涡轮叶冠换热特性实验与数值模拟

喻雷; 常海萍; 胡正权

涡轮叶冠换热特性实验与数值模拟

南京航空航天大学能源与动力学院, 南京 210016

计量
- 文章访问数: 1599
- HTML浏览量: 111
- PDF量: 995
- 被引次数: 0
出版历程
- 收稿日期: 2012-11-16
- 刊出日期: 2013-12-28

Experiment and numerical simulation of heat transfer characteristics in turbine shroud

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 利用数值模拟及实验方法对涡轮叶冠间隙流场换热特性进行了研究，分析静止状态下叶尖泄漏流雷诺数、前后孔岀流比、叶尖间隙等参数对叶冠的表面传热系数的影响.结果表明：叶冠转速的变化对表面传热系数影响较小；随着泄漏流雷诺数的增加，叶冠的平均表面传热系数增大；平均表面传热系数随前、后孔岀流比增大而增大，其中前孔出流比的影响较为明显；叶尖间隙减小，平均表面传热系数增大，并且随叶尖间隙的减小，增长越来越快.将计算与实验结果进行了比较，吻合良好，误差小于10%.
- 叶冠 /
- 数值模拟 /
- 雷诺数 /
- 岀流比 /
- 表面传热系数
Abstract: Numerical simulation and experimental methods were used to study the heat transfer characteristics of tip clearance flow in turbine shroud cavity.The impact of tip clearance flow Reynolds,outflow ratio of the front and rear holes and tip clearance on the heat transfer characteristics were simulated.Results show that the shroud rotational speed has little effect on heat transfer coefficient;the shroud heat transfer coefficient increases with the increase of leakage flow Reynolds number;heat transfer coefficient also increases with the increase of the outflow ratio of the front and rear holes,and the impact of the ratio of the front holes is larger;heat transfer coefficient increases with decrease of the tip clearance and the mean heat coefficient,increases faster with the decrease of tip clearance.The results show excellent agreement with the measurements and simulations, the error is less than 10%.
- shroud /
- numerical simulation /
- Reynolds number /
- outflow ratio /
- heat transfer coefficient

HTML

参考文献(18)

[1]	Came P M.Tip clearance losses in turbines:a review of experimental data and prediction methods[R].NGTE/NT 1969-754, 1969.
[2]	Mayle R E, Metzger D E.Heat transfer at the tip of an unshrouded turbine blade[C]//Proceedings of the Seventh International Heat Transfer Conference.Munich, West Gemany:Hemisphere Publications, 1982:87-92.
[3]	Bindon J P.Pressure distributions in the tip clearance region of an unshrouded axial turbine as affecting the problem of tip burnout[R].ASME Paper 87-GT-230, 1987.
[4]	Ameri A A, Steinthorsson E, Rigby D L.Effect of squealer tip on rotor heat transfer and efficiency[J].Journal of Turbomachinery, 1997, 120(4):753-759.
[5]	Bunker R S, Bailey J C.Effect of squealer cavity depth and oxidation on turbine blade tip heat transfer[R].ASME Paper 2001-GT-155, 2001.
[6]	Kwak J S, Ahn J, Han J C, et al.Heat transfer coefficients on the squealer tip and near-tip regions of a gas turbine blade with single or double squealer[R].ASME Paper 2003-GT-38907, 2003.
[7]	Denton J D, Johnson C G.An experimental study of the tip leakage flow around shrouded turbine blades[R].Central Electricity Generating Board (CEGB) Report R/M/N848, 1976.
[8]	Denton J D.Loss mechanisms in turbomachines[R].ASME Paper 93-GT-435, 1993.
[9]	Pfau A, Kalfas A I, Abhari R S.Making use of labyrinth interaction flow[R]. ASME Paper 2004-GT-53797, 2004.
[10]	Rosic B, Denton J D, Curtis E M.The influence of shroud and cavity geometry on turbine performance:an experimental and computational study:Part Ⅰ shroud geometry[R].ASME Paper 2007-GT-27769, 2007.
[11]	Nirmalan N V, Bailey J C, Braaten M E.Experimental and computational investigation of heat transfer effectiveness and pressure distribution of a shrouded blade tip section[R].ASME Paper 2004-GT-53279.
[12]	Chyu M K, Moon H K, Metzger D E.Heat transfer in the tip region of grooved turbine blades[J].Journal of Turbomachinery, 1989, 111(2):131-138.
[13]	Ameri A A, Bunker R S.Heat transfer and flow on the first stage blade tip of a power generation gas turbine:Part 2 simulation results[R].Indianapolis:International Gas Turbine Conference, 1999.
[14]	Tallman J, Lakshminarayana B.Numerical simulation of tip leakage flows in axial flow turbines, with emphasis on flow physics:Part Ⅰ effect of tip clearance height[R].ASME Paper 2000-GT-0514, 2000.
[15]	Tallman J, Lakshminarayana B.Numerical simulation of tip leakage flows in axial flow turbines, with emphasis on flow physics:Part Ⅱ effect of outer casing relative motion[R].ASME Paper 2000-GT-0516, 2000.
[16]	李伟, 乔渭阳, 许开富, 等.雷诺数对涡轮叶尖流场影响的数值研究[J].推进技术, 2007, 28(4):388-393. LI Wei, QIAO Weiyang, XU Kaifu, et al.Numerical simulation for effects of Reynolds numbers on tip leakage flows in turbine[J].Journal of Propulsion Technology, 2007, 28(4):388-393.(in Chinese)
[17]	Xiao Y, Amano R S.Study of losses in a leakage flow through the passage of a shrouded turbine blades with swirl velocity[R].New Orleans:International Gas Turbine Conference, 2001.
[18]	Morphis G, Bindon J P.The effects of relative motion, blade edge radius and gap size on the blade tip pressure distribution in an annular turbine cascade[R].ASME Paper 88-GT-256, 1988.
