主燃孔射流对模型燃烧室流动及燃烧影响的数值研究

徐榕; 赵坚行; 王锁芳

doi:10.13224/j.cnki.jasp.2014.06.008

主燃孔射流对模型燃烧室流动及燃烧影响的数值研究

doi: 10.13224/j.cnki.jasp.2014.06.008

南京航空航天大学能源与动力学院江苏省航空动力系统重点实验室, 南京 210016

详细信息

作者简介:
徐榕（1982- ），男，江苏苏州人，博士生，主要研究方向为燃烧试验与数值仿真.

中图分类号: V231.1
计量
- 文章访问数: 1403
- HTML浏览量: 2
- PDF量: 1052
- 被引次数: 0
出版历程
- 收稿日期: 2013-04-07
- 刊出日期: 2014-06-28

Numerical study of influences of primary jets on turbulent flows and spray combustion in model combustor

Jiangsu Province Key Laboratory of Aerospace Power System, College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 数值研究不同主燃孔射流对模型燃烧室内湍流流动与液雾燃烧全流程流场的影响，采用微分方程和分区相结合方法生成包括突扩扩压器、帽罩、双级轴向旋流器、火焰筒及内外环通道的模型燃烧室三维结构化网格；在任意曲线坐标系下采用多区域耦合法计算模型燃烧室的流场.采用RNG（re-normalization group）k-ε湍流模型，旋涡破碎湍流燃烧模型模拟湍流燃烧过程；颗粒轨道模型模拟两相流动.计算结果与试验数据的比较表明：本计算方法与数学模型适用于预测模型燃烧室湍流冷、热态流场；主燃孔结构参数变化对气流温度分布的影响比对回流区尺寸与速度分布的影响更为明显，其中主燃孔Ⅱ的出口温度分布要比其他主燃孔的出口温度分布更为合理.
- 双级轴向旋流器 /
- 湍流流动 /
- 主燃孔射流 /
- 燃烧数值模拟 /
- 液雾燃烧
Abstract: The influences of different primary jets on turbulent flows and spray combustion of a dual swirl model combustor were numerically studied. The three-dimensional block-structured grids were generated by the differential equation method and sub-regional method for a model combustor including a dump diffuser, cowl, dual-stage axial swirler, flame tube as well as outer and inner annuluses. In arbitrary curvilinear coordinates, a multi-zone coupling approach was used for model combustor flow field numerical investigation. RNG (re-normalization group) k-ε model and EBU (eddy break-up) turbulent combustion model were employed for turbulent combustion. The particle trajectory model was applied to simulating two-phase flows. Comparisons between predicted and experimental data show that simulation is appropriate for predicting turbulent cold and combustion flow field. The influences of different primary hole structure parameters on gas temperature distributions are more obvious than the size of recirculation zone and profiles of velocity, and profile of exit temperature of the primary hole Ⅱ is more rational than those of other primary holes.
- dual-stage axial swirler /
- turbulent flow /
- primary jet /
- combustion numerical simulation /
- spray combustion

HTML

参考文献(18)

[1]	Richards C D,Smuelsen G S.The role of primary jets in the dome region aerodynamics of a model can combustor[J].Journal of Engineering for Gas Turbines and Power,1992,114(1):20-26.
[2]	EIkady A M.The influence of primary air jets on flow and pollutant emissions characteristics within a model gas turbine combustor.AIAA 2006-544,2006.
[3]	Richards C D,Smuelsen G S.The interaction of primary jets with a swirl-induced recirculation zone.AIAA 90-0455,1990.
[4]	Mongia H C.Engineering aspects of complex gas turbine combustion mixers:Part Ⅵ swirl cup.AIAA 2011-5526,2011.
[5]	Mohammad B,Jeng S M,Andac M G.Influence of the primary jets and fuel injection on the aerodynamics of a prototype annular gas turbine combustor sector[J].Journal of Engineering for Gas Turbines and Power,2011,133(1):011505.1-011505.8.
[6]	党新宪,赵坚行,吉洪湖.试验研究双旋流器头部燃烧室几何参数对燃烧性能的影响[J].航空动力学报,2007,22(10):1639-1645. DANG Xinxian,ZHAO Jianxing,JI Honghu.Experimental study of effects of geometric parameters on combustion performance of dual-stage swirler combustor[J].Journal of Aerospace Power,2007,22(10):1639-1645.(in Chinese)
[7]	党新宪,赵坚行,吉洪湖.双旋流器燃烧室NOx生成研究[J].航空动力学报,2008,23(3):430-435. DANG Xinxian,ZHAO Jianxing,JI Honghu.A study on NOx formation for double swirler combustor[J].Journal of Aerospace Power,2008,23(3):430-435.(in Chinese)
[8]	党新宪,赵坚行,颜应文.试验研究主燃孔对模型燃烧室流场的影响[J].推进技术,2010,31(1):24-28. DANG Xinxian,ZHAO Jianxing,YAN Yingwen.Experimental investigation on effects of swirl number on aerodynamic characteristics of combustor[J].Journal of Propulsion Technology,2010,31(1):24-28.(in Chinese)
[9]	Giridharan M G,Mongia H C,Jeng S M.Swirl cup modeling:Part Ⅲ spray combustion in CFM-56 single cup flame tube.AIAA 2003-0319,2003.
[10]	赵坚行,伍艳玲,周琳.先进燃烧室涡流杯流场计算[J].工程热物理学报,2000,21(1):110-114. ZHAO Jianxing,WU Yanling,ZHOU Lin.Numerical computation of turbulent flow-field characteristics inside an advanced combustor swirl cup[J].Journal of Engineering Thermophysics,2000,21(1):110-114.(in Chinese)
[11]	Turner M G Ryder R,Norris A.High fidelity 3D turbofan engine simulation with emphasis on turbomachinery-combustor coupling.AIAA 2002-769,2002.
[12]	Turner M G,Norris A,Veres J P.High fidelity three-dimensional simulation of the GE90.NASA/TM 2004-212981,2004.
[13]	Speziale C G,Thangam S.Analysis of an RNG based turbulence model for separated flows[J].International Journal of Engineering Science,1992,30(10):1379-1388.
[14]	徐榕,赵坚行,党新宪,等.旋流杯燃烧室流场的数值与试验研究[J].工程热物理学报,2010,31(4):701-704. XU Rong,ZHAO Jianxing,DANG Xinxian,et al.Numerical and experimental study of flow fields in a swirl cup gas turbine combustor[J].Journal of Engineering Thermophysics,2010,31(4):701-704.(in Chinese)
[15]	Liu J,Shang H M,Chen Y S.Prediction of radiative transfer in general body-fitted coordinates.AIAA 97-0811,1997.
[16]	赵坚行.燃烧的数值模拟[M].北京:科学出版社,2002.
[17]	Kenworthy M J,Burrus D L.Internal flow field calculations for annular combustor configurations.AIAA 84-1168,1984.
[18]	Gosman A D,Loannides E.Aspects of computer simulation of liquid-fueled combustors.AIAA 81-0323,1981.
