旋翼非定常气动特性CFD模拟的通用运动嵌套网格方法

赵国庆; 招启军; 吴琪

doi:10.13224/j.cnki.jasp.2015.03.004

旋翼非定常气动特性CFD模拟的通用运动嵌套网格方法

doi: 10.13224/j.cnki.jasp.2015.03.004

南京航空航天大学航空宇航学院直升机旋翼动力学国家级重点实验室, 南京 210016

基金项目:

国家自然科学基金(11272150)

江苏高校优势学科建设工程

详细信息

作者简介:
赵国庆(1984-),男,山东五莲人,博士生,主要从事旋翼计算流体力学、流动控制研究.

中图分类号: V211.3
计量
- 文章访问数: 1592
- HTML浏览量: 110
- PDF量: 914
- 被引次数: 0
出版历程
- 收稿日期: 2013-10-24
- 刊出日期: 2015-03-28

A universal moving-embedded grid method for CFD simulation of unsteady aerodynamic characteristics of rotor

National Key Laboratory of Science and Technology on Rotorcraft Aeromechanics, College of Aerospace Engineering, Nanjing University of Aeronautics and Astronautics, 210016, China

摘要

摘要: 针对直升机旋翼非定常气动特性CFD模拟中的网格生成难题,提出了一套高效、通用的运动嵌套网格生成方法.首先,基于Poisson方程求解和翻折法生成旋翼桨叶的正交贴体网格.其次,针对旋翼桨叶的扭转分布及变距、挥舞等复杂运动,建立了一套通用的洞单元识别的扰动衍射法;为保证洞包络面的封闭性,完善了挖洞过程中网格加密策略;在洞边界确立基础上,提出了一种高效、鲁棒的最小距离法贡献单元搜索的改进方法.在此基础上,建立了基于RANS(Reynolds-averaged Navier-Stokes)方程的旋翼非定常流场CFD模拟方法.最后,采用所建立的方法分别对悬停和前飞状态下的C-T(Caradonna-Tung)旋翼和7A(Helishape 7A)旋翼的气动特性、桨尖涡的位置进行了计算,计算结果与试验值误差小于5%,验证了该运动嵌套网格生成方法在旋翼非定常气动特性CFD模拟中的有效性.
- 旋翼 /
- 非定常气动特性 /
- 运动嵌套网格 /
- 扰动衍射法 /
- 最小距离法
Abstract: Targeting the problem on grid generation for the CFD simulation of the unsteady aerodynamic characteristics of helicopter rotor, a highly-efficient and universal moving-embedded grid generation method was proposed. Firstly, the orthogonal and body-fitted grid around rotor blade were generated by using Poisson equations and folding approach. Then, considering the twist distribution and the complex pitching, flagging motion of rotor blade, a method for the identification of hole cells named disturbance diffraction method was established. In order to ensure the closeness of hole envelope surface, the grid refinement strategy in the hole-cutting procedure was improved. Meanwhile, based upon the determination of the hole boundary, an modified minimum distance scheme of donor element method with high efficiency and robustness was developed for searching the donor cells. On these basis, the CFD simulation method for unsteady flowfield of rotor was conducted by solving the RANS (Reynolds-averaged Navier-Stokes) equations. Finally, the aerodynamic characteristics and location of the blade tip vortex for C-T(Caradonna-Tung) and 7A (Helishape 7A) rotors were simulated by the presented method in hovering and forward flight respectively. The errors of numerical results are less than 5% according to the experiment data, and the effectiveness of CFD simulation on the unsteady aerodynamic characteristics of different rotors is demonstrated.
- rotor /
- unsteady aerodynamic characteristics /
- moving-embedded grid /
- disturbance diffraction method /
- minimum distance scheme of donor element

HTML

参考文献(21)

