基于线调频小波路径追踪阶比循环平稳解调的滚动轴承故障诊断

徐亚军; 于德介; 刘坚

基于线调频小波路径追踪阶比循环平稳解调的滚动轴承故障诊断

湖南大学机械与运载工程学院汽车车身先进设计制造国家重点实验室, 长沙 410082

基金项目: 国家自然科学基金(50875078);高等学校博士学科点专项科研基金(20060532009)

计量
- 文章访问数: 1626
- HTML浏览量: 227
- PDF量: 966
- 被引次数: 0
出版历程
- 收稿日期: 2012-10-27
- 刊出日期: 2013-11-28

Fault diagnosis of roller bearings based on chirplet path pursuit and order cyclostationary demodulation

State Key Laboratory of Advanced Design and Manufacturing for Vehicle Body, College of Mechanical and Vehicle Engineering, Hunan University, Changsha 410082, China

摘要

摘要: 针对变转速工况下滚动轴承的故障诊断问题,提出一种将线调频小波路径追踪算法与阶比循环平稳解调方法相结合的滚动轴承故障诊断方法.该方法先利用线调频小波路径追踪算法提取轴承的故障特征频率,再根据轴承的故障特征频率对变转速下时域振动信号的包络在角域等角度重采样,并对获取的角域平稳信号进行循环平稳解调,计算得到切片解调谱;最后根据切片解调谱识别滚动轴承故障.仿真分析和应用实例表明:该方法能准确提取变转速工况下滚动轴承的外圈与内圈故障故障特征,提取效果明显优于基于Wigner-Ville峰值跟踪法的包络阶次谱方法.
- 线调频小波 /
- 阶比跟踪 /
- 循环平稳解调 /
- 故障诊断 /
- 滚动轴承
Abstract: Aim at the problem of fault diagnosis of roller bearings with rotating speed fluctuation, a method for the fault diagnosis of roller bearings was proposed by combining the chirplet path pursuit algorithm with the order cyclostationary demodulation method. In this proposed method, the chirplet path pursuit algorithm was used to obtain the bearing fault characteristic frequency. According to the bearing fault characteristic frequency, the envelope of the time domain vibration signal with rotating speed fluctuation was resampled at constant angle increments in angular domain, and the obtained angular domain steady signal was dealt by cyclostationary demodulation. The slice demodulation spectrum was then acquired and used to diagnose the fault of roller bearings. Simulation analysis and application examples show that the proposed method can exactly extract the outer and inner fault characteristics of roller bearings with rotating speed fluctuation. Compared with the envelope order spectrum method based on Wigner-Ville distribution, the proposed method can obtain more distinct fault characteristic of roller bearings.
- chirplet /
- order tracking /
- cyclostationary demodulation /
- fault diagnosis /
- roller bearing

HTML

参考文献(22)

