带多孔板的APU进气系统气动性能实验

汪明生; 王虎山; 李强; 黄国平

带多孔板的APU进气系统气动性能实验

南京航空航天大学能源与动力学院, 南京 210016

计量
- 文章访问数: 1351
- HTML浏览量: 0
- PDF量: 883
- 被引次数: 0
出版历程
- 收稿日期: 2012-10-16
- 刊出日期: 2013-11-28

Experiment on aerodynamic performance of APU air inlet system with perforated plate

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 利用实验方法对一类带多孔板的辅助动力装置(APU)进气系统气动性能进行了研究.实验结果表明:两出口的总压恢复系数和总压畸变指数均随流量的增加不断降低.总压恢复系数在定总流量时略微下降,在定配比时几乎线性下降.总压畸变在周向上主要受多孔板无孔区影响,径向上主要受流道曲率影响.随开孔率增加,总压恢复系数不断增加.动力端不同开孔率下,总压畸变以径向畸变为主,负载端在小开孔率时以周向畸变为主,大开孔率时径向畸变成为主要因素.
- 辅助动力装置 /
- 进气系统 /
- 多孔板 /
- 开孔率 /
- 气动性能
Abstract: The aerodynamic performance of a kind of air inlet system with perforated plate used in auxiliary power units (APU) was investigated experimentally. The experimental results show that with the increase of mass flow rate, the outlet total pressure recovery coefficient and total pressure distortion coefficient decrease. The total pressure recovery coefficient decreases slightly in the fixed total mass flow rate case, but decreases linearly in the fixed proportion case. The total pressure distortion is mainly influenced by the imperforate area of the whole perforated plate in the circumferential direction and the flow passage curvature in the radial direction. With the increase of orifice ratio, the outlet total pressure recovery coefficient increases accordingly. The total pressure distortion of power section is mainly influenced radially in different orifice ratios; the distortion of load section is mainly influenced circumferentially in small orifice ratio and radially in large orifice ratio.
- auxiliary power unit /
- air inlet system /
- perforated plate /
- orifice ratio /
- aerodynamic performance

HTML

参考文献(17)

[1]	冯大庸.航空发动机设计手册:第14册辅助动力装置及起动机[M].北京:航空工业出版社,2001.
[2]	Turk M A,Zeiner P K.Advanced technology payoffs for future rotorcraft,commuter aircraft,cruise missile,and APU propulsion systems.AIAA 86-1545,1886.
[3]	Vanco M R,Wintucky W T,Niedzwiecki R W.An overview of the small engine component technology (SECT) studies.AIAA 86-1542,1986.
[4]	赵运生,胡骏,吴铁鹰,等.大型民用飞机辅助动力装置性能仿真[J].航空动力学报,2011,26(7):1950-1958. ZHAO Yunsheng,HU Jun,WU Tieying,et al.Performance simulation of large civil aircraft auxiliary power unit[J].Journal of Aerospace Power,2011,26(7):1950-1958.(in Chinese)
[5]	李东杰.大型民机辅助动力装置关键技术.广东深圳:大型飞机关键技术高层论坛暨中国航空学会2007年学术年会,2007.
[6]	金中平.辅助动力装置及其标准发展综述[J].航空标准化与质量,1998(4):19-22. JIN Zhongping.The review of auxiliary power units and its standard development[J].Aeronautics Standardization and Quality,1998(4):19-22.(in Chinese)
[7]	黄国平,梁德旺,何志强.大型飞机辅助动力装置与微型涡轮发动机技术特点对比[J].航空动力学报,2008,23(2):383-388. HUANG Guoping,LIANG Dewang,HE Zhiqiang.Comparison of technical characteristics of APU and micro turbine engines for large aircraft[J].Journal of Aerospace Power,2008,23(2):383-388.(in Chinese)
[8]	Campbell D J.Revolutionary propulsion and power for 21st century aviation[J].AIAA-2003-2561,2003.
[9]	Matsushima Y,Takeuchi T,Kohri I.Prediction method of engine compartment air flow using CFD analysis[J].Japan Society of Automotive Engineerings Review,2000,21(2):197-203.
[10]	Jesus A B,Oliveira G L,Brodt C S.Methodology for the design of APU air inlets for regional commercial aircraft[J].AIAA-2003-722,2003.
[11]	邓智亮,唐宏刚,张乃昌,等.APU 进气管道口尺寸比例对进气性能影响研究[J].科技信息,2011(22):446-449.
[12]	Gorinevsky D,Dittmar K,Mylaraswamy D,et al.Model based diagnostics for an aircraft auxiliary power unit//Proceedings of the 2002 IEEE International Conference on Control Application.Glasgow,Scotland:IEEE,2002:215-220.
[13]	Soo Y K,Sergey V Y.Performance analysis of an auxiliary power unit based on static/dynamic mathematic modeling//Proceedings of the ASME Turbo Expo 2007 Conference.Montreal,Canada:ASME,2007:1013-1022.
[14]	Rodgers C.The performance of single-shaft gas turbine load compress or auxiliary power units.AIAA 83-1159,1983.
[15]	汪明生,黄国平,傅鑫,等.带输出轴的直升机进气道设计改进[J].航空动力学报,2010,25(12):2756-2762. WANG Mingsheng,HUANG Guoping,FU Xin,et al.Study of modifying helicopter inlet containing output shaft[J].Journal of Aerospace Power,2010,25(12):2756-2762.(in Chinese)
[16]	Perry R H,Gree D W,Maloney J O.Perry's chemical engineers' handbook[M].6th edition.New York:McGraw-Hill,1984.
[17]	Smith P L Jr,Van Winkle M.Discharge coefficients through perforated plates at Reynolds numbers of 400 to 3000[J].AIChE Journal,1958,4(3):266-268.
