engine installed on the back of the fuselage[J].Journal of Aerospace Power,2008,23(4):651-656.(in Chinese)
[11]	杨承宇,张靖周,单勇.单边膨胀喷管红外辐射特性的数值模拟[J].航空学报,2010,31(10):1920-1926. YANG Chenyu,ZHANG Jingzhou,SHAN Yong.Numerical simulation on infrared radiation characteristics of single expansion ramp nozzles[J].Acta Aeronautica et Astronautica Sinica,2010,31(10):1920-1926.(in Chinese)
[12]	张小英,王先炜.轴对称矢量喷管红外特性的数值计算研究[J].航空动力学报,2004,19(5):367-369. ZHANG Xiaoying,WANG Xianwei.Numerical research of infrared characteristics of axial-symmetrical vectored nozzle[J].Journal of Aerospace Power,2004,19(5):367-369.(in Chinese)
[13]	金捷,朱谷君,徐南荣,等.发动机高速排气系统红外辐射特性的数值计算和分析[J].航空动力学报,2002,17(5):583-585. JIN Jie,ZHU Gujun,XU Nanrong,et al.Numerical simulation of infrared radiation characteristics for aeroengine high-speed exhaust system[J].Journal of Aerospace Power,2002,17(5):583-585.(in Chinese)
[14]	刘林华,董士奎,余其铮,等.红外1~14μm 波长间隔0.1μm上大气平均透过率:Ⅱ 水蒸气的透过率[J].哈尔滨工业大学学报,1999,31(6):75-78. LIU Linhua,DONG Shikui,YU Qizheng,et al.Atmospheric mean tansmittance in wavelength interval 0.1 μm form infrared 1 to 14 μm:Ⅱ transmittance of water vapor[J].Journal of Harbin Institute of Technology,1999,31(6):75-78.(in Chinese)
[15]	刘林华,董士奎,余其铮,等.红外1~14μm波长间隔0.1μm上大气平均透过率:Ⅰ二氧化碳的透过率[J].哈尔滨工业大学学报,1998,30(5):8-12. LIU Linhua,DONG Shikui,YU Qizheng,et al.Atmospheric mean tansmittance in wavelength interval 0.1 μm form infrared 1 to 14 μm:Ⅰ transmittance of carbon dioxide[J].Journal of Harbin Institute of Technology,1998,30(5):8-12.(in Chinese)
