微波在液体火箭发动机真空羽流中的衰减

王虹玥; 唐振宇; 贺碧蛟; 蔡国飙

微波在液体火箭发动机真空羽流中的衰减

北京航空航天大学宇航学院, 北京 100191

计量
- 文章访问数: 1221
- HTML浏览量: 1
- PDF量: 925
- 被引次数: 0
出版历程
- 收稿日期: 2012-11-08
- 刊出日期: 2013-12-28

Microwave attenuation in vacuum plume of the liquid-propellant rocket engine

School of Astranautics, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 为研究液体火箭发动机真空羽流对微波的衰减作用，以某双组元液体火箭发动机为对象，使用热力计算程序对燃烧室内的电子数密度进行了计算，使用冻结假设和有限化学反应速率假设两种情况对喷管内带电粒子的电离和再结合过程进行了模拟，并对羽流中带电粒子数密度和5~30GHz微波穿过羽流的衰减量进行了估算.研究结果显示：该发动机燃烧室和喷管出口的电子数密度量级分别为 10¹³~10¹⁴cm^-3和10¹⁰~10¹¹cm^-3，K，Na等碱金属为主要电子释放剂，Cl^-，OH^-等基团为主要电子吸收剂；低频微波在羽流中衰减更严重，5GHz微波的衰减可达4.5dB；微波斜穿羽流的衰减通常大于横穿情况.
- 微波衰减 /
- 液体发动机 /
- 羽流 /
- 碱金属 /
- 电子数密度
Abstract: The microwave attenuation in the vacuum plume of the liquid-propellant rocket engine was studied. Based on a sample of the bipropellant engine, the electron number densities in the chamber was calculated using a thermodynamic calculation code. The ionization and recombination processes in the nozzle were simulated under the assumption of frozen components or limited reaction rate. The electron number densities in the plume and the microwave attenuation of 5－30GHz were estimated. It is shown that the number densities are within the range of 10¹³-10¹⁴cm^-3 and 10¹⁰-10¹¹cm^-3, respectively, for the chamber and the exit of the nozzle. The alkali metals, K and Na, are main contributors of electrons while Cl^- and OH^- are main electron absorber. The attenuation is more serious for the microwave of lower frequency and oblique path, as high as 4.5dB in case of 5 GHz.
- microwave attenuation /
- liquid-propellant engine /
- plume /
- alkali metal /
- electron number density

HTML

参考文献(15)

[1]	Smoot L D, Underwood D L, Schroeder R G.Prediction of microwave attenuation characteristics of rocket exhausts.AIAA 65-181, 1965.
[2]	Smoot L D, Underwood D L.Prediction of microwave attenuation characteristics of rocket exhausts[J].Journal of Spacecraft and Rockets, 1996, 3(3):302-309.
[3]	Hughes R C, Landrum D B.Computational investigation of electron production in solid rocket plumes.AIAA 93-2454, 1993.
[4]	Copper D A, Frederick R A.The measurement of electron density in a rocket motor plume.AIAA 93-2453, 1993.
[5]	Mikatarian R R, Pergament H S.Effects of altitude on radar attenuation in nonequilibrium afterburning rocket exhaust plumes[J].AIAA Journal, 1969, 7(1):159-161.
[6]	刘青云, 张平, 安冬梅.固体推进剂碱金属杂质及喷焰后燃效应的参数辨识研究[J].推进技术, 1999, 20(3):45-49, 77. LIU Qingyun, ZHANG Ping, AN Dongmei.Parameters identification of alkali metal impurities of solid propellant and properties of exhaust afterburning[J].Journal of Propulsion Technology, 1999, 20(3):45-49, 77.(in Chinese)
[7]	张平, 崔继嵩, 刘青云.二维火箭喷焰流场的化学组份和电磁特性计算[J].推进技术, 1993, 8(4):8-13. ZHANG Ping, CUI Jisong, LIU Qingyun.Two-dimensional calculation of chemical species and electrical properties in rocket exhaust plume flow fields[J].Journal of Propulsion Technology, 1993, 8(4):8-13.(in Chinese)
[8]	王华峰, 李疏芬.固体火箭发动机喷焰对微波的衰减[J].固体火箭技术, 1989, 13(4):1-12.
[9]	张硕, 魏志军, 王宁飞, 等.固体火箭发动机排气羽流对微波衰减的计算方法[J].航空动力学报, 2009, 24(3):705-710. ZHANG Shuo, WEI Zhijun, WANG Ningfei, et al.Calculation method of microwave attenuation by exhaust plume of solid rocket motors[J].Journal of Aerospace Power, 2009, 24(3):705-710.(in Chinese)
[10]	张硕, 王宁飞, 张平, 等.固体火箭发动机排气羽流对红外制导信号衰减的计算方法[J].固体火箭技术, 2007, 30(5):408-411. ZHANG Shuo, WANG Ningfei, ZHANG Ping, et al.Calculation method on infrared signal attenuation caused by exhaust plume of solid rocket motor[J].Journal of Solid Rocket Technology, 2007, 30(5):408-411.(in Chinese)
[11]	石雁祥, 王菊, 葛德彪, 等.火箭喷焰微波衰减特征的理论研究[J].固体火箭技术, 2008, 31(4):421-424. SHI Yanxiang, WANG Ju, GE Debiao, et al.Theoretical study on attenuation characteristics of microwave in rocket exhaust plume[J].Journal of Solid Rocket Technology, 2008, 31(4):421-424.(in Chinese)
[12]	李宜敏, 张中钦, 张远君.固体火箭发动机原理[M].北京:北京航空航天大学出版社, 1991.
[13]	Bird G A.Molecular gas dynamics and the direct simulation of gas flow[M].New York:Oxford University Press Inc, 1994.
[14]	Russo A J.Estimates of attenuation and reflection of telemetering signals by ionized flow fields surrounding typical reentry bodies.Washington DC:Langley Research Center, National Aeronautics and Space Administration, NASA Technical Note D-1778, 1963.
[15]	曹晔, 徐蕴芝, 李志鲲, 等.原子吸收光谱法测定无水肼中杂质金属钠[J].航天发射技术, 2003, 4(2):42-44.
