超临界喷射受环境和喷射参数影响的数值研究

靳乐; 范玮; 范珍涔; 周舟

doi:10.13224/j.cnki.jasp.2014.06.009

超临界喷射受环境和喷射参数影响的数值研究

doi: 10.13224/j.cnki.jasp.2014.06.009

西北工业大学动力与能源学院, 西安 710072

基金项目:

国家自然科学基金（51176158，51376151）；教育部博士点基金（20126102110029）；西北工业大学博士论文创新基金（CX201314）

详细信息

作者简介:
靳乐（1987- ），男，河北石家庄人，博士生，主要从事航空发动机燃烧与流动方向相关研究.

中图分类号: V231.2
计量
- 文章访问数: 2012
- HTML浏览量: 125
- PDF量: 980
- 被引次数: 0
出版历程
- 收稿日期: 2013-10-21
- 刊出日期: 2014-06-28

Numerical investigation on effects of ambient and injection parameters on supercritical injection

School of Power and Energy, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 基于PR（Peng-Robinson）状态方程，采用二维轴对称的两相流控制方程和相关文献中的混合规则，建立了超临界燃油喷射的数值模型并采用预处理方法进行求解.以正癸烷为替代燃料研究了超临界燃油喷射到静止超临界氮气环境中时射流长度和射流扩张角的变化规律.结果表明：超临界射流长度和射流扩张角随环境压力的升高而减小，随环境温度和喷射温度的升高而增加，且超临界射流长度受环境和喷射参数影响的敏感性稍高于射流扩张角.分析认为影响超临界喷射的两个主要因素是喷射密度比和喷射动量，且后者占主导地位.
- 超临界 /
- 物性 /
- 数值模拟 /
- 射流长度 /
- 射流扩张角
Abstract: Based on the PR(Peng-Robinson) equation of state, two-dimensional axisymmetric governing equation of two-phase flow was introduced to establish a numerical model of supercritical injection by employing the mixing rule described in relevant references. And preconditioning method was used for solving, while n-decane was used as an alternative of liquid hydrocarbon fuel to investigate the supercritical injection characteristics in a quiescent supercritical nitrogen chamber. The jet length and jet spreading angle affected by ambient and injection parameters were separately analyzed. This demonstrates that jet length and jet spreading angle decrease with the increasing ambient pressure, but increase with the increasing ambient and injection temperature. The sensitivity of supercritical jet length affected by ambient and injection parameters is higher than jet spreading angle. It is deemed that the injection density ratio and injection momentum are two main influential factors to the supercritical injection, and the injection momentum is considered to be the dominant factor.
- supercritical /
- physical property /
- numerical simulation /
- jet length /
- jet spreading angle

HTML

参考文献(18)

[1]	Yang V.Modeling of supercritical vaporization,mixing,and combustion processes in liquid-fueled propulsion systems[J].Proceedings of Combustion Institute,2000,28(1):925-942.
[2]	Holland M,Eaton E,Hanley H.A correlation of the viscosity and thermal conductivity data of gaseous and liquid ethylene[J].Journal of Physical and Chemical Reference Date,1983,12(4):917-932.
[3]	Newman J,Brzustowski T.Behavior of a liquid jet near the thermodynamic critical region[J].AIAA Journal,1971,9(8):1595-1602.
[4]	Mayer W,Schik A,Vielle B,at al.Atomization and breakup of cryogenic propellants under high-pressure subcritical and supercritical conditions[J].Journal of Propulsion and Power,1998,14(5):835-842.
[5]	Oscbwald M,Schik A.Supercritical nitrogen free jet investigation by spontaneous Raman scattering[J].Experiments in Fluids,1999,27(6):497-506.
[6]	Chehroudi B,Talley D,Coy E.Visual characteristics and initial growth rates of round cryogenic jets at subcritical and supercritical pressures[J].Physical Fluids,2002,14(2):850-861.
[7]	Oschwald M,Micci M.Spreading angle and centerline variation of density of supercritical nitrogen jets[J].Atomization and Sprays,2002,12(1/2/3):91-106.
[8]	Zong N,Meng H,Hsieh S,at al.A numerical study of cryogenic fluid injection and mixing under supercritical conditions[J].Physics of Fluids,2004,16(12):4248-4261.
[9]	Chehroudi B,Cohn R D T.Cryogenic shear layers:experiments and phenomenological modeling of the initial growth rate under subcritical and supercritical conditions[J].International Journal of Heat and Fluid Flow,2002,23(5):554-563.
[10]	Zong N,Yang V.Dynamics of simplex swirl injectors for cryogenic propellants at supercritical conditions.AIAA-2004-1332,2004.
[11]	Doungthip T E J,Williams T,Bento J.Studies of injection of jet fuel at supercritical conditions[J].Industrical and Engineering Chemistry Research,2002,41(23):5856-5866.
[12]	Minotti A,Bruno C.Comparison between real and ideal sub and supercritical combustion simulations of LO₂-CH₄ LRE flames at 15MPa.AIAA-2008-951,2008.
[13]	Peng D,Robinson D.A new two-constant equation of state[J].Industrial and Engineering Chemistry Fudamentals,1976,15(1):59-64.
[14]	Reid R,John M,Bruce E.The prosperities of gases and liquids[M].Singapore:McGraw Hill International Editions,1989.
[15]	Chung T A M,Lee K.Generalized multiparameter corresponding state correlation for polyatomic,polar fluid transport prosperities[J].Industrial and Engineering Chemistry Research,1988,27(4):671-679.
[16]	Edwards T,Maurice L Q.Surrogate mixtures to represent complex aviation and rocket fuels[J].Journal of Propulsion and Power,2001,17(2):461-466.
[17]	范珍涔,范玮.流动参数对超临界喷射特性影响的数值模拟[J].航空学报,2013,34(5):1018-1027. FAN Zhencen,FAN Wei.Numerical simulation on effects of flow parameters on supercritical injection characteristics[J].Acta Aeronautica et Astronautica Sinica,2013,34(5):1018-1027.(in Chinese)
[18]	Chehroudi B,Cohn R,Talley D.Spray/gas behavior of cryogenic fluids under sub and supercritical conditions.Pasadena,America:Proceedings of the Eighth International Conference on Liquid Atomization and Spray System,2000.
