高压涡轮工作叶片缘板阻尼结构设计分析

吴向宇; 韩绪军; 张海洋; 王婧; 栾旭

doi:10.13224/j.cnki.jasp.2014.06.017

高压涡轮工作叶片缘板阻尼结构设计分析

doi: 10.13224/j.cnki.jasp.2014.06.017

1. 北京航空航天大学能源与动力工程学院, 北京 100191;
2. 中国航空工业集团公司沈阳发动机设计研究所, 沈阳 110015

详细信息

作者简介:
吴向宇（1969- ），女，陕西咸阳人，研究员，博士生，主要从事涡轮气冷叶片设计工作.

中图分类号: V231.92
计量
- 文章访问数: 1436
- HTML浏览量: 3
- PDF量: 851
- 被引次数: 0
出版历程
- 收稿日期: 2014-04-02
- 刊出日期: 2014-06-28

Analysis and design of platform damper construction for high pressure turbine blade

1. School of Energy and Power Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China;
2. Shenyang Engine Design and Research Institute, Aviation Industry Corporation of China, Shenyang 110015, China

摘要

摘要: 对某高压涡轮工作叶片缘板阻尼结构进行了阻尼效果计算及试验分析，试验结果表明：随着正压力的增加，阻尼比基本呈现为先增加后降低，然后在一定范围内波动的规律，阻尼比峰值出现在100~280N之间.计算得到一弯共振下的正压力为123~158N，与阻尼效果试验基本一致.分类比较了常用缘板阻尼结构形式的优缺点，改进完善后的阻尼片结构质量增加约30%，在激振力占气动力百分比分别为1%，3%及5%时，振动响应减幅分别为31%，21%及16%.
- 高压涡轮工作叶片 /
- 缘板阻尼 /
- 阻尼效果 /
- 正压力 /
- 振动响应
Abstract: Analyzed the damping effect of a real engine's platform damper structure of high pressure turbine blade (HPTB) through calculation and experiment, experimental results show that with the increase of positive pressure, damping ratio increase at first, then reduce, and then fluctuate within a certain range, peak of the damping ratio occurs between 100-280N. Calculated positive pressure under the condition of first order bending resonance is 123-158N, damping effect consist with experimental results. Classified the platform damper structures commonly used and compared their advantages and disadvantages.Improved the damper mass about 30% by increased thickness of the damping sheet, when excitation force is 1%, 3% and 5% mass of aerodynamic force, a reduction of vibration response is 31%, 21% and 16%.
- high pressure turbine blade /
- platform damper /
- damping effect /
- positive pressure /
- vibration response

HTML

参考文献(16)

[1]	李其汉,王延荣,王建军.航空发动机叶片高循环疲劳失效研究[J].航空发动机,2003,29(4):16-18. LI Qihan,WANG Yanrong,WANG Jianjun.Investigation of high cycle fatigue failures for the aero engine blades[J].Aeroengine,2003,29(4):16-18.(in Chinese)
[2]	郝燕平,单颖春,朱梓根.缘板摩擦阻尼器的减振实验研究[J].航空动力学报,2001,16(1):55-58. HAO Yanping,SHAN Yingchun,ZHU Zigen.Effects of platform friction damper on resonant stress in gas turbine blades[J].Journal of Aerospace Power,2001,16(1):55-58.(in Chinese)
[3]	单颖春,郝燕平,朱梓根,等.干摩擦阻尼块在叶片减振方面的应用与发展[J].航空动力学报,2001,16(3):218-223. SHAN Yingchun,HAO Yanping,ZHU Zigen,et al.Application and development of platform friction damper for depressing resonant vibration of blades[J].Journal of Aerospace Power,2001,16(3):218-223.(in Chinese)
[4]	郝燕平.带摩擦阻尼叶片的动力响应和减振研究.北京:北京航空航天大学,2001.
[5]	郝燕平,朱梓根.带摩擦阻尼的叶片响应求解方法[J].航空学报,2001,22(5):411-414. HAO Yanping,ZHU Zigen,New method to resolve vibratory response of blades with friction damping[J].Acta Aeronautica et Astronautica Sinica,2001,22(5):411-414.(in Chinese)
[6]	漆文凯.涡轮转子叶片叶根阻尼装置减振特性分析及实验研究.南京:南京航空航天大学,2005. QI Wenkai.Research on analysis and experiment of turbine blade vibration characteristics with platform damper.Nanjing:Nanjing University of Aeronautics Astronautics,2005.(in Chinese)
[7]	漆文凯,高德平.带摩擦阻尼装置系统振动响应分析方法研究[J].航空动力学报,2006,21(1):161-167. QI Wenkai,GAO Deping.Study of vibration response analysis method for the dry friction damping systems[J].Journal of Aerospace Power,2006,21(1):161-167.(in Chinese)
[8]	古远兴,龚梦贤,曹磊,等.叶片缘板阻尼器设计分析中的一些问题[J].燃气涡轮实验与研究,2000,13(4):31-37.
[9]	Panning L,Sextro W,Popp K.Optimization of interblade friction damper design.ASME Paper GT2000-541,2000.
[10]	Panning L,Szwedowicz J,Gilbert C,et al.Numerical and experimental damping assessment of an thin-walled friction damper in the rotating set-up with high pressure turbine blades.ASME Paper GT2006-90951,2006.
[11]	Griffin J H,Sifford P P,Somner T P,et al.Blade damper:United States,4355957.1982-10-26.
[12]	Lillibridge H J,Schwarzmann R A.Blade to blade vibration damper:United States,4455122.1984-06-19.
[13]	Bourguignon S P L,Choque R R,Pham L P.Device for damping vibrations of mobile turbine blades:United States,4480959.1984-11-06.
[14]	Corsmeier R J,Dietz P W,Steckle C E.Turbine blade damper:United States,5369882.1994-12-06.
[15]	Burge J C,El-Aini Y M,Meece C E.Turbine engine rotor blade vibration damping device:United States,5498137.1996-03-12.
[16]	斯奈克玛.用于涡轮机叶片的阻尼器:中国,200810095076.1.2008-10-29.
