跨声速压气机转子叶尖流场旋转不稳定现象的数值研究

付磊 袁巍 宋西镇 周盛 陆利蓬

付磊, 袁巍, 宋西镇, 周盛, 陆利蓬. 跨声速压气机转子叶尖流场旋转不稳定现象的数值研究[J]. 航空动力学报, 2014, (5): 1145-1153.
引用本文: 付磊, 袁巍, 宋西镇, 周盛, 陆利蓬. 跨声速压气机转子叶尖流场旋转不稳定现象的数值研究[J]. 航空动力学报, 2014, (5): 1145-1153.
FU Lei, YUAN Wei, SONG Xi-zhen, ZHOU Sheng, LU Li-peng. Numerical investigation on rotating instability phenomenon in tip flow field of transonic compressor rotor[J]. Journal of Aerospace Power, 2014, (5): 1145-1153.
Citation: FU Lei, YUAN Wei, SONG Xi-zhen, ZHOU Sheng, LU Li-peng. Numerical investigation on rotating instability phenomenon in tip flow field of transonic compressor rotor[J]. Journal of Aerospace Power, 2014, (5): 1145-1153.

跨声速压气机转子叶尖流场旋转不稳定现象的数值研究

基金项目:

国家自然科学基金(50906001)

详细信息
    作者简介:

    付磊(1984- ),男,河北安平人,博士生,主要从事叶轮机械气动热力学研究.

    通讯作者:

    宋西镇(1977- ),男,陕西宝鸡人,讲师,博士,主要从事叶轮机械气动力学等研究.

  • 中图分类号: V231.3

Numerical investigation on rotating instability phenomenon in tip flow field of transonic compressor rotor

  • 摘要: 对某跨声速压气机转子在不同工作流量下的叶尖非定常流场进行了数值研究.结果显示:大流量状态下,该转子叶尖流场几乎不发生振荡.此时,叶尖流场可以按定常流场进行分析;小流量状态下,叶尖泄漏涡大幅振荡,相邻叶片通道内的叶尖泄漏流之间也存在周期性相互干涉.其结果是在稳定状态时出现由于叶尖泄漏涡的振荡及其周向传播造成的“旋转不稳定”现象.“旋转不稳定”流场结构主模态旋涡个数大约为40%的叶片通道个数;其周向尺度占据2~3个栅距.



  • [1] Mailach R, Lehmann I, Vogeler K.Rotating instabilities in an axial compressor originating from the fluctuating blade tip vortex[J].Journal of Turbomachinery, 2001, 123(3):453-460.
    [2] Mailach R, Sauer H, Vogeler K.The periodical interaction of the tip clearance flow in the blade rows of axial compressors[R].ASME Paper 2001-GT-0299, 2001.
    [3] Marz J, Hah C, Neise W.An experimental and numerical investigation into the mechanisms of rotating instability[J].Journal of Turbomachinery, 2002, 124(3):367-374.
    [4] Inoue M, Kuroumaru M, Yoshida S, et al.Effect of tip clearance on stall evolution process in a low-speed axial compressor stage[R].ASME Paper 2004-GT-53354, 2004.
    [5] Nishioka T, Kuroda S, Nagano T, et al.Influence of rotating instability on stall inception patterns in a variable-pitch axial-flow fan[R].ASME Paper 2006-GT-90589, 2006.
    [6] Nishioka T, Kanno T, Hayami H.Characteristics of end-wall flow at spike and modal stall inceptions in a variable-pitch axial-flow fan[R].ASME Paper 2007-GT-27738, 2007.
    [7] Nishioka T, Kanno T, Hayami H.Rotating stall inception from spike and rotating instability in a variable-pitch axial-flow fan[R].ASME Paper 2008-GT-51466, 2008.
    [8] Nishioka T, Kanno T, Hiradate K.Rotor-tip flow fields near inception point of rotating instability in an axial-flow fan[R].ASME Paper 2011-GT-45338, 2011.
    [9] Biela C, Mulier M W, Schiffer H, et al.Unsteady pressure measurement in a single stage axial transonic compressor near the stability limit[R].ASME Paper 2008-GT-50245, 2008.
    [10] Hah C, Bergner J, Schiffer H.Tip clearance vortex oscillation, vortex shedding and rotating instabilities in an axial transonic compressor rotor[R].ASME Paper 2008-GT-50105, 2008.
    [11] Hah C, Voges M, Mueller M, et al.Characteristics of tip clearance flow instability in a transonic compressor[R].ASME Paper 2010-GT-22101, 2010.
    [12] Hah C.Near stall flow analysis in the transonic fan of the RTA propulsion system[R].AIAA-2010-277, 2010.
    [13] Tong Z, Lin F, Chen J, et al.The self-induced unsteadiness of tip leakage vortex and its effect on compressor stall inception[R].ASME Paper 2007-GT-27010, 2007.
    [14] Du J, Lin F, Zhang H, et al.Numerical investigation on the self-induced unsteadiness in tip leakage flow for a transonic fan rotor[J].Journal of Turbomachinery, 2010, 132(2):021017.1-021017.9.
    [15] 脱伟.处理机匣对跨声速压气机全叶展流场影响的机理探索[D].北京:北京航空航天大学, 2009. TUO Wei.Investigation of the influence of casing treatment on whole span flow field in a transonic compressor[D].Beijing:Beijing University of Aeronautics and Astronautics, 2009.(in Chinese)
    [16] 袁巍.处理机匣的几何结构对压气特性的影响研究[D].北京:北京航空航天大学, 2003. YUAN Wei.The research on the influence of casing treatment geometry on compressor characteristic[D].Beijing:Beijing University of Aeronautics and Astronautics, 2003.(in Chinese)
