机翼积冰数值模拟

李鑫; 白俊强; 王昆

机翼积冰数值模拟

西北工业大学航空学院, 西安 710072

计量
- 文章访问数: 1586
- HTML浏览量: 1
- PDF量: 996
- 被引次数: 0
出版历程
- 收稿日期: 2013-02-02
- 刊出日期: 2013-12-28

Numerical simulation of ice accretions on aircraft wing

School of Aeronautics, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 采用计算流体力学（CFD）方法对三段翼和MS-317后掠翼进行了积冰数值模拟研究，基于欧拉两相流理论，应用分区算法，对空气流场和水滴流场进行了数值求解，得到水滴收集率.求解3-D积冰模型得到积冰量.将MS-317的冰形计算结果与实验数据以及软件LEWICE3D的计算结果进行了对比.结果显示：三维积冰模型具有较好的精度，虽然预测的冰形与实验数据有一些差异，最大厚度方面，误差在13.1%以内，但是积冰的类型与体积和实验数据基本一致.
- 欧拉两相流 /
- 飞机积冰 /
- 多段翼 /
- 分区算法 /
- 多块网格 /
- 三维数值模拟
Abstract: Ice accretions on three-element airfoils and MS-317 swept wing were predicted by using CFD method. Based on Eulerian two phase flow theory, the governing equations for air and droplets were solved by using partition algorithm to obtain the water collection efficiency. The amount of ice accreted was calculated by solving the 3-D ice accretions model, and the predicted ice shape was compared with those of experimental and ice accretions software LEWICE3D results. The results show that the precision of the approach and algorithm is good. Although there are some discrepancies between the predicted ice shape and experimental ice shape, the error is less than 13.1% in terms of the maximum thickness, and the predicted ice shape is basically the same with the experiment data in terms of type and volume.
- Eulerian two phase flow /
- aircraft ice accretion /
- multi-element airfoil /
- partition algorithm /
- multi-block grid /
- three dimensional numerical simulation

HTML

参考文献(18)

[1]	陈维健, 张大林.飞机机翼结冰过程的数值模拟[J].航空动力学报, 2005, 20(6):1010-1017. CHEN Weijian, ZHANG Dalin.Numerical simulation of ice accretion on airfoils[J].Journal of Aerospace Power, 2005, 20(6):1010-1017.(in Chinese)
[2]	蒋胜距, 李凤蔚.基于N-S方程的翼型结冰数值模拟[J].西北工业大学学报, 2004, 22(5):559-562. JIANG Shengju, LI Fengwei.A better numerical simulation of ice accretion on airfoil[J].Journal of Northwestern Polytechnical University, 2004, 22(5):559-562.(in Chinese)
[3]	张强, 曹义华, 钟国.飞机机翼表面霜冰的三维数值模拟[J].航空动力学报, 2010, 25(6):1303-1309. ZHANG Qiang, CAO Yihua, ZHONG Guo.Three-dimensional numerical simulation of rime ice accretions on an aircraft wing[J].Journal of Aerospace Power, 2010, 25(6):1303-1309.(in Chinese)
[4]	Potapczuk M G, Bidwell C S.Numerical simulation of ice growth on a MS-317 swept wing geometry[R].NASA TM-103705, 1991.
[5]	Bourgault Y, Beaugendre H, Habashi W G.Development of a shallow water icing model in fensap-ice[J].Journal of Aircraft, 2000, 37(4):640-646.
[6]	Beaugendre H, Morency F, Habashi W G.Fensap-ice:roughness effects on ice shape prediction[R].AIAA-2003-1222, 2003.
[7]	Hedde T, Guffond D.ONERA three-dimensional icing model[J].AIAA Journal, 1995, 33(6):1038-1044.
[8]	Mingione G, Brandi V, Esposito B.Ice accretion prediction on multi-element airfoils[R].AIAA 97-0177, 1997.
[9]	Guy F, Ilinca A, Laforte J L, et al.Prediction of 2d airfoil ice accretion by bisection method and by rivulets beads modeling.AIAA-2003-1076, 2003.
[10]	Guy F, Laforte J L, Beisswenger A.Prediction of ice shapes on NACA0012 airfoil.AIAA-2003-2154, 2003.
[11]	常士楠, 苏心明, 邱义芬.三维机翼结冰模拟[J].航空学报, 2011, 32(2):212-222. CHANG Shinan, SU Xinming, QIU Yifen.Ice accretion simulation on three dimensional wings[J].Acta Aeronautica et Astronautica Sinica, 2011, 32(2):212-222. (in Chinese)
[12]	易贤, 桂业伟, 朱国林.飞机三维结冰模型及其数值求解方法[J].航空学报, 2010, 31(11):2152-2158. YI Xian, GUI Yewei, ZHU Guolin.Numerical method of a three-dimensional ice accretion model of aircraft[J].Acta Aeronautica et Astronautica Sinica, 2010, 31(11):2152-2158.(in Chinese)
[13]	张强, 胡利, 曹义华.过冷水滴撞击三维机翼的数值模拟[J].航空动力学报, 2009, 24(6):1345-1350. ZHANG Qiang, HU Li, CAO Yihua.Three dimensional numerical simulation of supercooled droplets impinging on a wing[J].Journal of Aerospace Power, 2009, 24(6):1345-1350.(in Chinese)
[14]	Potapczuk M G, Bidwell C S.Numerical simulation of ice growth on a MS-317 swept wing geometry[R].AIAA 91-263, 1991.
[15]	苏伟.基于CFD技术和代理模型的气动外形优化设计方法研究.西安:西北工业大学, 2007. SU Wei.Aerodynamic optimization design based on computational fluid dynamics and surrogate model.Xi'an:Northwestern Polytechnical University, 2007.(in Chinese)
[16]	张强, 高正红, 傅林.非结构网格在翼型积冰数值模拟中的应用[J].航空动力学报, 2011, 26(5):977-983. ZHANG Qiang, GAO Zhenghong, FU Lin.Application of unstructured grids in numerically simulating ice accretions on airfoils[J].Journal of Aerospace Power, 2011, 26(5):977-983.(in Chinese)
[17]	陈海昕.复杂外形绕流Euler/N-S方程数值分析.西安:西北工业大学, 1999. CHEN Haixin.Numerical analysis for complex configurations solving Euler/N-S equations.Xi'an:Northwestern Polytechnical University, 1999.(in Chinese)
[18]	Bidwell C S.Icing characteristic of a natural-laminar flow, a medium-speed, and a swept, medium-speed airfoil[R].NASA TM-103693, 1991.
