激波矢量控制喷管落压比影响矢量性能及分离区控制数值模拟

王猛杰; 额日其太; 王强; 吴盟

doi:10.13224/j.cnki.jasp.2015.03.002

激波矢量控制喷管落压比影响矢量性能及分离区控制数值模拟

doi: 10.13224/j.cnki.jasp.2015.03.002

1. 北京航空航天大学能源与动力工程学院, 北京 100191;
2. 中国航空工业集团公司成都发动机 (集团)有限公司, 成都 610503

详细信息

作者简介:
王猛杰(1986-),男,浙江萧山人,博士生,主要从事流体推力矢量喷管及横向射流与主流相互作用研究.

中图分类号: V231.3
计量
- 文章访问数: 1602
- HTML浏览量: 150
- PDF量: 888
- 被引次数: 0
出版历程
- 收稿日期: 2014-02-28
- 刊出日期: 2015-03-28

Numerical simulaton of nozzle pressure ratio effect on vector performance and separation control for shock vector control nozzle

1. School of Energy and Power Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China;
2. Chengdu Engine (Group) Company Limited, Aviation Industry Corporation of China, Chengdu 610503, China

摘要

摘要: 激波矢量控制喷管矢量角随落压比(NPR)的增大而下降的现象已被许多研究所证实.对NPR影响矢量角机理及基于多缝腔体和多缝辅助注气方法的分离区控制研究,目标是寻求大NPR条件下矢量性能提高的方法.研究表明:NPR影响矢量角的机理主要由于次流下游近壁面分离区由小NPR时的开放型变为大NPR时的封闭型,从而导致由于壁面压差力产生的矢量力减小所致.多缝辅助注气方法可以有效控制分离区在大NPR时保持开放,注气压力为环境压力时可以在不从系统额外引气的条件下提高矢量性能.
- 激波矢量控制 /
- 矢量角 /
- 落压比 /
- 多缝辅助注气 /
- 分离区
Abstract: The phenomenon that vector angle of shock vector control nozzle decreases with increasing nozzle pressure ratio (NPR) has been verified by numerous researches. The study was involved with the mechanism of vector angle variation with NPR and multi-slot cavity and multi-slot assistant injection for separation control. A way for improvement of vector performance at large NPR conditions was studied. Results indicate that, the mechanism of vector angle variation with NPR is mainly due to the transition of separation region structure (from open to closed), which is located downstream the secondary injection. This leads to the reduction of thrust vector force caused by wall pressure difference. With the help of multi-slot assistant injection, the separation can be kept open at large NPR conditions. Vector performance can be improved by atmosphere pressure injection without need of bleeding air from engine.
- shock vector control /
- vector angle /
- nozzle pressure ratio(NPR) /
- multi-slot assistant injection /
- separation

HTML

参考文献(18)

[1]	Karen A D.Summary of fluidic thrust vectoring research conducted at NASA langley research center[R].AIAA-2003-3800,2003.
[2]	Wing D J.Static investigation of two fluidic thrust-vectoring concepts on a two-dimensional convergent-divergent nozzle[R].NASA TM-4574,1994.
[3]	Deere K A.Computational investigation of the aerodynamic effects on fluidic thrust vectoring[R].AIAA-2000-3598,2000.
[4]	Andrew J N,Fernando N G,John Y.Performance studies of shock vector control fluidic thrust vectoring[R].AIAA-2007-5086,2007.
[5]	Yagle P J,Miller D N,Ginn K B,et al.Demonstration of fluidic throat skewing for thrust vectoring in structrally fixed nozzles[R].ASME Paper 2000GT-0013,2000.
[6]	Miller D N,Catt J A.Conceptual development of fixed-geometry nozzles using fluidic injection for throat area control[R].AIAA 95-2603,1995.
[7]	Sadiq M U.Performance analysis and flowfield characterization of secondary injection thrust vector control (SITVC) for a 2DCD nozzle[D].Los Angeles:University of Southern California,2007.
[8]	DalBello T,Georgiadis N J,Yoder D A,et al.Computational study of axisymmetric off-design nozzle flows[R].NASA/TM-2003-212876,2003.
[9]	吴雄.固体发动机燃气二次喷射理论与试验研究[D].长沙:国防科学技术大学,2007. WU Xiong.Theoretical and experimental research on hot gas secondary injection for solid rocket motor[D].Changsha:National University of Defence Technology,2007.(in Chinese)
[10]	Dickmann D A.On the near field mean flow structure of transverse jets issuing into a supersonic freestream[D].Arlington:University of Texas,2007.
[11]	Anderson C J,Giuliano V J,Wing D J.Investigation of hybrid fluidic/mechanical thrust vectoring for fixed-exit exhaust nozzles[R].AIAA 97-3148,1997.
[12]	Waithe K A,Deere K A.Experimental and computational investigation of multiple injection ports in a convergent-divergent nozzle for fluidic thrust vectoring[R].AIAA-2003-3802,2003.
[13]	Miller D N,Yagle P J,Hamstra J W.Fluidic throat skewing for thrust vectoring in fixed geometry nozzles[R].AIAA 99-0365,1999.
[14]	Hunter C A,Deere K A.Computational investigation of fluidic counterflow thrust vectoring[R].AIAA 99-2669,1999.
[15]	Flamm J D.Experimental study of a nozzle using fluidic counterflow for thrust vectoring[R].AIAA 98-3255,1998.
[16]	Dhinagaran R,Bose T.Comparison of Euler and Navier-Stokes solutions for nozzle flows with secondary injection[R].AIAA 96-0453,1996.
[17]	Hunter C A.Experimental,theoretical and computational investigation of separated nozzle flows[R].AIAA 98-3107,1998.
[18]	Asbury S C,Hunter C A.Static performance of a fixed-geometry exhaust nozzle incorporating porous cavities for shock-boundary layer interaction[R].NASA TM-1999-209513,1999.
