不可压缩翼型绕流数值研究
Numerical investigation of impressible turbulent flows past airfoils
-
摘要: 使用标准k-ω模型及与色散模型相耦合的k-ω模型分别计算了NACA0012翼型和NACA 4412翼型的低速绕流问题.NACA 0012翼型计算了其来流雷诺数为2.88×106，攻角从0°到15°范围内的流动结构、翼型表面压力分布和升力、阻力特性；NACA 4412翼型计算了临界雷诺数为1.52×106，攻角为13.87°时的流动分离和翼型表面压力系数 ，并与实验数据进行对比.结果表明：在同等条件下，使用与色散模型相耦合的k-ω模型计算得到的NACA 0012翼型的升力和阻力系数比标准k-ω模型提高精度约5%，NACA 4412翼型的表面压力系数精度提高了约3%，进一步验证了其可信性，可将其进一步应用到低速飞行器的气动计算中.Abstract: The standard k-ω model and the k-ω model coupled with dispersion model were computed for turbulent flow over two airfoils, NACA 0012 and NACA 4412. The flow characteristics on the surface of the NACA 0012 airfoil were analyzed in detail under a typical Reynolds number of 2.88×106 and attack angle from 0° to 15° including pressure coefficient, lift coefficient and drag coefficient; the flow characteristics on the surface of the NACA 4412 airfoil were analyzed in detail under a typical Reynolds number of 1.52×106 and attack angle of 13.87° including the flow separation and pressure coefficient, and then compared with the experiment data. Under the same condition, the new model improved the accuracy of about 5% than the standard k-ω model when calculating the lift coefficient of NACA 0012, and improved the accuracy of about 3% than the standard k-ω model when calculating the pressure coefficient of NACA 4412. The results prove its credibility and value further more.
-
Key words:
- incompressible /
- dispersion effect /
- turbulence /
- airfoil /
- numerical investigation
-
[1] Guilmineau E, Piquet J, Queutey P.Two-dimensional turbulent viscous flow simulation past airfoils at fixed incidence[J].Computers and Fluids, 1997, 26(2):135-162. [2] Lien F S, Leschziner M A.Modeling 2D separation from a high lift aerofoil with a non-linear eddy-viscosity model and second-moment closure[J].Aeronautical Journal, 1995, 99(984):125-144. [3] Davidson L, Rizzi A. Navier-Stokes computation of airfoil in stall using algebraic Reynolds-stress model[R].AIAA 92-0195, 1992. [4] 钱炜祺, 蔡金狮.绕翼型低速湍流的数值模拟[J].航空学报, 1999, 20(3):261-264. QIAN Weiqi, CAI Jinshi.Numerical simulation of turbulent flow past airfoil at low Mach number[J].Acta Aeronautica et Astronautica Sinica, 1999, 20(3):261-264.(in Chinese) [5] 高歌.湍流的耗散及弥散相互作用理论[J].中国科学:A辑, 1985(5):457-465. [6] 董鹤, 高歌, 邸亚超.不可压缩湍流的色散模型[J].航空动力学报, 2013, 28(1):90-95. DONG He, GAO Ge, DI Yachao.Dispersion model for incompressible turbulent flows[J].Journal of Aerospace Power, 2013, 28(1):90-95.(in Chinese) [7] Wilcox D C.Turbulence modeling for CFD[M].California:DCW Industries, 2006. [8] Gregory N, O'Reilly C L.Low-speed aerodynamics of MACA0012 aerofoil section, including the effects of upper-surface roughness simulation hoar frost[R].National Physical Laboratory, NPL Aero Report 1308, 1970. [9] McCroskey W J.A critical assessment of wind tunnel results for the NACA 0012 airfoil[R].NASA Technical Memorandum 100019, 1987. [10] Ladson C L.Effects of independent variation of Mach and Reynolds numbers on the low-speed aerodynamics characteristic of the NACA 0012 airfoil section[R].NASA-TM-4074, 1988. [11] Eleni D C.Evaluation of the turbulence models for the simulation of the flow over a National Advisory Committee for Aeronautics (NACA) 0012 airfoil[J].Journal of Mechanical Engineering Research, 2012, 4(3):100-111. [12] Hong-Sik I M, Zhan G.Delayed detached eddy simulation of a stall flow over NACA0012 airfoil using high order schemes[R].AIAA-2011-1297, 2011. [13] 任鑫, 李百合, 尹幸愉, 等.使用GAO-YONG湍流方程组计算翼型分离流[J].航空动力学报, 2007, 22(1):73-78. REN Xin, LI Baihe, YIN Xingyu, et al.Calculation of airfoil flows using GAO-YONG turbulence equations[J]. Journal of Aerospace Power, 2007, 22(1):73-78.(in Chinese) [14] Coles D, Wadcock A J.Flying-hot-wire study of flow past an NACA 4412 airfoil at maximum lift[J].AIAA Journal, 1979, 17(4):321-329. [15] 江立军.对湍流模化的反观思考与模拟研究[D].北京:北京航空航天大学, 2012. JIANG Lijun.Reconsideration on turbulence modeling and numerical study[D].Beijing:Beijing University of Aeronautics and Astronautics, 2012.(in Chinese) -
