螺旋桨黏性流场非定常数值模拟
Unsteady numerical simulation of the viscous flow fields of the propeller
-
摘要: 基于多块结构滑移网格,采用多参考系模型(MFR),对某六叶螺旋桨黏性流场进行了非定常数值模拟.分别建立包围螺旋桨的旋转区域和螺旋桨以外的静止区域,很好地解决了螺旋桨的相对旋转问题.计算结果与实验结果吻合良好,验证了计算方法的正确性.对前进比为0.90和0.75情况下的桨后复杂流场进行分析,得到了螺旋桨尾涡的一些静态和动态特征,螺旋桨尾涡中包含正负两层,与实验观察到的现象一致.获得了螺旋桨对桨后轴向速度分布的影响规律:螺旋桨对桨叶45%和70%半径处轴向速度增加远大于90%半径处轴向速度;随前进比减小,该区域内轴向速度继续增加,90%半径处轴向速度几乎不变.Abstract: The viscous flow fields of a propeller with six blades have been numerically simulated with unsteady N-S equations based on structured sliding grids of multiple blocks. The rotational subzone containing the propeller and the stationary subzone was constructed separately based on MFR(multiple frames of reference),proving this is an effective approach to resolve the problems involving relative rotation of the propeller. The data of the calculation and the experiment agreed very well and proved that the method had good accuracy to simulate the fluids of a propeller. Then the complicated flow fields behind the propeller with advanced ratio of 0.90 and 0.75 were analyzed, and the static and dynamic features of the propeller trailing vortex the same as the phenomenon in the test were achieved: two opposite layers were incorporated into the propeller trailing vortex. The rules influenced by the propeller on the axial velocity were obtained: the increase of the income flow velocity in the area of 45% and 70% of the radius of the blade after the propeller is larger than the area of 90% of the radius; with the decrease of the advance ratio, the axial velocity still increases, and the area of the 90% of the radius almost keep unchanged.
-
Key words:
- propeller /
- viscous flow fields /
- unsteady /
- structure of the wake field /
- axis velocity
-
[1] Chandrasekaran B.Method for calculating effects of a prop fan on aircraft aerodynamics at subsonic speeds[R].AIAA 83-1216, 1983. [2] 陆林章.组合式推进器摸底方案流场LDV 测试报告[R].江苏 无锡:中国船舶科学研究中心科技报告, 2003. [3] Chesnakas C, Jessup S.Experimental characterization of propeller tip flow.Washington DC, US:USA 22nd Symposium on Naval Hydrodynamics, 1998. [4] Stella A, Guj G, Felice F D, et al.Propeller wake analysis by means of LDV phase sampling techniques[J].Experiments in Fluids, 2000, 28(1):1-10. [5] Cotroni A, Felicef D, Romanog P, et al.Investigation of the near wake of a propeller using particle image velocimetry[J].Experiments in Fluids, 2000(suppl.):227-236. [6] Calcagno G, Felice F D, Felli M.Propeller wake analysis behind a ship by stereo PIV[C]//Proceedings of the 24th Symposium on Naval Hydrodynamics.Fukuoka, Japan:Office of Naval Research, 2002:8-13. [7] Lee S J, Paik B G, Yoon J H, et al.Three component velocity field measurements of propeller wake using a stereoscopic PIV technique[J].Experiments in Fluids, 2004, 36(4):575-585. [8] Whitfield D L, Jameson A.Three dimensional Euler equation simulation of propeller wing interaction in transonic flow[R].AIAA 83-0286, 1983. [9] Zori L A J, Rajagopalan R G.Navier-Stokes calculations of rotor airframe interaction in forward flight[J].Journal of the American Helicopter Society, 1995, 40(2):57-67. [10] Chffin M S, Berry J D.Helicopter fuselage aerodynamics under a rotor by Navier-Stokes simulation[J].Journal of the American Helicopter Society, 1997, 42(3):235-243. [11] 李巍, 王国强, 汪蕾.螺旋桨黏流水动力特性数值模拟[J].上海交通大学学报, 2007, 41(7):1200-1204. LI Wei, WANG Guoqiang, WANG Lei.The numerical simulation of hydrodynamics characteristic in propeller[J].Journal of Shanghai Jiaotong University, 2007, 41(7):1200-1204.(in Chinese) [12] 韦喜忠, 黄振宇, 洪方文.基于非结构网格的螺旋桨周围流场大涡模拟[J].水动力学研究与进展, 2008, 23(4):419-425. WEI Xizhong, HUANG Zhenyu, HONG Fangwen.Large eddy simulation of flowfield about marine propeller on unstructured meshes[J].Chinese Journal of Hydrodynamics, 2008, 23(4):419-425.(in Chinese) [13] 张营川, 马骏.螺旋桨旋涡发放数值模拟[J].中国舰船研究, 2011, 6(5):55-60. ZHANG Yingchuan, MA Jun.Numerical simulation on vortex shedding of propeller[J].Chinese Journal of Ship Research, 2011, 6(5):55-60.(in Chinese) [14] 叶金铭, 熊鹰.螺旋桨尾流场的数值计算方法[J].水动力学研究与进展, 2007, 22(2):188-193. YE Jinming, XIONG Ying.Numerical computation method of propeller wake field[J].Journal of Hydrodynamics, 2007, 22(2):188-193.(in Chinese) [15] 陈科甲, 白俊强, 朱军.发动机短舱对翼身组合体跨音速气动特性影响研究[J].航空计算技术, 2010, 40(1):63-66. CHEN Kejia, BAI Junqiang, ZHU Jun.Research on transonic aerodynamic performence impact of the engine nacelle[J].Aeronautical Computing Technique, 2010, 40(1):63-66.(in Chinese) [16] 李广年, 张军, 陈正寿, 等.基于PIV数据的螺旋桨尾涡结构分析[J].船舶力学, 2011, 15(10):1110-1114. LI Guangnian, ZHANG Jun, CHEN Zhengshou, et al.Propeller trailing vortex analysis based on PIV experimental data[J].Journal of Ship Mechanics, 2011, 15(10):1110-1114.(in Chinese) [17] 李广年, 张军, 陆林章, 等.PIV, LDV在螺旋桨尾流测试中的比对应用[J].航空动力学报, 2010, 25(9):2083-2090. LI Guangnian, ZHANG Jun, LU Linzhang, et al.Comparative study of PIV and LDV measurements in the wake of a propeller[J].Journal of Aerospace Power, 2010, 25(9):2083-2090.(in Chinese)
