贫油直喷三喷嘴模型燃烧室燃烧性能

曾青华; 孔文俊; 艾育华; 王宝瑞

doi:10.13224/j.cnki.jasp.2014.06.006

贫油直喷三喷嘴模型燃烧室燃烧性能

doi: 10.13224/j.cnki.jasp.2014.06.006

中国科学院工程热物理研究所轻型动力重点实验室, 北京 100190

基金项目:

国家自然科学基金（50936005）；国家高技术研究发展计划（2007AA050501）

详细信息

作者简介:
曾青华（1982- ），男，湖南常宁人，助理研究员，博士，主要从事发动机燃烧学研究.

中图分类号: V231.2
计量
- 文章访问数: 1698
- HTML浏览量: 80
- PDF量: 1064
- 被引次数: 0
出版历程
- 收稿日期: 2013-10-21
- 刊出日期: 2014-06-28

Combustion performances of lean direct injection model combustor with three injectors

Key Laboratory of Light-duty Gas-turbine, Institute of Engineering Thermophysics, Chinese Academy of Sciences, Beijing 100190, China

摘要

摘要: 构建了反向双旋文氏管预混（CDV）三喷嘴矩形模型燃烧室，研究了其燃烧特征及性能.结果表明：火焰近乎全蓝色，类似气体的贫预混燃烧，且在此工况下，CO和NOx换算成15%含氧量（体积分数）下排放的体积分数分别低于10×10^-6和50×10^-6.此外，研究了进气温度变化对CDV三喷嘴污染物排放的影响，发现CO排放相对NOx更易受到进气温度变化的影响，并分析揭示了产生该现象的原因.另外雾化器的性能极易影响贫油直喷火焰特征；需要改进雾化器的加工工艺以确保在预热工况下它能够保持持续稳定的良好雾化性能.
- 贫油直喷 /
- 燃烧室 /
- 燃烧性能 /
- 蓝色火焰 /
- 低排放
Abstract: A rectangular model combustor with three counter dual-swirl Venturi-premix (CDV) injectors was designed and its combustion characteristics and performances were also investigated. The results showed that, the combustion flames were blue, which were very similar to those of lean premixed gaseous combustion. And in the above-mentioned working condition, CO and NOx emission volume fraction converted to 15 percent oxygen were less than 10×10^-6 and 50×10^-6 respectively. In addition, the effect of inlet air temperature change on pollutant emissions of these three CDV injectors was also investigated. It was found that the CO emission concentration was more affected by the change of inlet air temperatures than that of NOx. And the reason about above-specified phenomenon was analyzed and revealed. Moreover, the study showed that, atomizer's performances greatly influenced the characteristics of lean direct injection combustion flames. Processing technology of the fuel atomizers should be improved to ensure long-term stability of their atomization performances.
- lean direct injection /
- combustor /
- combustion performance /
- blue flame /
- low emissions

HTML

参考文献(23)

