浸入边界法模拟小圆柱对主圆柱涡脱落的抑制

宋利伟; 吴颂平

doi:10.13224/j.cnki.jasp.2014.06.028

浸入边界法模拟小圆柱对主圆柱涡脱落的抑制

doi: 10.13224/j.cnki.jasp.2014.06.028

宋利伟¹,
吴颂平^1,2,3

1. 北京航空航天大学航空科学与工程学院, 北京 100191;
2. 北京航空航天大学国家计算流体力学实验室, 北京 100191;
3. 北京航空航天大学流体力学教育部重点实验室, 北京 100191

基金项目:

国家自然科学基金（91016006）

详细信息

作者简介:
宋利伟（1979- ），男，辽宁海城人，博士生，主要从事计算流体力学研究.

中图分类号: V211.3
计量
- 文章访问数: 1653
- HTML浏览量: 97
- PDF量: 903
- 被引次数: 0
出版历程
- 收稿日期: 2013-03-21
- 刊出日期: 2014-06-28

Suppression of vortex shedding around main circular cylinder by another small control cylinder using immersed boundary method

SONG Li-wei¹,
WU Song-ping^1,2,3

1. School of Aeronautic Science and Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China;
2. National Laboratory for Computational Fluid Dynamics, Beijing University of Aeronautics and Astronautics, Beijing 100191, China;
3. Key Laboratory of Fluid Mechanics of Ministry of Education, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 使用浸入边界法研究了小圆柱对主圆柱涡脱落的抑制.方法中使用非贴体笛儿尔网格，易于处理包含复杂边界的流动问题.采用离散附加力直接加入边界条件方法对虚单元进行重构，使边界条件在浸入边界上精确满足.使用隐式分步法解二维非定常不可压Navier-Stokes方程，通过速度和压力解耦提高计算效率.数值模拟单圆柱绕流及不同位置小圆柱和主圆柱的流动干扰，通过分析流场涡结构和升、阻力系数，得到小圆柱对主圆柱涡脱落的延迟和抑制作用.计算结果与已有实验结论和数值结果对比，计算误差不超过5%，说明浸入边界法可以简单有效地处理圆柱涡脱落抑制这类流动干扰问题.
- 涡脱落抑制 /
- 不可压流动 /
- 浸入边界法 /
- 分步法 /
- 非贴体网格
Abstract: Based on the immersed boundary method, the suppression of vortex shedding around a main circular cylinder by another small control cylinder was numerically studied. The flow was computed on non-body conformal Cartesian grid, which was suitable for problems with complex boundaries. The discrete forcing direct boundary condition imposition could impose boundary condition on immersed boundary accurately. An implicit fractional step method on collocated grid was used to solve the two-dimensional unsteady incompressible Navier-Stokes equations, and improve its computational efficiency by decoupling of velocity and pressure. The numerical simulations included the flow over a cylinder and the flow interference between a main circular cylinder and another small control cylinder located at two different positions. From analysis on the vortex structure of flow fields and the lift and drag coefficients, the delay and complete suppression of vortex shedding behind the main circular cylinder was found. All the calculated results agreed well with the previous experiment and numerical results, with the error not exceeding 5%. This indicates the immersed boundary method could be simply and efficiently used for numerical simulation on suppression of vortex shedding.
- suppression of vortex shedding /
- incompressible flow /
- immersed boundary method /
- fractional step method /
- non-body conformal grid

HTML

参考文献(17)

[1]	Zdravkovich M M.The effects of interference between circular cylinders in cross flow[J].Journal of Fluids and Structures,1987,1(2):239-261.
[2]	Zdravkovich M M.Review of flow interference between two circular cylinders in various arrangements[J].Journal of Fluids Engineering,1977,99(4):618-633.
[3]	Strykowski P J,Sreenivasan K R.On the formation and suppression of vortex shedding at low Reynolds numbers[J].Journal of Fluid Mechanics,1990,218(9):71-107.
[4]	Dipankar A,Sengupta T K,Talla S B.Suppression of vortex shedding behind a circular cylinder by another control cylinder at low Reynolds numbers[J].Journal of Fluid Mechanics,2007,573(2):171-190.
[5]	Kim J,Choi H.An immersed-boundary finite-volume method for simulation of heat transfer in complex geometries[J].Journal of Mechanical Science and Technology,2004,18(6):1026-1035.
[6]	李椿萱,彭少波,吴子牛.附属小圆柱对主圆柱绕流影响的数值模拟[J].北京航空航天大学学报,2003,29(11):951-968. LEE Chunhian,PENG Shaobo,WU Ziniu.Numerical study of flow around a main cylinder by controlled satellite cylinders[J].Journal of Beijing University of Aeronautics and Astronautics,2003,29(11):951-968.(in Chinese)
[7]	彭少波,吴子牛.小圆柱控制主圆柱涡脱落的详细流动结构数值研究[J].兵工学报,2000,20(suppl.):29-31. PENG Shaobo,WU Ziniu.Numerical study of flow field structures behind a circular cylinder with vortex shedding controlled by a small cylinder[J].Acta Armamentarii,2000,20(suppl.):29-31.(in Chinese)
[8]	Peskin C S.Flow patterns around heart valves:a numerical method[J].Journal of Computational Physics,1972,10(2):252-271.
[9]	Mittal R,Iaccarino G.Immersed boundary methods[J].Annual Reviews of Fluid Mechanics,2005,37(2):239-261.
[10]	Mittal R,Dong H,Bozkurttas M,et al.A versatile sharp interface immersed boundary method for incompressible flows with complex boundaries[J].Journal of Computational Physics,2008,227(10):4825-4852.
[11]	Van Kan J.A second-order accurate pressure-correction scheme for viscous incompressible flow[J].Journal on Scientific and Statistical Computing,1986,7(3):870-891.
[12]	Ye T,Mittal R,Udaykumar H S,et al.An accurate Cartesian grid method for viscous incompressible flows with complex immersed boundaries[J].Journal of Computational Physics,1999,156(2):209-240.
[13]	Zang Y,Streett R L,Koseff J R.A non-staggered fractional step method for time-dependent incompressible Navier-Stokes equations in curvilinear coordinates[J].Journal of Computational Physics,1994,114(1):18-33.
[14]	Majumdar S,Iaccarino G,Durbin P A.RANS solver with adaptive structured boundary non-conforming grids//CTR Annual Research Briefs.Stanford:Center for Turbulence Research,2001:353-366.
[15]	Chiu P H,Lin R K,Sheu Tony W H.A differentially interpolated direct forcing immersed boundary method for predicting incompressible Navier-Stokes equations in time-varying complex geometries[J].Journal of Computational Physics,2010,229(12):4476-4500.
[16]	Xu S,Wang Z J.An immersed interface method for simulating the interaction of a fluid with moving boundaries[J].Journal of Computational Physics,2006,216(2):454-493.
[17]	Liu C,Zheng X,Sung C H.Preconditioned multigrid methods for unsteady incompressible flows[J].Journal of Computational Physics,1998,139(1):35-57.
