基于临界平面的镍基单晶高温合金疲劳寿命预测模型

王荣桥; 荆甫雷; 胡殿印

基于临界平面的镍基单晶高温合金疲劳寿命预测模型

北京航空航天大学能源与动力工程学院, 北京 100191

计量
- 文章访问数: 1358
- HTML浏览量: 1
- PDF量: 979
- 被引次数: 0
出版历程
- 收稿日期: 2012-11-04
- 刊出日期: 2013-11-28

Fatigue life prediction model based on critical plane of nickel-based single crystal superalloy

School of Energy and Power Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 根据循环损伤累积的思想,发展了一种基于临界平面的镍基单晶高温合金疲劳寿命预测模型.以非弹性应变能密度最大的滑移面作为镍基单晶高温合金承受最大损伤的临界平面,并结合基于滑移系的黏塑性变形分析结果,建立了疲劳寿命与最大滑移系分解剪应力、最大滑移剪应变率、滑移剪应变范围、应变比以及拉伸/压缩保载频率等临界平面参数的函数关系.采用760℃下DD6单晶的疲劳试验结果对上述预测模型进行验证,试验与计算结果符合良好,基本在2倍分散带内.
- 镍基单晶高温合金 /
- 寿命预测 /
- 疲劳 /
- 黏塑性 /
- 临界平面 /
- 循环损伤累积
Abstract: A model was developed for fatigue life prediction of nickel-based single crystal superalloy based on critical plane and cyclic damage accumulation.The slip plane with the maximum inelastic strain energy density was chosen as the critical plane of nickel-based single crystal superalloy which was subjected to the most serious damage.Based on the results of viscoplastic deformation analysis on slip systems,the relation between the fatigue life and the parameters of the critical plane such as the maximum resolved shear stress,the maximum shear strain rate due to slip,shear strain range due to slip,strain ratio and the tension/compression dwell frequency,was formulated.The life prediction method was validated with the fatigue testing results of DD6 at 760℃.The experiments agree well with the calculations,and almost all of the results fall in the scatter band of 2.
- nickel-based single crystal superalloy /
- life prediction /
- fatigue /
- viscoplastic /
- critical plane /
- cyclic damage accumulation

HTML

参考文献(19)

[1]	胡壮麒,刘丽荣,金涛,等.镍基单晶高温合金的发展[J].航空发动机,2005,31(3):1-7. HU Zhuangqi,LIU Lirong,JIN Tao,et al.Development of the Ni-base single crystal superalloys[J].Aeroengine,2005,31(3):1-7.(in Chinese)
[2]	石多奇,杨晓光,于慧臣.一种镍基单晶和定向结晶的疲劳寿命模型[J].航空动力学报,2010,25(8):1871-1875. SHI Duoqi,YANG Xiaoguang,YU Huichen.Fatigue life prediction model for nickel-based single crystal and directionally solidified superalloy[J].Journal of Aerospace Power,2010,25(8):1871-1875.(in Chinese)
[3]	岳珠峰,陶仙德,尹泽勇,等.一种镍基单晶超合金高温低周疲劳的晶体取向相关性模型[J].应用数学与力学,2000,21(4):373-381. YUE Zhufeng,TAO Xiande,YIN Zeyong,et al.A crystallographic model for the orientation dependence of low cyclic fatigue property of a nickel-base single crystal superalloy[J].Applied Mathematics and Mechanics,2000,21(4):373-381.(in Chinese)
[4]	丁智平,刘义伦,尹泽勇.镍基单晶高温合金蠕变-疲劳寿命评估方法进展[J].机械强度,2003,25(3):254-259. DING Zhiping,LIU Yilun,YIN Zeyong.Development on evaluating method of creep-fatigue life of single crystal nickel-based superalloys[J].Journal of Mechanical Strength, 2003,25(3):254-259.(in Chinese)
[5]	Swanson G,Arakere N K.Effect of crystal orientation on analysis of single-crystal nickel-based turbine blade superalloys.NASA/TP-2000-210074,2000.
[6]	Arakere N K,Swanson G.Effect of crystal orientation on fatigue failure of single crystal nickel base turbine blade superalloys[J].Journal of Engineering for Gas Turbines and Power,2002,124(1):161-176.
[7]	Naik R A,DeLuca D P,Shah D M.Critical plane fatigue modeling and characterization of single crystal nickel superalloys[J].Journal of Engineering for Gas Turbines and Power,2004,126(2):391-400.
[8]	Ranjan S,Arakere N K.A fracture-mechanics-based methodology for fatigue life prediction of single crystal nickel-based superalloys[J].Journal of Engineering for Gas Turbines and Power,2008,130(3):032501.1-032501.8.
[9]	刘金龙.镍基单晶/定向凝固涡轮叶片铸造模拟及其合金低循环疲劳行为研究.北京:北京航空航天大学,2011. LIU Jinlong.Investigation on cast simulation and low cycle fatigue behavior of Ni-based single crystal and directionally solidified turbine blade.Beijing:Beijing University of Aeronautics and Astronautics,2011.
[10]	Jordan E H,Walker K P.A viscoplastic model for single crystals[J].Journal of Engineering Materials and Technology,1992,114:19-26.
[11]	于慧臣,吴学仁.航空发动机设计用材料数据手册:第四册[M].北京:航空工业出版社,2010.
[12]	Nelson R S,Levan G W,Harvey P R.Creep fatigue life prediction for engine hot section materials (isotropic):final report.NASA-CR-189221,1992.
[13]	Karolczuk A,Macha E.A review of critical plane orientations in multiaxial fatigue failure criteria of metallic materials[J].Internation Journal of Fracture,2005,134(3/4):267-304.
[14]	尚德广,王德俊.多周疲劳强度[M].北京:科学出版社,2007.
[15]	李影,苏彬.DD6单晶合金高温低周疲劳机制[J].航空动力学报,2003,18(6):732-736. LI Ying,SU Bin.Mechanisms of low cyclic fatigue of DD6 alloy at elevated temperature[J].Journal of Aerospace Power,2003,18(6):732-736.(in Chinese)
[16]	Tinga T,Brekelmans W A M,Geers M G D.Time-incremental creep-fatigue damage rule for single crystal Ni-base superalloys[J].Material Science and Engineering:A,2009,508(1):200-208.
[17]	Leckovitch V,Sievert R,Svendsen B.Simulation of deformation and lifetime behavior of a fcc single crystal superalloy at high temperature under low-cycle fatigue loading[J].International Journal of Fatigue,2006,28(12):1791-1802.
[18]	Staroselsky A,Cassenti B N.Creep,plasticity,and fatigue of single crystal superalloy[J].International Journal of Solids and Structures,2011,48(13):2060-2075.
[19]	Wan J S,Yue Z F.A low-cycle fatigue life model of nickel-based single crystal superalloys under multiaxial stress state[J].Material Science and Engineering:A,2005,392(1):145-149.
