间隙约束二元翼段系统分岔与多解共存现象分析

尹磊磊; 张思进; 文桂林; 徐慧东

doi:10.13224/j.cnki.jasp.2014.06.022

间隙约束二元翼段系统分岔与多解共存现象分析

doi: 10.13224/j.cnki.jasp.2014.06.022

湖南大学机械与运载工程学院, 长沙 410082

基金项目:

国家杰出青年科学基金（11225212）；国家自然科学基金（11372101，11002052）

详细信息

作者简介:
尹磊磊（1989- ），男，湖北汉川人，硕士生，主要从事非光滑动力学研究.

通讯作者:
张思进（1971- ），男，安徽潜山人，教授，主要从事非光滑动力学、动力学控制、复合材料动力学及分岔控制理论等方面的研究.

中图分类号: V211.41;V211.3
计量
- 文章访问数: 1351
- HTML浏览量: 1
- PDF量: 868
- 被引次数: 0
出版历程
- 收稿日期: 2013-04-08
- 刊出日期: 2014-06-28

Analysis on the system bifurcation and coexistence of multiple solutions for typical airfoil section with freeplay

College of Mechanical and Vehicle Engineering, Hunan University, Changsha 410082, China

摘要

摘要: 研究了分段刚度描述的间隙约束二元翼段气动弹性系统，取俯仰角最大幅值处为类 Poincaré 截面，数值计算得到了系统随飞行速度变化的分岔图，发现飞行速度在Ma=0.71~0.75属于跨临界颤振区，而在Ma=0.75~0.95发生极限环震荡.同时通过构造极限环震荡的四维Poincaré映射分析了极限环震荡的稳定性，结合稳定性和运动流形理论，得到极限环震荡的吸引域一般位于极限环内部并用数值方法进行了验证.且跨临界颤振速度区域中存在多种分岔形式以及多解共存现象，例如由双周期运动直接通向混沌、多周期运动与双周期运动共存现象，振动幅值也存在跳跃现象.
- 间隙非线性 /
- 二元翼段 /
- 极限环震荡 /
- 类Poincaré /
- 截面 /
- 分岔 /
- 吸引域
Abstract: The typical airfoil section system with freeplay described by a piecewise-stiffness model was studied. The pitch angle at the maximum amplitude was chosen as the quasi-Poincaré sections to obtain numerically the bifurcation diagram with change of flight speed. It was found the trans-critical flutter area was located on flight speed of Ma=0.71-0.75 and limit cycle oscillation area located on flight speed of Ma=0.75-0.95 based on the bifurcation diagram. The stability of limit cycle oscillation was analyzed through the constructed four-dimensional map. According to the stability and motion manifold theory, it was learnt that the attraction basin of the limit cycle oscillation was located in the interior region of limit cycle, which was validated by the numerical method at last. At the same time, the coexistence of multiple solutions and various forms of bifurcation phenomena were found in trans-critical flutter area, such as the direct transition from double periodic motion to chaos, the coexistence of multiple periodic motion and double periodic motion, and the phenomenon of jump on amplitude.
- freeplay nonlinearity /
- typical airfoil section system /
- limit cycle oscillation /
- quasi-Poincaré /
- section /
- bifurcation /
- attraction basin

HTML

参考文献(17)

[1]	Ashley H,Zartarian G.Piston theory:a new aerodynamic tool for the aeroelastician[J].Journal of Aeronaut Science,1956,23(12):1109-1118.
[2]	Liviu L,Gianfranco C,Picrgiovanni M.Implications of cubic physical/aerodynamic non-linearities on the character of the flutter instability boundary[J].International Journal of Non-Linear Mechanics,2003,38:173-199.
[3]	Sander G,Bon C,Geradin M.Finite element analysis of supersonic panel flutter[J].International Journal for Numerical Methods in Engineering,1973,7(3):379-394.
[4]	Mcintosh J R S C,Reed J R R E,Rodden W P.Experimental and theoretical study of nonlinear flutter[J].Journal of Aircraft,1981,18(12):1057-1063.
[5]	Sheta E F,Harrand V J,Thompson D E,et al.Computational and experimental investigation of limit cycle oscillations of nonlinear aeroelastic systems[J].Journal of Aircraft,2002,39(1):133-141.
[6]	Liu L,Wong Y S,Lee B H K.Application of the center manifold theory in nonlinear aeroelasticity[J].Journal of Sound and Vibration,2000,234(4):641-659.
[7]	Sadaghat A,Copper J E.Limit cycle oscillation prediction for aeroelastic systems with continuous nonlinearities[J].AIAA 2000-1397,2000.
[8]	郑国勇,杨翊仁.结构非线性机翼的超音速和高超音速颤振[J].西南交通大学学报,2007,42(5):578-582. ZHENG Guoyong,YANG Yiren.Flutter of airfoil with structural nonlinearity in supersonic and hypersonic flow[J].Journal of Southwest Jiaotong University,2007,42(5):578-582.(in Chinese)
[9]	王益峰,邵松,朱清华,等.带有气动及结构非线性的二元机翼颤振分析[J].航空动力学报,2012,27(9):2063-2074. WANG Yifeng,SHAO Song,ZHU Qinghua,et al.Flutter analysis of a two-dimensional wing with aerodynamic and structural non-linearity[J].Journal of Aerospace Power,2012,27(9):2063-2074.(in Chinese)
[10]	Bunton R W,Denegri J R C M.Limit cycle oscillation characteristics of fighter aircraft[J].Journal of Aircraft,2000,37(5):916-918.
[11]	Denegri J R C M.Limit cycle oscillation test results of a fighter with external stores[J].Journal of Aircraft,2000,37(5):761-769.
[12]	Ding Q,Wang L D.Flutter control of a two-dimensional airfoil using wash-out filter technique[J].Chinese Journal of Aeronautics,2005,18(2):130-136.
[13]	于明礼,文浩,胡海岩,等.二维翼段颤振的μ控制[J].航空学报,2007,28(2):340-343. YU Mingli,WEN Hao,HU Haiyan,et al.Active flutter suppression of a two-dimensional airfoil section using μ synthesis[J].Acta Aeronautica et Astronautica Sinica,2007,28(2):340-343.(in Chinese)
[14]	李道春,向锦武.间隙非线性气动弹性颤振控制[J].北京航空航天大学学报,2007,33(6):640-643. LI Daochun,XIANG Jinwu.Flutter control of aeroelasticity with freeplay nonlinearity[J].Journal of Beijing University of Aeronautics and Astronautics,2007,33(6):640-643.(in Chinese)
[15]	任爱娣,张琪昌.具有不对称间隙的二元机翼颤振研究[J].工程力学,2006,23(9):25-29. REN Aidi,ZHANG Qichang.The flutter study of a two-dimensional airfoil with asymmetry freeplay[J].Engineering Mechanics,2006,23(9):25-29.(in Chinese)
[16]	赵永辉,胡海岩.具有操纵面间隙非线性二维翼段的气动弹性分析[J].航空学报,2003,24(6):521-525. ZHAO Yonghui,HU Haiyan.Aeroelastic analysis of a two-dimensional airfoil with control surface freeplay nonlinearity[J].Acta Aeronautica et Astronautica Sinica,2003,24(6):521-525.(in Chinese)
[17]	Zhang S J,Wen G L,Peng F,et al.Analysis to limit cycle vibration of a typical airfoil section with freeplay[J].Acta Mechanica Sinica,2013,29(4):583-592.
