高超声速内收缩进气道轴对称基准流场改进

李永洲; 张堃元; 罗蕾; 王磊

高超声速内收缩进气道轴对称基准流场改进

南京航空航天大学能源与动力学院, 南京 210016

基金项目: 国家自然科学基金(90916029,91116001)

计量
- 文章访问数: 1365
- HTML浏览量: 4
- PDF量: 855
- 被引次数: 0
出版历程
- 收稿日期: 2012-10-31
- 刊出日期: 2013-11-28

Modified axisymmetric basic flowfield for hypersonic inward turning inlet

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 针对轴对称基准流场中前缘曲激波靠近中心体的部分激波强度过大现象,基于马赫数分布可控反设计方法,将这道前缘曲激波分解为一道较弱弯曲激波和部分等熵压缩波,改进的基准流场存在“四波四区”结构且压缩效率明显提高.基于该改进的基准流场和常规“两波三区”基准流场分别设计了圆形进口的内收缩进气道并对其流场特点和性能进行数值研究.结果表明:改进的进气道的流场能较好保持基准流场的特点;在来流马赫数为4.0~7.0范围内具有较高的压缩效率和良好的流量捕获能力,设计点的出口压比和总压恢复系数分别为17.56和0.540;改进的进气道采用来流马赫数从高到低前缘弯曲激波和汇集的等熵压缩波依次封口的设计概念,在提高流量捕获能力的同时减小了总压损失,总体性能优于常规进气道,来流马赫数为7.0时总压恢复系数相对提高了23.6%,来流马赫数为4.0时流量系数相对提高了5.7%.
- 高超声速 /
- 内收缩进气道 /
- 基准流场 /
- 马赫数分布 /
- 设计方法 /
- 数值仿真
Abstract: The leading edge shock wave near the center body,which is too intensive in axisymmetric basic flowfield,was separated into one curved shock and partial isentropic compression wave using the design method of controllable Mach number distribution.With a structure of four shock waves and four regions,the modified basic flowfield could improve compression efficiency obviously.The circular intake inward turning inlets for modified basic flowfield and common basic flowfield of two shock waves and three regions were designed,and also numerically studied to obtain the flowfield characteristics and general performance.The results indicate the modified inlet has similar flowfield characteristics for the basic flowfield.It features high compression ratio and mass flow capture capability for Mach number of 4.0 to 7.0,and the pressure ratio and total pressure recovery coefficient are 17.56 and 0.540,respectively,at the design point.Besides,the leading shock and converged isentropic compression wave attached the cowl lip in turn while the Mach number of incoming flow varied from high to low,increasing the mass capture ratio and decreasing the total pressure loss.Its overall performance is better than common one with 23.6% higher total pressure recovery coefficient at Mach number of 7.0 and 5.7% higher mass flow coefficient at Mach number of 4.0.
- hypersonic /
- inward turning inlet /
- basic flowfield /
- Mach number distribution /
- design method /
- numerical simulation

HTML

参考文献(18)