[1]	Tacina R R.Low NOx potential of gas turbine engines.AIAA 90-0550,1990.
[2]	Tacina R,Wey C,Laing P,et al.A low NOx lean-direct injection,multipoint integrated module combustor concept for advanced aircraft gas turbines.NASA/TM-2002-211347,2002.
[3]	Patel N,Menon S.Simulation of spray-turbulence-flame interactions in a lean direct injection combustor[J].Combustion and Flame,2008,153(1/2):228-257.
[4]	林宇震,许全宏,刘高恩.燃气轮机燃烧室[M].北京:国防工业出版社,2008:232-234.
[5]	Yang S L,Siow Y K,Peschke B D,et al.Numerical study of nonreacting gas turbine combustor swirl flow using Reynolds stress model[J].Journal of Engineering for Gas Turbines and Power,2003,125(3):804-811.
[6]	Dewanji D,Rao A G,Pourquie M,et al.Investigation of flow characteristics in lean direct injection combustors[J].Journal of Propulsion and Power,2012,28(1):181-196.
[7]	Fu Y,Jeng S M,Tacina R.Confinement effects on the swirling flow generated by a helical axial swirler[J].AIAA-2006-545,2006.
[8]	Tacina R,Mansour A,Partelow L,et al.Experimental sector and flame-tube evaluations of a multipoint integrated module concept for low emission combustors.ASME Paper GT2004-53263,2004.
[9]	Tacina K M,Lee C M,Wey C.NASA Glenn high pressure low NOx emissions research.NASA/TM-2008-214974,2008.
[10]	Patel N,Kirtas M,Sankaran V,et al.Simulation of spray combustion in a lean-direct injection combustor[J].Proceedings of the Combustion Institute,2007,31(2):2327-2334.
[11]	Iannetti A C,Liu N S.The effect of spray initial conditions on heat release and emissions in LDI CFD calculations[J].AIAA-2008-1150,2008.
[12]	Fu Y,Jeng S M,Tacina R.Characteristics of the swirling flow in a multipoint LDI combustor[J].AIAA-2007-846,2007.
[13]	Yang S L,Siow Y K,Teo C Y,et al.Numerical study of lean-direct injection combustor with discrete-jet swirlers using Reynolds stress model[J].Journal of Engineering for Gas Turbines and Power,2003,125(4):1059-1065.
[14]	邓甜,王方,黄勇.多点喷射燃烧室冷态流场特性研究[J].工程热物理学报,2008,29(5):876-880. DENG Tian,WANG Fang,HUANG Yong.Investigation of the cold flow field of a multi-injection combustor[J].Journal of Engineering Thermophysics,2008,29(5):876-880.(in Chinese)
[15]	张群,徐华胜,钟华贵,等.多旋流器阵列贫油直喷燃烧室流场的数值模拟[J].航空动力学报,2009,24(3):483-487. ZHANG Qun,XU Huasheng,ZHONG Huagui,et al.Numerical simulation of flow field in a multi-swirler array lean direct injection combustor[J].Journal of Aerospace Power,2009,24(3):483-487.(in Chinese)
[16]	张群,徐华胜,钟华贵,等.反旋向多旋流器阵列燃烧室流场的数值研究[J].西北工业大学学报,2009,27(3):305-309. ZHANG Qun,XU Huasheng,ZHONG Huagui,et al.A numerical study of the flow field of a combustor with a couter-rotating multi-swirler array[J].Journal of Northwestern Polytechnical University,2009,27(3):305-309.(in Chinese)
[17]	吴垚锃,黄勇,王方,等.不同结构多点喷射燃烧室冷态流场研究[J].航空动力学报,2010,25(7):1536-1544. WU Yaozeng,HUANG Yong,WANG Fang,et al.Investigation of cold flow field of a multi-injection combustor with different geometries[J].Journal of Aerospace Power,2010,25(7):1536-1544.(in Chinese)
[18]	张振奎,钟华贵.多点喷射模型燃烧室性能CFD分析[J].航空发动机,2010,36(4):16-21. ZHANG Zhenkui,ZHONG Huagui.CFD analysis of performance for the model multipoint injection combustor[J].Aeroengine,2010,36(4):16-21.(in Chinese)
[19]	Archer S,Gupta A K.Effect of swirl and combustion on flow dynamics in lean direct injection gas turbine combustion[J].AIAA-2003-1343,2003.
[20]	Archer S,Gupta A K.Confinement effects on flow dynamics in swirling flames.ASME Power,PWR2005-50167,2005.
[21]	Archer S,Gupta A K.Flow dynamics of under confined and unconfined combustion conditions.ASME Design Engineering Technical Conferences,DETC2004-57732,2004.
[22]	Zeng Q,Kong W,Sui C.Effect of confinement on combustion characteristics in lean direct injection combustion system.ASME Paper GT2013-95413,2013.
[23]	胡正义.航空发动机设计手册:第9册主燃烧室[M].北京:航空工业出版社,2000.
