不同出口形状S形喷管的RSC特性

李岳锋; 杨青真; 李翔; 环夏

不同出口形状S形喷管的RSC特性

西北工业大学动力与能源学院, 西安 710072

计量
- 文章访问数: 1673
- HTML浏览量: 2
- PDF量: 1035
- 被引次数: 0
出版历程
- 收稿日期: 2012-11-06
- 刊出日期: 2013-12-28

RCS characteristic of S-shaped nozzle with different outlet shapes

School of Power and Energy, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 采用超椭圆方法、面积变化规律及中心线变化规律设计了三种出口形状的S形喷管，结合等效边缘电磁流（EEC）法和迭代物理光学（IPO）法开发了计算程序；EEC法分析喷管出口边缘产生的绕射场对S形喷管的雷达散射截面（RCS）的贡献；IPO法分析S形喷管腔体产生的散射场对S形喷管RCS的贡献；通过对两种电磁场所产生的电磁波的矢量叠加计算S形喷管的总RCS；在此基础上，研究了3种不同出口形状的S形喷管的RCS特性.结果表明：出口形状对RCS影响较大；圆形出口是3种S形喷管中RCS最小的；相互错位的锯齿修型可有效减小喷管的RCS；喷管的S形结构设计使得全局探测角内总散射场的RCS不关于0°探测角对称，并使得最大RCS移向正探测角.
- S形喷管 /
- 超椭圆方法 /
- 雷达散射截面 /
- 等效边缘电磁流法 /
- 迭代物理光学法
Abstract: Based on the expressions of the super-elliptic method, the center-line and proportion variation patterns, three types of S-shaped nozzle with different outlet shape were designed. A program was developed to combine the equivalent edge currents(EEC) method and iterative physical optic (IPO) method. The EEC method was applied to calculate the contribution of edge diffraction field of nozzle outlet to the radar cross section (RCS) of S-shaped nozzle, and the IPO method was used to calculate RCS created by scattering field of cavities of S-shaped nozzle. The total RCS of S-shaped nozzle was calculated through vector summation of electromagnetic wave generated by two electromagnetic fields. On this basis, RCS characteristics of the S-shaped nozzle with three different outlet shapes were investigated. The results show that the outlet shape has great effects on RCS, and the S-shaped nozzle with circular outlet have the minimum RCS. The dislocation of sawtooth modification can effectively decrease the RCS of nozzle. The S-shaped structure of nozzle makes the RCS of the total scattering filed not symmetrically distribute about 0° detection angle within the range of global detection, which shifts the maximum RCS to the region of the positive detection angle.
- S-shaped nozzle /
- super-ellipse method /
- radar cross section (RCS) /
- equivalent edge currents (EEC) method /
- iterative physical optic (IPO) method

HTML

参考文献(19)

[1]	阮颖铮.雷达截面与隐身技术[M].北京:国防工业出版社, 1998.
[2]	Knott E F.Radar cross section[M].Dedham, US:Artech House Inc, 1985.
[3]	Ruck G T.Radar cross section handbook[M].New York, US:Plenum Press, 1970.
[4]	阮颖铮.空腔结构电磁散射分析方法研究[J].电波科学学报, 1994, 9(1):73-82. RUAN Yingzheng.An EM scattering analysis on open-ended cavities[J].Chinese Journal of Radio Science, 1994, 9(1):73-82.(in Chinese)
[5]	万顺生, 罗屹洁, 郭荣伟.采用SBR法研究飞机进气道的雷达散射截面[J].航空动力学报, 2006, 21(6):1033-1036. WAN Shunsheng, LUO Yijie, GUO Rongwei.Research on RCS of airplane duct based on SBR method[J].Journal of Aerospace Power, 2006, 21(6):1033-1036.(in Chinese)
[6]	郭文彦, 朱颜镇, 李海涛.飞机进气道的高频电磁散射特性及RCS计算[J].哈尔滨工业大学学报, 1999, 31(1):123-129. GUO Wenyan, ZHU Yanzhen, LI Haitao.HF electromagnetic scattering properties and RCS calculation of the airplane's inlet[J].Journal of Harbin Institute of Technology, 1999, 31(1):123-129.(in Chinese)
[7]	Johason T W, Moffat D L.Electromagnetic scattering by open circular waveguides[J].Radio Scienee, 1982, 17(16):1547-1556.
[8]	Pathak P H, Burkholder R J.Model, ray and beam techniques for analyzing the EM scattering by open-ended waveguide cavities[J].IEEE Transaction on Antennas and Propagation, 1989, 37(5):635-647.
[9]	许小燕.开口腔体的RCS计算[D].西安:西安电子科技大学, 2007. XU Xiaoyan.Calculation of the radar cross section for open-ended cavities.Xi'an:Xidian University, 2007.(in Chinese)
[10]	石磊, 郭荣伟.蛇形进气道的电磁散射特性[J].航空学报, 2007, 28(7):1296-1301. SHI Lei, GUO Rongwei.Electromagnetic scattering characteristics of serpentine inlet[J].Acta Aeronautica et Astronautica Sinica, 2007, 28(7):1296-1301.(in Chinese)
[11]	姬金祖, 武哲, 刘战合.S弯进气道隐身设计中弯度参数研究[J].西安电子科技大学学报, 2009, 36(4):746-750. JI Jinzu, WU Zhe, LIU Zhanhe.Research on the curvature parameter in the S-shaped inlet's stealth design[J].Journal of Xidian University, 2009, 36(4):746-750.(in Chinese)
[12]	陈立海, 杨青真, 陈玲玲, 等.不同喷口修形的二元收敛喷管RCS数值模拟[J].航空动力学报, 2012, 27(3):513-520. CHEN Lihai, YANG Qingzhen, CHEN Lingling, et al.Numerical simulation of RCS for 2-D convergent nozzle with different trailing edges[J].Journal of Aerospace Power, 2012, 27(3):513-520.(in Chinese)
[13]	罗明东, 吉洪湖, 黄伟.二元喷管热喷流的红外光谱辐射特性实验[J].推进技术, 2007, 28(2)152-156. LUO Mingdong, JI Honghu, HUANG Wei.Experiment on spectral infrared radiation characteristic of exhaust jet from 2D nozzle of turbofan engine[J].Journal of Propulsion Technology, 2007, 28(2):152-156.(in Chinese)
[14]	李岳锋, 杨青真, 孙志强.超椭圆S形进气道的设计及气动性能研究[J].计算机仿真, 2011, 28(3):82-85. LI Yuefeng, YANG Qingzhen, SUN Zhiqiang.Design of super-elliptic S-shaped inlet and analysis of aerodynamic performance[J].Computer Simulation, 2011, 28(3):82-85. (in Chinese)
[15]	Lee C C, Boekicker C.Subsonic diffuser design and performance for advanced fighter aircraft.AIAA 85-3073, 1985.
[16]	Basteriro F, Rodriguez J L, Burkholder R J.An interative physical optics approach for analyzing the electromagnetic scattering by large open-ended cavities[J].IEEE Transaction on Antennas and Propagation, 1995, 43(4):356-361.
[17]	Robert J B, Tomas L.Forward-backward iterative physical optics algorithm for computing the RCS of open ended cavities[J].IEEE Transaction on Antennas and Propagation, 2005, 53(2):793-799.
[18]	聂在平, 方大纲.目标与环境电磁散射特性建模-理论、方法与实现:基础篇[M].北京:国防工业出版社, 2009.
[19]	Anastasis C P, Constantine A B, Craig R B.Radar cross section of trihedral corner reflectors using PO and MEC[J].Annals of Telecommunications, 1995, 50(5):510-516.
