真实爆震载荷作用下爆震室动态响应分析与壁厚优化

郑龙席; 陈景彬; 黄希桥; 卢杰; 陈星谷

真实爆震载荷作用下爆震室动态响应分析与壁厚优化

西北工业大学动力与能源学院, 西安 710072

计量
- 文章访问数: 1252
- HTML浏览量: 0
- PDF量: 801
- 被引次数: 0
出版历程
- 收稿日期: 2012-10-24
- 刊出日期: 2013-11-28

Dynamic response analysis and wall thickness optimization of detonation combustor under actual detonation loading

School of Power and Energy, Northwest Polytechnical University, Xi'an 710072, China

摘要

摘要: 针对一内径为60mm的爆震室,建立其有限元模型并通过加载实验获取真实爆震载荷,计算分析了多循环工作条件下不同因素对爆震室等效应力的影响,并以此为基础对等壁厚爆震室进行了壁厚优化.研究发现:爆震室后段的等效应力峰值较前段平均高出20MPa;温度因素对爆震室等效应变影响显著,30Hz时最大等效应变较不考虑温度场情况增加51.2%;与材料、温度因素相比,爆震室壁厚对等效应力影响较大,室温条件下,壁厚为0.95mm时,最大等效应力达200MPa,已经基本达到材料的屈服应力极限(205MPa);通过更换模型材料进行计算对比发现,选择具有较高屈服应力极限、弹性模量和较低密度的材料会降低爆震室工作时的等效应力.
- 脉冲爆震发动机 /
- 爆震室 /
- 多循环 /
- 结构强度 /
- 壁厚优化
Abstract: According to a detonation combustor with 60mm inner diameter,the finite element model was built,and the actual detonation loading obtained by experiments was loaded.The influences of different factors on equivalent stress of detonation combustor were calculated under multi-cycle working condition,and the optimization of the detonation combustor wall with constant thickness was completed.It is found that the peak equivalent stress at rear section is 20MPa higher than that at head section on average.The temperature has a significant effect on the equivalent strain of detonation combustor,and the maximum equivalent strain at 30Hz is increased by 51.2% if the temperature is considered.Compared with the material and temperature,the wall thickness of detonation combustor has great influence on the equivalent stress.Under the room temperature and wall thickness of 0.95mm,the maximum equivalent strain reaches 200MPa,almost reaching the yield limit (205MPa) of the material.The calculation results by replacing the model material show that materials with the characteristics of higher yield limit,modulus of elasticity and lower density can reduce the equivalent stress of detonation combustor.
- pulse detonation engine /
- detonation combustor /
- multi-cycle /
- structural intensity /
- wall thickness optimization

HTML

参考文献(15)

[1]	Tang S.Dynamic response of a thin-walled cylindrical tube international moving pressure.Michigan:University of Michigan,1963.
[2]	Shepherd J E.Pressure load and structural response of the BNL high-temperature detonation tube.U.S.Nuclear Regulatory Commission,DE-ac02-76ch00016,1992.
[3]	Beltman W M,Burcsu E N,Shepherd J E,et al.The structural response of cylindrical shells to internal shock loading[J].Journal of Pressure Vessel Technology,1999,121(3):315-322.
[4]	Beltman W M,Shepherd J E.Linear elastic response of tubes to internal detonation loading[J].Journal of Sound and Vibration,2002,252(4):617-655.
[5]	Mirzaei M,Mazaheri K,Biglari H.Analytical modeling of the elastic structural response of tube to internal detonation loading[J].International Journal of Pressure Vessels and Piping,2005,82(12):883-895.
[6]	Mirzaei M,Biglari H,Slavatian M.Analytical and numerical modeling of the transient elasto-dynamic response of a cylindrical tube to internal gaseous detonation[J].International Journal of Pressure Vessels and Piping,2006,83(7):531-539.
[7]	Mazaheri K,Mirzaei M,Biglari H.Transient dynamic response of tubes to internal detonation loading[J].Journal of Sound and Vibration,2006,297(1/2):106-122.
[8]	Mirzaei M.On amplification of stress waves in cylindrical tubes under internal dynamic pressures[J].International Journal of Mechanical Sciences,2008,50(8):1292-1303.
[9]	姜宏伟,郑龙席.单次爆震载荷作用下爆震室结构响应的数值研究[J].机械科学与技术,2011,30(10):1635-1640. JIANG Hongwei,ZHENG Longxi.Numerical analysis on the structural response of the detonation combustor to single detonation loading[J].Mechanical Science and Technology for Aerospace Engineering,2011,30(10):1635-1640.(in Chinese)
[10]	郑龙席,姜宏伟,严传俊,等.多循环脉冲爆震载荷作用下爆震室强度分析与结构优化[J].航空动力学报,2011,26(12):2777-2782. ZHENG Longxi,JIANG Hongwei,YAN Chuanjun,et al.Strength analysis and structural optimization of detonation combustor to multi-cycle pulse detonation loading[J].Journal of Aerospace Power,2011,26(12):2777-2782.(in Chinese)
[11]	郑龙席,严传俊,李牧.多循环PDE模型机爆震室壁温分布数值模拟[J].燃烧科学与技术,2007,13(5):414-420. ZHENG Longxi,YAN Chuanjun,LI Mu.Numerical simulation on detonation chamber wall temperature distribution of a multi-pulse detonation engine model[J].Journal of Combustion Science and Technology,2007,13(5):414-420.(in Chinese)
[12]	郑龙席,严传俊,范玮,等.脉冲爆震发动机模型机爆震室壁温分布试验研究[J].燃烧科学与技术,2003,9(4):344-347. ZHENG Longxi,YAN Chuanjun,FAN Wei,et al.Experimental investigation on outer wall temperature distribution of a pulse detonation engine model[J].Journal of Combustion Science and Technology,2003,9(4):344-347.(in Chinese)
[13]	李海鹏,何立明,周鑫.脉冲爆震发动机性能对爆震室材料强度的需求[J].机械科学与技术,2007,26(5):623-625. LI Haipeng,HE Liming,ZHOU Xin.Pulse detonation engine's requirements for material strength of its detonation chamber[J].Mechanical Science and Technology for Aerospace Engineering,2007,26(5):623-625.(in Chinese)
[14]	赵少汴.抗疲劳设计[M].北京:机械工业出版社,1994.
[15]	刘涛,杨凤鹏.精通ANSYS[M].北京:清华大学出版社,2002.
