不可压缩湍流的多尺度模型

董鹤; 高歌; 李志强; 唐杨杨; 许欢; 包醒东

不可压缩湍流的多尺度模型

北京航空航天大学能源与动力工程学院, 航空发动机气动热力国家级重点实验室, 北京 100191

计量
- 文章访问数: 1539
- HTML浏览量: 2
- PDF量: 1087
- 被引次数: 0
出版历程
- 收稿日期: 2013-06-21
- 刊出日期: 2013-12-28

Multiscale model for incompressible turbulent flows

National Key Laboratory of Science and Technology on Aero-Engine Aero-thermodynamics, School of Energy and Power Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 基于可变时间间隔平均方法，提出了一种不可压缩湍流多尺度模型及平均流动方程.与传统的单尺度湍流模型不同，该模型在建立的过程中，保留了湍流的多尺度特性，结合平均流动方程，可以更好地预测湍流流场特征.通过模拟平面后台阶流动和不对称平板扩压器流动，并将预测结果与标准k-ε模型的预测结果对比，初步验证了其可信性及优越性.结果表明：计算所得的平面后台阶流动的流向再附长度与台阶边压力系数比比标准k-ε模型提高精度约20%；平板扩压器流动的回流区位置误差约为7%、倾斜壁面摩擦因数误差约为5%，而标准k-ε模型未能预测出分离现象.可以看出该模型适用于典型的分离流动，在湍流流场的预测中表现优异，具有一定的工程应用价值
- 湍流模型 /
- 多尺度 /
- 可变时间间隔平均 /
- 分离流动 /
- 非定常
Abstract: A multiscale model based on variable interval time average method and a set of averaged equations for incompressible turbulent flows were presented.Unlike traditional turbulence models,the multiscale characteristics of turbulent flows were researved during establishment,and more accurate prediction of the flow field was given.The credibility of this model was verified through numerical simulation of the flow over a back-facing step and the flow in an asymmetric plane diffuser.The reattachment length and the surface pressure coefficient on step-side wall for the flow over a back-facing step were closer to the experimental results than the results that calculated with the standard k-ε model, which is almost 20%. The error of the position of the recirculation zone for the flow in an asymmetric plane diffuser is almost 7%, and the error of the frictional resistance coefficient on inclined wall is almost 5%, while the flow separation could not be predicted using the standard k-ε model.Results show that this model is suitable for separated flows, and gives a more accurate prediction of flow field, so this model is useful in engineering application.
- turbulence model /
- multiscale /
- variable interval time average /
- separated flow /
- unsteady

HTML

参考文献(15)

[1]	Frisch U.Turbulence[M].Cambridge:Cambridge University Press, 1995.
[2]	Yih C S.Fluid mechanics[M].New York:McGraw-Hill, 1969.
[3]	张兆顺, 崔桂香, 许春晓.湍流理论与模拟[M].北京:清华大学出版社, 2005.
[4]	Hanjalic K, Launder B E, Schiestel R.Multiple-time-concepts in turbulence transport modeling[R].NASA NSG-2256, 1980.
[5]	Wilcox D C.Turbulence modeling for CFD[M].California:DCW Industries, 2006.
[6]	是勋刚.湍流[M].天津:天津大学出版社, 1994.
[7]	陶文铨.数值传热学[M].西安:西安交通大学出版社, 2001.
[8]	陈景仁.湍流模型及有限分析法[M].上海:上海交通大学出版社, 1989.
[9]	Kim J, Kline S J, Johnston J P.Investigation of a reattaching turbulent shear layer:flow over a backward-facing step[J].Journal of Fluids Engineering, 1980, 102(3):41-48.
[10]	Thangam S, Speziale C G.Turbulent separated flow past a backward-facing step:a critical evaluation of two-equation turbulence models[J].AIAA Journal, 1992, 30(5):1314-1320.
[11]	Obi S, Aoki K, Masuda S. Experimental and computational study of turbulent separating flow in an asymmetric plane diffuser[R].Kyoto:9th Symposium on Turbulent Shear Flows, 1993.
[12]	Buice C U, Eaton J K.Experimental investigation of flow through an asymmetric plane diffuser[J].Journal of Fluids Engineering, 2000, 122(2):433-435.
[13]	Durbin P.Separated flow computations with the k-ω-v² model[J].AIAA Journal, 1995, 33(4):659-664.
[14]	Apsley D D, Leschziner M A.Advanced turbulence modeling of separated flow in a diffuser[J].Flow, Turbulence and Combustion, 1999, 63(1/2/3/4):81-112.
[15]	江立军.对湍流模化的反观思考与模拟研究[D].北京:北京航空航天大学, 2012. JIANG Lijun.Reconsideration on turbulence modeling and numerical study[D].Beijing:Beijing University of Aeronautics and Astronautics, 2012.(in Chinese)
