地面效应中前飞旋翼的自由尾迹计算

辛冀; 李攀; 陈仁良

地面效应中前飞旋翼的自由尾迹计算

南京航空航天大学航空宇航学院直升机旋翼动力学国家级重点实验室, 南京 210016

基金项目: 江苏省普通高校研究生科研创新计划（CXLX12_0166）；中央高校基本科研业务费专项资金

计量
- 文章访问数: 1706
- HTML浏览量: 188
- PDF量: 1115
- 被引次数: 0
出版历程
- 收稿日期: 2012-11-14
- 刊出日期: 2013-12-28

Calculation of free-wake of forward flying rotor in ground effect

National Key Laboratory of Rotorcraft Aeromechanics, College of Aerospace Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 发展了一种自由尾迹模型，用于对地面效应状态下的旋翼前飞流场进行数值模拟，并求解该状态下的旋翼气动特性.为了扩大模型的适用范围，使用了面元法模拟地面对流场的影响.为提高尾迹迭代的收敛性和精度，在计算模型中引入了地下尾迹等比例修正、环式地面面元分布等改进措施.结果显示：前进比增加，地面附近的旋翼流场由环流模式转变为地面涡模式.在前飞速度很小时出现的环流，对旋翼前缘的轴向下洗速度影响十分强烈，导致此时出现随前进比增加，旋翼拉力减小、需用功率几乎不变的特殊现象.将得到的旋翼气动特性参数随前进比变化情况同实验值进行了对比，证实了新构建模型的准确性.
- 地面效应 /
- 旋翼 /
- 自由尾迹 /
- 面元法 /
- 地面涡
Abstract: A free-wake based model was developed to predict the flow field and performance of a forward flying rotor in ground effect.In order to expand the application range of the model,the ground was modeled using surface panel method to simulate the influence of ground upon the flow field.For further improving the prediction convergence and accuracy,modification measures such as rectifying the wake vortices below the ground plane proportionally and distributing the ground panels circularly were incorporated into the model.The prediction results show that as the advance ratio increases,the flow regime below the rotor changes from recirculation to ground vortex mode.When rotor gets into the recirculation regime at extremely low advance ratio,the downwash velocity across rotor leading edge is very large.Which leads to an unexpected phenomenon that the rotor thrust decreases and the required rotor power almost keeps constant while the advance ratio increases.The predicted characteristic values of rotor aerodynamics at different advance ratios were then compared with experimental results and conformed well,proving the accuracy of the newly founded model.
- IGE (in ground effect) /
- rotor /
- free-wake /
- panel method /
- ground vortex

HTML

参考文献(21)

[1]	Sheridan P F, Weisner W.Aerodynamics of helicopter flight near the ground[R].Washington DC:The 33rd Annual AHS Forum, 1977.
[2]	Curtiss H C, Sun M, Putman W F, et al.Rotor aerodynamics in ground effect at low advance ratios[J].Journal of the American Helicopter Society, 1984, 29(1):48-55.
[3]	Ganesh S, Komerath N.Study of ground vortex structure of rotorcraft in ground effect at low advance ratios[R].AIAA-2006-3475, 2006.
[4]	Jenkins J L Jr.Trim requirements and static-stability derivatives from a wind-tunnel investigation of a lifting rotor in transition[R].NASA TND-2655, 1965.
[5]	Curtiss H C, Erdman W, SUN M.Ground effect aerodynamics[J].Vertica, 1987, 11(1):29-42.
[6]	Nathan N D, Green R B.Measurements of a rotor flow in ground effect and visualisation of the brown-out phenomenon[R].Montreal, Canada:The 64th Annual American Helicopter Society Forum, 2008.
[7]	何承健, 高正.贴地飞行的旋翼尾迹研究[J].航空学报, 1986, 7(4):325-331. HE Chengjian, GAO Zheng.A study of the rotor wake in nap-of-the-earth[J].Acta Aeronautica et Astronautica Sinica, 1986, 7(4):325-331.(in Chinese)
[8]	Kang N, Sun M.Simulated flowfields in near-ground operation of single and twin-rotor configurations[J].Journal of Aircraft, 2000, 37(2):214-220.
[9]	叶靓, 招启军, 徐国华.基于非结构嵌套网格方法的旋翼地面效应数值模拟[J].航空学报, 2009, 30(5):780-786. YE Liang, ZHAO Qijun, XU Guohua.Numerical simulation on flowfield of rotor in ground effect based on unstructured embedded grid method[J].Acta Aeronautica et Astronautica Sinica, 2009, 30(5):780-786.(in Chinese)
[10]	孙茂, Curtiss H C.近地低速飞行时旋翼尾涡系的畸变及其诱导速度[J].空气动力学学报, 1989, 7(1):35-42. SUN Mao, Curtiss H C.Rotor vortex wake distortion and its induced velocity in ground effect at low speed[J].Acta Aerodynamica Sinica, 1989, 7(1):35-42.(in Chinese)
[11]	Saberi H A, Maisel M D.A free-wake rotor analysis including ground effect[R].Saint Louis, US:The 43rd Annual American Helicopter Society Forum, 1987.
[12]	Lee C S, He C J.A free wake/ground vortex model for rotors at low speed in-ground-effect flight.Mountain View, US:The 51st Annual American Helicopter Forum, 1995.
[13]	Pulla D, Conlisk A T.The long time structure of the rotor wake in ground effect.AIAA-2005-1408, 2005.
[14]	Griffiths D A, Ananthan S, Leishman J G. Predictions of rotor performance in ground effect using a free-vortex wake model[J].Journal of the American Helicopter Society, 2005, 50(4):302-314.
[15]	Itoga N, Nagashima T, Iboshi N, et al.A new numerical method for predicting aero-mechanical behaviors of a rotor hovering at close proximity to inclined flat surface[R].Montreal, Canada:The 55th Annual American Helicopter Society Forum, 1999.
[16]	Griffiths D A.A study of multi-rotor interference and ground effect using a free-vortex wake model[D].Washington DC:University of Maryland, 2001.
[17]	Katz J, Plotkin A.Low-speed aerodynamics[M].2nd ed.Cambridge, UK:Cambridge University Press, 2001.
[18]	Bagai A.Contributions to the mathematical modeling of rotor flow-fields using a pseudo-implicit free-wake analysis.Washington DC:University of Maryland, 1995.
[19]	Anathan S, Leishman J G.Role of filament strain in the free-vortex medeling of rotor wakes[J].Journal of the American Helicopter Society, 2004, 49(2):176-191.
[20]	李攀, 陈仁良.旋翼桨尖涡模型及其参数确定方法研究[J].空气动力学学报, 2009, 27(3):296-302. LI Pan, CHEN Renliang.Research on rotor tip vortex model and the method for determining its parameter[J].Acta Aerodynamica Sinica, 2009, 27(3):296-302.(in Chinese)
[21]	王适存.直升机空气动力学[M].北京:航空专业教材编审组, 1985.