[1]	虞和济,韩庆大,李沈,等.设备故障诊断工程[M].北京:冶金工业出版社,2001.
[2]	钟秉林,黄仁.机械故障诊断学[M].北京:机械工业出版社,2007.
[3]	张帆,丁康.平方解调分析原理及在机械信号故障诊断中的应用[J].汕头大学学报:自然科学版,2002;17(1):42-47. ZHANG Fan,DING Kang.Application of square demodulation analysis in fault diagnosis for mechanical signal[J].Journal of Shantou University:Natural Science Edition,2002,17(1):42-47.(in Chinese)
[4]	丁康,孔正国,何志达.振动调幅信号的循环平稳解调原理与应用[J].振动工程学报,2005,18(3):304-308. DING Kang,KONG Zhengguo,HE Zhida.The principle and application of cyclostationary analysis for demodulation of amplitude modulated signals[J].Journal of Vibration Engineering,2005,18(3):304-308.(in Chinese)
[5]	姜鸣,陈进.循环自相关函数的解调性能分析[J].上海交通大学学报,2002,36(6):799-802. JIANG Ming,CHEN Jin.Demodulation analysis for cyclic autocorrelation function[J].Journal of Shanghai Jiaotong University,2002,36(6):799-802.(in Chinese)
[6]	陈向民,于德介,罗洁思.基于线调频小波路径追踪阶比循环平稳解调的齿轮故障诊断[J].机械工程学报,2012,48(3):95-101. CHEN Xiangmin,YU Dejie,LUO Jiesi.Gear tooth fault diagnosis by using order cyclostationary demodulating approach based on chirplet path pursuit[J].Journal of Mechanical Engineering,2012,48(3):95-101.(in Chinese)
[7]	周福昌,陈进,何俊,等.循环自相关函数的解调特性分析及其在故障诊断中的应用[J].振动工程学报,2004,17(suppl.1):280-283. ZHOU Fuchang,CHEN Jin,HE Jun,et al.Characteristics of demodulation about cyclic autocorrelation and its application in fault diagnosis[J].Journal of Vibration Engineering,2004,17(suppl.1):280-283.(in Chinese)
[8]	Capdessud C,Sidahmed M,Lacoume J L.Cyclostationary processes:application in gear faults early diagnosis[J].Mechanical System and Signal Processing,2000,14(3):371-385.
[9]	Randall R B,Antoni J,Chobsaard S.The relationship between spectral correlation and envelope analysis in the diagnostics of bearing faults and other cyclostationary machine signals[J].Mechanical System and Signal Processing,2001,15(5):945-962.
[10]	Antoniadis I,Glossiotis G.Cyclostationary analysis of rolling-element bearing vibration signals[J].Journal of Sound and Vibration,2001,248(5):829-845.
[11]	Raad A,Antoni J,Sidanmel M.Indicators of cyclostationarity:theory and application to gear fault monitoring[J].Mechanical System and Signal Processing,2008,22(3):574-587.
[12]	崔玲丽,高立新,蔡力钢,等.基于循环平稳解调的齿轮裂纹早期故障诊断研究[J].振动工程学报,2008,21(3):274-278. CUI Lingli,GAO Lixin,CAI Ligang,et al.Gear tooth crack early fault diagnosis based on the cyclostationary demodulation[J].Journal of Vibration Engineering,2008,21(3):274-278.(in Chinese)
[13]	Fyfe K R,Munck E D S.Analysis of computed ordertracking[J].Mechanical System and Signal Processing,1997,11(2):187-205.
[14]	Bossley K M,Mckendrick R J.Hybrid computed order tracking[J].Mechanical System and Signal Processing,1999,13(4):627-641.
[15]	Saavedra P N,Rodriguez C G.Accurate assessment of computed order tracking[J].Shock and Vibration,2006,13(1):13-32.
[16]	Capdessud C,Sidahmed M,Lacoume J L.Cyclostationary processes:application in gear faults early diagnosis[J].Mechanical System and Signal Processing,2000,14(3):371-385.
[17]	张贤达,保铮.非平稳信号分析与处理[M].北京:国防工业出版社,1998:20-26.
[18]	Candès E J,Charlton P R,Helgason H.Detecting highly oscillatory signals by chirplet path pursuit[J].Applied and Computational Harmonic Analysis,2008,24(1):14-40.
[19]	Anderson W G,Balasubramanlan R.Time-frequency detection of gravitational waves[J].Physical Review:D,1999,60(10):1-12.
[20]	PAN Minchun,CHIU Chunching.Investigation on improved Gabor order tracking technique and its applications[J].Journal of Sound and Vibration,2006,295(3):810-826.
[21]	丁康,李巍华,朱小勇.齿轮及齿轮箱故障诊断实用技术[M].北京:机械工业出版社,2005.
[22]	Mallat S,Zhang Z.Matching pursuit with time-frequency dictionaries[J].Signal Processing,1993,41(12):3397-3415.
