并联硅基扩缩微通道热沉强化传热特性

柴磊; 夏国栋; 周明正; 崔珍珍

并联硅基扩缩微通道热沉强化传热特性

1.
北京工业大学环境与能源工程学院, 北京 100124
2.
中国科学院工程热物理研究所, 北京 100190

基金项目: 国家自然科学基金（51176002）；国家重点基础研究发展计划（2011CB710704）；教育部博士点学科专项科研基金（20111103110009）

计量
- 文章访问数: 1291
- HTML浏览量: 3
- PDF量: 900
- 被引次数: 0
出版历程
- 收稿日期: 2012-11-05
- 刊出日期: 2013-12-28

Heat transfer enhancement characteristics of parallel-microchannel silicon heat sink with expansion-constriction cross sections

1.
College of Environmental and Energy Engineering, Beijing University of Technology, Beijing 100124, China
2.
Institute of Engineering Thermophysics, Chinese Academy of Sciences, Beijing 100190, China

摘要

摘要: 采用去离子水作为冷却工质，实验研究了并联硅基扩缩微通道热沉内的流体流动与强化传热特性.基于微尺度强化传热机理，设计加工了两种并联硅基扩缩微通道热沉.通过测量流体的体积流量、进出口压降与温度、热沉底面加热膜温度，并以传统矩形直通道热沉为参照，获得了并联硅基扩缩微通道热沉在恒热流边界条件和不同体积流量工况下流体流动与对流传热特性参数.结果显示：相对于矩形直通道，并联硅基扩缩微通道热沉的表面传热系数可提高12.5%~85.1%，但摩擦因数只增加了-9.2%~31.4%.表明并联硅基扩缩微通道热沉具有优越的强化传热特性.
- 扩缩 /
- 微通道 /
- 恒热流 /
- 摩擦因数 /
- 强化传热
Abstract: With deionized water as working fluid,experiments on fluid flow and heat transfer enhancement characteristics were conducted in the parallel-microchannel silicon heat sink with expansion-constriction cross sections.Based on the microscale heat transfer enhancement mechanism,two parallel-microchannel silicon heat sink with expansion-constriction cross sections were designed and processed.In contrast to the corresponding conventional rectangular microchannel heat sink,the flow and heat transfer parameters of parallel-microchannel silicon heat sink with expansion-constriction cross sections were obtained in different volume flow rates and constant wall heat flux,along with simultaneous measurement of volume flow rate,pressure drop and temperature in the inlet and outlet,and wall temperature at the substrate of heat sink.It is found that the heat transfer rate of parallel-microchannel silicon heat sink with expansion-constriction cross sections is increased by 12.5%-85.1% over the rectangular straight microchannel heat sink value,but the friction factor is only increased by -9.2%-31.4%,showing that the parallel-microchannel silicon heat sink with expansion-constriction cross sections has superior heat transfer enhancement characteristics.
- expansion-constriction /
- microchannel /
- constant heat flux /
- friction factor /
- heat transfer enhancement

HTML

参考文献(16)

[1]	王艳.基于MEMS加工工艺的复杂结构微通道散热器研究[D].上海:上海交通大学, 2009. WANG Yan.Investigation of microchannel heat sink with complicated channel structure based on MEMS technologies[D].Shanghai:Shanghai Jiaotong University, 2009.(in Chinese)
[2]	Xu J L, Gan Y H.Microscale heat transfer enhancement using thermal boundary layer redeveloping concept[J].International Journal of Heat and Mass Transfer, 2005, 48(9):1662-1674.
[3]	Xu J L, Song Y X.Numerical simulations of interrupted and conventional microchannel heat sinks[J].International Journal of Heat and Mass Transfer, 2008, 51(25):5906-5917.
[4]	Chen Y P, Cheng P.Heat transfer and pressure drop in fractal tree-like microchannel nets[J].International Journal of Heat and Mass Transfer, 2002, 45(13):2643-2648.
[5]	Chen Y P, Cheng P.An experimental investigation on the thermal efficiency of fractal tree-like microchannel nets[J].International Communications in Heat and Mass Transfer, 2005, 32(7):931-938.
[6]	Guzmán A M, Cardenas M J.Heat transfer enhancement by flow bifurcations in asymmetric wavy wall channels[J].International Journal of Heat and Mass Transfer, 2009, 52(15):3778-3789.
[7]	Sui Y, Teo C J.Fluid flow and heat transfer in wavy microchannels[J].International Journal of Heat and Mass Transfer, 2010, 53(13):2760-2772.
[8]	Sui Y, Lee P S.An experimental study of flow friction and heat transfer in wavy microchannels with rectangular cross section[J].International Journal of Thermal Sciences, 2011, 50(12):2473-2482.
[9]	Mohammed H A, Gunnasegaran P.Numerical simulation of heat transfer enhancement in wavy microchannel heat sink[J].International Communications in Heat and Mass Transfer, 2011, 38(1):63-68.
[10]	Promvonge P, Sripattanapipat S.Numerical investigation of laminar heat transfer in a square channel with 45° inclined baffles[J].International Communications in Heat and Mass Transfer, 2010, 37(2):170-177.
[11]	Promvonge P, Sripattanapipat S.Laminar periodic flow and heat transfer in square channel with 45° inline baffles on two opposite walls[J].International Journal of Thermal Sciences, 2010, 49(6):963-975.
[12]	Promvonge P, Jedsadaratanachai W.Numerical study of laminar flow and heat transfer in square channel with 30° inline angled baffle turbulators[J].Applied Thermal Engineering, 2010, 30(11):1292-1303.
[13]	Xia G D, Chai L, Zhou M Z.Effects of structural parameters on fluid flow and heat transfer in a microchannel with aligned fan-shaped reentrant cavities[J].International Journal of Thermal Sciences, 2011, 50(3):411-419.
[14]	Xia G D, Chai L, Wang H Y.Optimum thermal design of microchannel heat sink with triangular reentrant cavities[J].Applied Thermal Engineering, 2011, 31(6):1208-1219.
[15]	景思睿, 张鸣远.流体力学[M].西安:西安交通大学出版社, 2001.
[16]	Loosen P.Cooling and packaging of high-power diode lasers[J].High-Power Diode Lasers, 2000, 78:289-301.
