二次流喷口形状对激波矢量控制喷管推力矢量特性影响

史经纬; 王占学; 刘增文; 张晓博

二次流喷口形状对激波矢量控制喷管推力矢量特性影响

西北工业大学动力与能源学院, 西安 710072

基金项目: 国家自然科学基金（51176156）；教育部博士点基金（20106102110025）

计量
- 文章访问数: 1471
- HTML浏览量: 4
- PDF量: 1132
- 被引次数: 0
出版历程
- 收稿日期: 2012-11-10
- 刊出日期: 2013-12-28

Effects of secondary injection forms on thrust vector performance of shock vector controlling nozzle

School of Power and Energy, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 基于CFD数值模拟技术，考虑变比热比及温度对黏度的影响，针对二次流喷口主要几何参数（二次喷射角度及喷口无量纲展向长度）在不同喷管落压比、二次流压比工况下对激波矢量控制喷管三维流动特性及推力矢量特性进行分析.研究表明：喷射角度增加，二次流喷射前主分离线前移，激波角度增加，在较小的二次流压比下随着喷射角度增加，推力矢量角增大，二次流压比为1.0和1.2时，存在最佳的喷射角度使得推力矢量角最大；喷口无量纲展向长度小于1.0时，喷口前分离涡演变为马蹄涡，并在喷口下游诱导尾涡，二次流压比大于0.6时随喷口无量纲展向长度增大，推力矢量角度增加.
- 激波矢量控制 /
- 喷口形状 /
- 数值模拟 /
- 流动特性 /
- 推力矢量角
Abstract: By taking alterable specific heat ratio and effects of temperature on viscosity coefficient into account,based on CFD technology,effects of secondary injection geometric parameters,including injection angle and non-dimension slot width,on three dimensional flow characteristic and vector performance of shock vector controlling nozzle under different nozzle pressure ratios and secondary pressure ratios were investigated.Results show that,with increase of injection angle,position of main separation line before injection slot moves forward and shock angle ascends.In case of smaller secondary pressure ratio,thrust vector angle increases with the injection angle.When secondary pressure ratios equal to 1.0 and 1.2,there is an optimal injection angle for a maximal thrust vector angle.If non-dimension slot length is less than 1.0,the separation vortex before injection slot becomes into horse vortex and induces wake vortex.When secondary pressure ratio is larger than 0.6,thrust vectoring angle ascends with the increase of non-dimensional slot length.
- shock vector control /
- injection form /
- numerical simulation /
- flow characteristic /
- thrust vector angle

HTML

参考文献(15)

[1]	Chiarelli C, Johnsen R K, Shieh C F.Fluidic scale model mutli-plane thrust vector control test results[R].AIAA 93-2433, 1993.
[2]	Mangin B, Chpoun A, Jacquin L.Experimental and numerical study of fluidic thrust vectoring of a two dimensional supersonic nozzle[R].AIAA-2006-3666, 2006.
[3]	王占学, 王玉男, 李志杰, 等.基于激波控制的流体推力矢量喷管推力矢量喷管试验[J].推进技术, 2011, 31(6):751-756. WANG Zhanxue, WANG Yunan, LI Zhijie, et al.Experiment on fluidic thrust vectoring nozzle based on shock control concept[J].Journal of Propulsion Technology, 2011, 31(6):751-756.(in Chinese)
[4]	Miller D N, Yagle P J, Hamstra J W.Fluidic throat skewing for thrust vectoring in fixed geometry nozzles[R].AIAA 99-0365, 1999.
[5]	Van der Veer M R, Strykowskit P J.Counterflow thrust vectoring control of subsonic jets:continuous and bistable regimes[J].Journal of Propulsion and Power, 1997, 13(3):412-420.
[6]	Deere K A.Summary of fluidic thrust vectoring research conducted at NASA langley research center[R].AIAA-2003-3800, 2003.
[7]	Wilson W G, Comparin R A.An analysis of the flow disturbance and side forces due to gaseous secondary injection into a rocket nozzle[R].AIAA 69-443, 1969.
[8]	Deere K A.PAB3D simulations of a nozzle with fluidic injection for yaw thrust-vector contorl[R].AIAA 98-3254, 1998.
[9]	Waithe K A, Deere K A.Experimental and computational investigation of multiple injection ports in a convergent-divergent nozzle for fluidic thrust vectoring[R].AIAA-2003-3802, 2003.
[10]	Hamed A, Laskowski G.A performance study of slots injection thrust vectoring in a 2DCD nozzle[R].AIAA 97-3154, 1997.
[11]	郭建中, 陈步学.基于推力矢量控制的气体二次喷射混合流场实验研究[J].流体力学实验与测量, 2003, 17(4):34-37. GUO Jianzhong, CHEN Buxue.Experimantal research of secondary injection based on thrust vector control[J].Experiments and Measurements in Fluidic Mechanics, 2003, 17(4):34-37.(in Chinese)
[12]	张群峰, 吕志咏, 王戈一.轴对称射流喷管的试验和数值模拟[J].推进技术, 2004, 25(2):139-143. ZHANG Qunfeng, LV Zhiyong, WANG Geyi, et al.Experimental and numerical simulation of an axisymmetric fluidc vectoring nozzle[J].Journal of Propulsion Technology, 2004, 25(2):139-143.(in Chinese)
[13]	Neely A J, Gesto F N, Young J.Performance studies of shock vector control fluidic thrust vectoring.AIAA-2007-5086, 2007.
[14]	张相毅, 王如根, 周敏, 等.单缝和双缝射流注入对二元喷管推力矢量的影响[J].推进技术, 2007, 28(6):629-632. ZHANG Xiangyi, WANG Rugen, ZHOU Min, et al.Effects of single and duel injection ports on thrust vector for 2D nozzle[J].Journal of Propulsion Technology, 2007, 28(6):629-632.(in Chinese)
[15]	李志杰, 王占学, 蔡元虎.二次流喷射位置对流体推力矢量喷管气动性能影响的数值模拟[J].航空动力学报, 2008, 23(9):1603-1608. LI Zhijie, WANG Zhanxue, CAI Yuanhu.Numeical simulation of aerodynamic effects of secondary injection positions on fluidic thrust vectoring nozzle[J].Journal of Aerospace Power, 2008, 23(9):1603-1608.(in Chinese)