[1]	Coder J G,Maughmer M D,Martin P B.CFD investigation of unsteady rotorcraft airfoil aerodynamics:mites and dynamic stall[R].AIAA-2011-1125,2011.
[2]	Leishman J G.Principles of helicopter aerodynamics[M].Cambridge,UK:Cambridge University Press,2000.
[3]	孙伟,张呈林.直升机桨叶气动外形多目标优化设计[J].航空动力学报,2011,26(7):1608-1614. SUN Wei,ZHANG Chenglin.Multi-objective optimization for aerodynamic shape of helicopter blade[J].Journal of Aerospace Power,2011,26(7):1608-1614.(in Chinese)
[4]	Steijl R,Barakos G.CFD analysis of rotor-fuselage interactional aerodynamics[R].AIAA-2007-1278,2007.
[5]	Belk D M,Mapple R C.Automated assembly of structured grids for moving body problems[R].AIAA 95-1680-CP,1995.
[6]	叶靓,招启军,徐国华.非结构嵌套网格的直升机旋翼/机身前飞流场数值模拟[J].航空动力学报,2009,24(4):904-909. YE Liang,ZHAO Qijun,XU Guohua.Numerical simulation of flowfield of helicopter rotor and fuselage in forward flight based on unstructured embedded grid technique[J].Journal of Aerospace Power,2009,24(4):904-909.(in Chinese)
[7]	Wang J Z,Parthasarathy V,Hariharan N.A fully automated chimera methodology for multiple moving body problems[R].AIAA 98-217,1998.
[8]	杨文青,宋笔锋,宋文萍.高效确定重叠网格对应关系的距离减缩法及其应用[J].航空学报,2009,30(2):205-212. YANG Wenqing,SONG Bifeng,SONG Wenping.Distance decreasing method for confirming corresponding cells of overset grids and its application[J].Acta Aeronautica et Astronautica Sinica,2009,30(2):205-212.(in Chinese)
[9]	Benek J A,Buning P G,Steger J L.A 3-D chimera grid embedding technique[R].AIAA 85-1523,1985.
[10]	Nirschl H,Dwyer H A,Denk V.A chimera grid scheme for the calculation of particle flows[R].AIAA 94-0519,1994.
[11]	ZHAO Qijun,XU Guohua,ZHAO Jinggen.Numerical simulations of the unsteady flowfield of helicopter rotors on moving embedded grids[J].Aerospace Science and Technology,2005,9(2):117-124.
[12]	LaBozzetta W F,Gatzke T D.MACGS:towards the complete grid generation system[R].AIAA 94-1923-CP,1994.
[13]	Meakin R L.A new method for establishing intergrid communication among systems of overset grids[R].AIAA 91-1586,1991.
[14]	王博,招启军,徐广,等.一种适合于旋翼前飞非定常流场计算的新型运动嵌套网格方法[J].空气动力学学报,2012,30(1):14-21. WANG Bo,ZHAO Qijun,XU Guang,et al.A new moving-embedded grid method for numerical simulation of unsteady flow-field of the helicopter rotor in forward flight[J].Acta Aerodynamica Sinica,2012,30(1):14-21.(in Chinese)
[15]	于子文,曹义华.涵道尾桨的CFD模拟与验证[J].航空动力学报,2006,21(1):19-24. YU Ziwen,CAO Yihua.CFD simulation and validation of ducted tail rotor[J].Journal of Aerospace Power,2006,21(1):19-24.(in Chinese)
[16]	Meakin R.A new method for establishing intergrid communication among systems of overset grids[R].AIAA 91-1586,1991.
[17]	Allmaras S.A one-equation turbulence model for aerodynamic flows[R].AIAA 92-0439,1992.
[18]	Caradonna F X,Tung C.Experimental and analytical studies of a model helicopter rotor in hover[J].Vertica,1981,5(1):149-161.
[19]	Steijl R,Barakos G N,Badcock K J.A CFD framework for analysis of helicopter rotors[R].AIAA-2005-5124,2005.
[20]	Caradonna F X,Laub G H,Tung C.An experimental investigation of the parallel blade-vortex interaction[R].NASA/TM 86005,1984.
[21]	Light J S.Tip vortex geometry of a hovering helicopter rotor in ground effect[J].Journal of the American Helicopter Society,1993,38(2):34-42.
