出口轮毂形状对大型轴流风机性能影响的数值研究

尹超; 胡骏; 屠宝锋; 严伟; 张晨凯

出口轮毂形状对大型轴流风机性能影响的数值研究

南京航空航天大学能源与动力学院江苏省航空动力系统重点实验室, 南京 210016

基金项目:

高等学校博士学科点专项科研基金（20113218120006）

详细信息

作者简介:
尹超（1987- ），男，江苏扬州人，博士生，主要从事叶轮机械气动热力学研究.

中图分类号: V211.4
计量
- 文章访问数: 1201
- HTML浏览量: 4
- PDF量: 849
- 被引次数: 0
出版历程
- 收稿日期: 2013-03-14
- 刊出日期: 2014-05-28

Numerical investigation of effect of outlet hub geometry on performance of large scale axial fan

Jiangsu Province Key Laboratory of Aerospace Power System, College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 针对某大型轴流风机设计了4种出口段轮毂匹配方案，采用数值模拟方法对比分析了4种方案下的风机特性和叶尖以及叶根流场结构.结果表明：出口轮毂形状的变化对该风机叶尖流场结构影响很小；该风机出口无轮毂时，在叶根区域出现约占20%叶高区域的分离流，损失严重，降低了工作效率；在相同的叶尖间隙下，风机效率随着出口轮毂扩压角的减小而提高；在风机出口增加一个匹配的平直轮毂或收缩轮毂可使叶根分离涡后移，分离区域减小至5%叶高以下，同时可使该风机效率至少提高2个百分点.
- 大型轴流风机 /
- 全压效率 /
- 出口轮毂形状 /
- 结构匹配 /
- 叶根分离涡
Abstract: Four different outlet hub geometries of a large scale axial fan were designed and investigated. CFD methods were used to compare the fan characteristics and analyze the flow field structures in the blade tip and blade root. The results show that variation of outlet hub geometry has little effect on the fan's tip flow structure; there is a large separated flow in the blade root region which occupies 20% of blade height when the fan isn't provided with outlet hub, causing serious loss and decrease of efficiency; with the same blade tip clearance, the fan's efficiency increases when the outlet hub diffuser angle decreases; a matching straight or convergent hub could make the blade root separated vortex move backwards, reduce the separated area to 5% of blade height and increase at least 2 percentage points of the fan efficiency.
- large scale axial fan /
- total pressure efficiency /
- outlet hub geometry /
- structure matching /
- blade root separated vortex