[1]	Van Wie D,Mlder S.Applications of Busemann inlets design for flight at hypersonic speeds.AIAA 92-1210,1992.
[2]	SUN Bo,ZHANG Kunyuan,WANG Chengpeng,et al.Investigation on a streamtraced hypersonic busemann inlet[J].Journal of Aerospace Engineering,2010,224(1):57-63.
[3]	Smart M K.Design of three-dimensional hypersonic inlets with rectangular-to-elliptical shape transition[J].Journal of Propulsion and Power,1999,15(3):408-416.
[4]	贺旭照,乐嘉陵,宋文燕,等.基于轴对称喷管的三维内收缩进气道的设计与初步评估[J].推进技术,2010,31(2):147-152. HE Xuzhao,LE Jialing,SONG Wenyan,et al.3D inward turning inlet design basing on axisymmetric nozzle and its preliminary assessment[J].Journal of Propulsion Technology,2010,31(2):147-152.(in Chinese)
[5]	Matthews A J,Jones T V.Design and test of a modular waverider hypersonic intake.AIAA-2005-3379,2005.
[6]	尤延铖,梁德旺.内乘波式进气道内收缩基本流场研究[J].空气动力学学报,2008,26(2):203-207. YOU Yancheng,LIANG Dewang.Investigation of internal compression flowfield for internal waverider-derived inlet[J].Acta Aerodynamica Sinica,2008,26(2):203-207.(in Chinese)
[7]	南向军,张堃元,金志光,等.压升规律可控的高超声速内收缩进气道设计[J].航空动力学报,2011,26(3):518-523. NAN Xiangjun,ZHANG Kunyuan,JIN Zhiguang,et al.Investigation on hypersonic inward turning inlets with controlled pressure gradient[J].Journal of Aerospace Power,2011,26(3):518-523.(in Chinese)
[8]	李永洲,张堃元,南向军.基于马赫数分布规律可控概念的高超声速内收缩进气道设计[J].航空动力学报,2012,27(11):2484-2491. LI Yongzhou,ZHANG Kunyuan,NAN Xiangjun.Design of hypersonic inward turning inlets based on concept of controllable Mach number distribution[J].Journal of Aerospace Power,2012,27(11):2484-2491.(in Chinese)
[9]	郭军亮,黄国平,尤延铖,等.改善内乘波式进气道出口均匀性的内收缩基本流场研究[J].宇航学报,2009,30(5):1934-1940. GUO Junliang,HUANG Guoping,YOU Yancheng,et al.Study of internal compression flow field for improving the outflow uniformity of internal wave rider inlet[J].Journal of Astronautics,2009,30(5):1934-1940.(in Chinese)
[10]	Billig F S,Baurle R A,Tam C J,et al.Design and analysis of streamline traced hypersonic inlets.AIAA 99-4974,1999.
[11]	Ramasubramanian V,Lewis M,Starkey R.Performance of various truncation strategies employed on hypersonic Busemann inlets.AIAA 2009-7249,2009.
[12]	Oswatish K.Pressure recovery in missiles with reaction propulsion at high supersonic speeds.NACA TM 1140,1947.
[13]	Smart M K.Optimization of two-dimensional scramjet inlets[J].Journal of Aircraft,1999,36(2):430-433.
[14]	陈兵,徐旭,王元光,等.定几何混压式轴对称超声速进气道设计及性能计算[J].航空动力学报,2005,20(3):373-379. CHEN Bing,XU Xu,WANG Yuanguang,et al.Design and performance calculation the mixed-compression fixed-geometry axisymmetric supersonic inlets[J].Journal of Aerospace Power,2005,20(3):373-379.(in Chinese)
[15]	李永洲,张堃元,李志华,等.Ma数分布可控的高超内收缩进气道改进设计初探.长沙:2012年火箭推进技术学术年会,2012.
[16]	Drayna T W,Nompelis I,Candler G V.Hypersonic inward turning inlets:design and optimization.AIAA-2006-297,2006.
[17]	南向军,张堃元,金志光,等.矩形转圆形高超声速内收缩进气道数值及实验研究[J].航空学报,2011,32(6):988-996. NAN Xiangjun,ZHANG Kunyuan,JIN Zhiguang,et al.Numerical and experimental investigation of hypersonic inward turning inlets with rectangular to circular shape transition[J].Acta Aeronautica et Astronautica Sinica,2011,32(6):988-996.(in Chinese)
[18]	王翼,范晓樯,梁剑寒,等.三维侧压高超声速进气道不启动流场试验与数值模拟研究[J].宇航学报,2008,29(6):1927-1932. WANG Yi,FAN Xiaoqiang,LIANG Jianhan,et al.Experimental and numerical investigation on the unstart flowfield of a three-dimensional sidewall compression hypersonic inlet[J].Journal of Astronautics,2008,29(6):1927-1932.(in Chinese)
