几何构型对逆流推力矢量喷管特性影响

刘赵淼; 徐迎丽; 申峰

doi:10.13224/j.cnki.jasp.2014.06.023

几何构型对逆流推力矢量喷管特性影响

doi: 10.13224/j.cnki.jasp.2014.06.023

北京工业大学机械工程与应用电子技术学院, 北京 100124

基金项目:

北京市教委科技计划重点项目（KZ201210005003）

详细信息

作者简介:
刘赵淼（1970- ），女，吉林德惠人，教授，博士，主要从事计算流体力学和微流体力学研究.

中图分类号: V235.15
计量
- 文章访问数: 1603
- HTML浏览量: 96
- PDF量: 850
- 被引次数: 0
出版历程
- 收稿日期: 2013-03-22
- 刊出日期: 2014-06-28

Geometric configuration on the performance of counterflow thrust vectoring nozzle

College of Mechanical Engineering and Applied Electronics Technology, Beijing University of Technology, Beijing 100124, China

摘要

摘要: 采用数值模拟方法研究了几何构型对逆流推力矢量喷管内部流动结构及性能的影响.研究结果表明：主流未附体时，增大缝宽可提高推力矢量角，但同时却降低了合成推力系数，抽吸二次流流向由同向转变为逆向且流量逐渐增大；增大斜切角可致使推力矢量角减小，合成推力系数先增大后减小.随着斜切角的增大，抽吸二次流流向由逆向逐渐转变为同向二次流，流量比在2%以内，且呈先减小后增大趋势.
- 逆流 /
- 矢量喷管 /
- 缝宽 /
- 斜切角 /
- 推力系数
Abstract: Numerical simulation was applied to study internal flow structure and performance of counterflow thrust vectoring nozzle with geometric configuration. Results indicate that thrust vectoring angle increased with the increasing of slot height and terminal angle when the jet was not attached to the collar, while resultant thrust ratio decreased. Suction second flow shifted from coflow to counterflow, while the mass flow rate increased. The thrust vectoring angle decreased with the increase of terminal angle; resultant thrust ratio firstly increased but then decreased. During the procedure of increasing terminal angle, suction second flow shifted from counterflow to coflow, and mass flow rate was less than 2%, but decreased and then increased.
- counterflow /
- vectoring nozzle /
- slot height /
- terminal angle /
- thrust coefficient

HTML

参考文献(15)

[1]	段冬冬,沈小林.推力矢量技术在空空导弹上的应用与分析[J].飞航导弹,2012(4):84-87.
[2]	宫朝霞,王蕾.国外空空导弹发展综述[J].飞航导弹,2011(4):60-67.
[3]	宋亚飞,高峰,何至林.流体推力矢量技术[J].飞航导弹,2010(11):71-75,89.
[4]	连永久.射流推力矢量控制技术研究[J].飞机设计,2008,28(2):19-24. LIAN Yongjiu.Fluidic thrust vectoring techniques research[J]. Aircraft Design,2008,28(2):19-24.(in Chinese)
[5]	范文正,李明.推力矢量喷管现状和发展趋势[J].航空科学技术,2006(1):21-22. FAN Wenzheng,LI Ming.Status and trends of the thrust-vectoring nozzle[J].Aeronautial Science and Technology,2006(1):21-22.(in Chinese)
[6]	Madruga S M.Experimental study on counterflow thrust vectoring of a gas turbine engine.Florida:Florida State University,2005.
[7]	Flamm J D.Experimental study of a nozzle using fluidic counterflow for thrust vectoring[J].AIAA 98-3255,1998.
[8]	Hunter C A,Deere K A.Computational investigation of fluidic counter flow thrust vectoring[J].AIAA 99-2669,1999.
[9]	Dores D,Madruga S M,Krothapalli A,et al.Characterization of a counterflow thrust vectoring scheme on a gas turbine engine exhaust jet.California,SF:3rd AIAA Flow Control Conference,2006.
[10]	Dores D,Madruga S M,Krothapalli A,et al.Characterization of a counterflow thrust vectoring scheme on a gas turbine engine exhaust jet.California,SF:3rd AIAA Flow Control Conference,2006.
[11]	汪明生,杨建军.逆流推力矢量喷管基本流动特征的数值研究[J].航空学报,2008,29(4):769-775. WANG Mingsheng,YANG Jianjun.Numerical research on basic flow characteristics of counterflow thrust[J].Acta Aeronautica et Astronautica Sinica,2008,29(4):769-775.(in Chinese)
[12]	汪明生,杨建军.逆流推力矢量喷管的非定常内流性能研究[J].航空动力学报,2009,24(1):75-82. WANG Mingsheng,YANG Jianjun.Unsteady internal performance study of counterflow vectoring thrust nozzle[J].Journal of Aerospace Power,2009,24(1):75-82.(in Chinese)
[13]	汪明生,杨建军.几何参数对逆流矢量喷管性能的影响研究[J].火箭推进,2009,35(2):30-36. WANG Mingsheng,YANG Jianjun.Effect of geometric parameters on performance of counterflow thrust vectoring nozzle[J].Journal of Rocket Proplusion,2009,35(2):30-36.(in Chinese)
[14]	刘赵淼,张谭.Laval型微喷管内气体流动的计算及分析[J].航空动力学报,2008,24(7):1556-1563. LIU Zhaomiao,ZHANG Tan.Numerical investigation on gas flow in Laval micronozzle[J].Journal of Aerospace Power,2008,24(7):1556-1563.(in Chinese)
[15]	刘赵淼,张谭,逄燕.喉部形状设计对微喷管内流动及性能的影响[J].航空动力学报,2010,25(10):2279-2284. LIU Zhaomiao,ZHANG Tan,PANG Yan.Effects of throat shape design on propulsion performance of micronozzles[J].Journal of Aerospace Power,2010,25(10):2279-2284.(in Chinese)
