施加轴向力的旋转轮盘低循环疲劳试验

刘大成; 黄福增; 刘闯; 霍成民; 刘海

doi:10.13224/j.cnki.jasp.2014.06.019

施加轴向力的旋转轮盘低循环疲劳试验

doi: 10.13224/j.cnki.jasp.2014.06.019

中国航空工业集团公司沈阳发动机设计研究所, 沈阳 110015

详细信息

作者简介:
刘大成（1984- ），男，辽宁沈阳人，工程师，硕士，主要从事航空发动机转子强度寿命试验研究工作.

中图分类号: V231.95;V232.3
计量
- 文章访问数: 2243
- HTML浏览量: 145
- PDF量: 948
- 被引次数: 0
出版历程
- 收稿日期: 2013-12-05
- 刊出日期: 2014-06-28

Low cycle fatigue test of rotating disc under axial loading

Shenyang Engine Design and Research Institute, Aviation Industry Corporation of China, Shenyang 110015, China

摘要

摘要: 为满足配装某型飞机的发动机在外场使用的需要，利用传统安全寿命法对航空发动机轮盘进行了低循环疲劳试验.通过有限元方法计算轮盘在发动机工作条件下的应力状态，结合失效分析，确定了轮盘的关键部位和相应的标准循环.针对该轮盘的应力状态受轴向力影响大的特点，运用类比法确定了试验参数，设计的试验装置实现了在旋转条件下对轮盘施加轴向力.研究表明：轮盘关键部位的确定不仅与应力水平有关，还与结构和失效模式有关.试验设计须考虑轴向力对轮盘应力状态产生的影响.试验装置通过调节油量控制轴向力，可同时满足不同试验参数的新盘和外场使用盘的需要.
- 低循环疲劳试验 /
- 旋转轮盘 /
- 传统安全寿命法 /
- 关键部位 /
- 轴向力
Abstract: In order to meet the outfield service requirement of the engine assembled in a aircraft, the research was conducted on low cycle fatigue test of aero-engine disc based on traditional safety life method. The stress state of disc under engine working conditions was calculated using finite element method, while the critical positions and the corresponding standard cycle were confirmed with failure analysis. According to the feature that the disc's stress state was affected by axial loading, the test parameters were confirmed through analogy, and the test rig was designed to apply axial loading to the disc under rotating condition. The research shows: the critical position of the disc is not only related to stress level, but also depends on structure and failure mode. Test design needs to consider the impact on the stress state by axial loading. By adjusting the amount of oil, the test rig can control the axial loading and meet the requirement of various tests with different parameters for the new disc and the used one after outfield service.
- low cycle fatigue test /
- rotating disc /
- traditional safety life method /
- critical position /
- axial loading

HTML

参考文献(18)

[1]	Corran R S J,Williams S J.Lifing methods and safety criteria in aero gas turbines[J].Engineering Failure Analysis,2007,14:518-528.
[2]	Rolls-Royce Limited.SPEY Mk's 201,202,203.Derby,U.K.:Rolls-Royce Limited,ISSUE 4,1982.
[3]	Rolls-Royce Limited.SPEY Mk202 HP compressor stage 2-12 discs and spacers.Derby,U.K.:Rolls-Royce Limited,ASR 3480,1965.
[4]	Military Aviation Authority.Defence standard 00-970 design and airworthiness requirements for service aircraft:Part 11 engines[S].U.K.:Ministry of Defence,2006:ANNEX A4-A7.
[5]	Military Aviation Authority.Defence standard 00-971 General specification for aircraft gas turbine engine[S].U.K.:Ministry of Defence,1987:ANNEX A1-A2.
[6]	何倩,黄怀璋,陈应根,等.斯贝Mk202发动机翻修手册:第6册[M].西安:西安航空发动机公司,1988.
[7]	Rolls-Royce Limited.Military SPEY Mk's 101,202 and 250 series identification of LCF cracking regions group ‘A’ components.Derby,U.K.:Rolls-Royce Limited,HSK 3254,1985.
[8]	Rolls-Royce Limited.SPEY RB163-25 HP compressor St.1 & 2 discs,cold cyclic fatigue test with simulated gas load for life assessment.Derby,U.K.:Rolls-Royce Limited,MRA 10612,1970.
[9]	Rolls-Royce Limited.SPEY Mk202 fatigue stresses in S/CMV HP turbine shaft.Derby,U.K.:Rolls-Royce Limited,AST 4859,1965.
[10]	Rolls-Royce Limited.SPEY Mk506-14D M162 stress analysis of HP 7-9 compressor discs under engine conditions and rig analysis of stage 8 HP compressor disc.Derby,U.K.:Rolls-Royce Limited,MRA 10628,1988.
[11]	Rolls-Royce Limited.SPEY Mk506-14 HP compressor stage 7 disc temperature predictions.Derby,U.K.:Rolls-Royce Limited,TDR 12109,1988.
[12]	Rolls-Royce Limited.Experiment of component test department report RB163-2&25 HP compressor stage 8 disc in H53V specimens 177 cold cyclic fatigue test.Derby,U.K.:MRA 10653,1965.
[13]	汪好,宋文艳,石德永.压气机和涡轮转子三维温度场计算研究[J].航空工程进展,2012,3(3):344-350. WANG Hao,SONG Wenyan,SHI Deyong.Calculation study on the compressor and turbine rotor three-dimensional temperature field[J].Advances in Aeronautical Science and Engineering,2012,3(3):344-350.(in Chinese)
[14]	Rolls-Royce Limited.EGD-3 SPEY Mk202 stressing standards[S].U.K.:Rolls-Royce Limited,1979:48.
[15]	Rolls-Royce Limited.Military SPEY cyclic life review.Derby,U.K.:Rolls-Royce Limited,MDM 16090,1985.
[16]	Rolls-Royce Limited.Commercial SPEY Mk506-14D group ‘A’ component life declaration for rated and full throttle take-off procedure.Derby,U.K.:Rolls-Royce Limited,DLR 10027,1975.
[17]	Rolls-Royce Limited.Proposed peak stress fatigue design criteria for IMI685,FV535 and N901 materials.Derby,U.K.:Rolls-Royce Limited,ASR 4911,1971.
[18]	ANE-111.33.70-1 Guidance material for aircraft engine life-limited parts requirements[S].U.S.:Department of Transportation,2009:10-11.
