航空发动机中介轴承的故障特征与诊断方法
Fault characteristics and diagnosis method of intershaft bearing in aero-engine
-
摘要: 提出了转差域频谱和转差域包络谱的概念,建立了诊断航空发动机中介轴承故障的方法.利用发动机高、低压转差作为触发信号,对发动机振动信号进行等转差周期采集,并在转差域对振动信号进行频谱和包络谱分析.结果表明:不平衡响应、不对中响应以及外环静止的轴承故障响应等振动信号在转差域频谱和转差域包络谱上的位置随转速变化;而中介轴承的故障响应在转差域频谱上的边频成分间距不随转速变化,具有倍频“恒间距”特征;在转差域包络谱上的位置也不随转速变化,具有“恒频”特征.带外环故障的中介轴承实验表明:转速变化时,在转差域包络谱中,外环故障特征倍频成分位置不变;在转差域频谱中,出现间隔宽度恒定为外环故障特征倍频的频率成分.Abstract: Spectrum and envelope spectrum analysis of vibrations measured on aero-engines were developed in rotary-speed-difference-domain for detection of faults in inter-shaft bearings. Rotary-speed-difference of high pressure rotor and low pressure rotor is used as triggering signal. Vibration signals were sampled at the whole cycles of rotary-speed-difference,and their spectrum and envelope spectrum were analyzed in rotary-speed-difference-domain. The result shows that the position of vibration components caused by rotor imbalance, misalignment and defects in normal bearings(outer race fixed) will change in the horizontal coordinate(octave form in rotary-speed-difference-domain) when the rotary speed changes. However the side-band components in the vibration spectrum resulting from defects in inter-shaft bearings will keep constant space between any two components when the rotary speed changes. This phenomenon is referred to as "constant space " feature. Furthermore, vibration components in envelope spectrum caused by defects in inter-shaft bearings will keep constant location in the horizontal coordinate(octave form in rotary-speed-difference-domain) when the rotary speed changes. This phenomenon is referred to as "constant octave " feature. The experimental results obtained from the measurements on a test rig of inter-shaft bearing with defects in outer race show that the two features really present in the spectrum and envelope spectrum in in rotary-speed-difference-domain respectively.
-
[1] McFadden P D.Model for the vibration produced by a single point defect in a rolling element bearing[J].Journal of Sound and Vibration, 1984, 96(1):69-82. [2] McFadden P D.The vibration produced by multiple point defects in a rolling element bearing[J].Journal of Sound and Vibration, 1985, 98(2):263-273. [3] 沈庆根.化工机器故障诊断技术[M].浙江:浙江大学出版社.1994. [4] 雷剑宇, 廖明夫.滚动轴承局部故障的特征倍频诊断方法[J].测控技术, 2007, 26(9):72-75. LEI Jianyu, LIAO Mingfu.A new approach based on the defect characteristic octave frequncies to diagnose local defects in a rolling element bearing[J].Measurement and Control Technology, 2007, 26(9):72-75.(in Chinese) [5] 陈刚, 廖明夫.基于小波分析的滚动轴承故障诊断研究[J].科学技术与工程, 2007, 7(12):2810-2814. CHEN Gang, LIAO Mingfu.Fault diagnosis for a rolling element bearing based on wavelet analysis[J].Science Technology and Eengineering, 2007, 7(12):2810-2814.(in Chinese) [6] 王平, 廖明夫.滚动轴承故障诊断的自适应共振解调技术[J].航空动力学报, 2005, 20(4):606-612. WANG Ping, LIAO Mingfu.Adaptive demodulated resonance technique for the rolling bearing fault diagnosis[J].Journal of Aerospce Power, 2005, 20(4):606-612.(in Chinese) [7] 孟涛, 廖明夫.利用时延相关解调法诊断滚动轴承的故障[J].航空学报, 2004, 25(1):41-44. MENG Tao, LIAO Mingfu.Detection and diagnosis of the rollimg element bearing fault by the delayed correlation envelope technique[J].Acta Aeronautica et Astronautica Sinica, 2004, 25(1):41-44.(in Chinese) [8] Gasch R, Nordmann R, Pfuetzner H.Rotordynamik[M].Berlin:Springer, 2002. [9] 胡广书.数字信号处理:理论、算法与实现[M].北京:清华大学出版社, 1997. [10] 廖明夫, 马振国, 邓巍.某型航空发动机中介轴承外环故障振动分析[J].航空动力学报, 2011, 26(11):2422-2426. LIAO Mingfu, MA Zhenguo, DENG Wei.Vibration analysis on turbofan engine intershaft bearing with outer race defect[J].Journal of Aerospace and Power, 2011, 26(11):2422-2426.(in Chinese) [11] 邓巍, 廖明夫, 马振国.航空发动机中介轴承局部故障边带差值诊断法[J].机械科学与技术, 2012, 31(2):335-339. DENG Wei, LIAO Mingfu, MA Zhenguo.Sideband difference diagnostics of local defects for aero-engine intershaft bearing[J].Mechanical Science and Technology for Aerospace Engineering, 2012, 31(2):335-339.(in Chinese) [12] 雷剑宇.滚动轴承局部故障的振动分析与诊断.西安:西北工业大学, 2007. LEI Jianyu.Vibration analysis and diagnosis on the local fault of a rolling element bearing.Xi'an:Northwestern Polytechnical University, 2007.(in Chinese) [13] 屈梁生.机械故障诊断学[M].上海:上海科学技术出版社, 1986. [14] 孟涛.齿轮与滚动轴承故障的振动分析与诊断[D].西安:西北工业大学, 2003. MENG Tao.Vibration analysis and diagnosis on the fault of the gear and rolling element bearing[D].Xi'an:Northwestern Polytechnical University, 2003.(in Chinese) [15] Vance J M.Rotordynamics of turbomachinery[M].New York:Wiley, 1987.
