双弯曲入射激波的可控中心体内收缩基准流场设计

李永洲; 张堃元; 朱伟; 杨顺凯

doi:10.13224/j.cnki.jasp.2015.03.006

双弯曲入射激波的可控中心体内收缩基准流场设计

doi: 10.13224/j.cnki.jasp.2015.03.006

南京航空航天大学能源与动力学院, 南京 210016

基金项目:

国家自然科学基金(90916029, 91116001, 11102087)

详细信息

作者简介:
李永洲(1984-),男,宁夏固原人,博士生,研究方向为高超声速推进技术.

中图分类号: V439
计量
- 文章访问数: 1634
- HTML浏览量: 162
- PDF量: 912
- 被引次数: 0
出版历程
- 收稿日期: 2013-11-05
- 刊出日期: 2015-03-28

Design for inward turning basic flowfield with controlled center body and two incident curved shock waves

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 采用有旋特征线法设计了一种双弯曲入射激波的可控中心体内收缩基准流场,两道入射激波交于中心体起始点,入射激波和反射激波通过给定激波径向总压恢复系数分布进行反设计,壁面通过给定轴向马赫数分布规律进行反设计.该基准流场分为“三波四区”且压缩效率较高.基于该基准流场设计了圆形进口内收缩进气道并进行了黏性修正,数值计算结果表明:内收缩进气道设计点核心区的流场特征和激波形状与基准流场基本一致;在来流马赫数为4.0~7.0时进气道具有较高的压缩效率和良好的流量捕获能力,设计点喉道截面增压比和总压恢复系数分别为17.7和0.729;来流马赫数为5.0~7.0时内部总阻力系数变化平缓,从0.23下降为0.22.
- 高超声速进气道 /
- 基准流场 /
- 弯曲激波 /
- 中心体 /
- 反设计
Abstract: A basic flowfield with controlled center body and two incident curved shock waves was designed by rotational method of characteristics. The two incident shock waves were intersected at the initial point of the center body. Both incident shock waves and reflected shock waves were inversely designed by the given radial total pressure recovery coefficient distribution,and the wall was inversely designed by the given axial Mach number distribution. The basic flowfield with high compression efficiency was divided into three shock waves and four regions. On the basis of the basic flowfield,the inward turning inlet with circle shape intake was designed and corrected by viscosity. The computational results indicate that the flowfield characteristics and the shock waves of the core of inward turning inlet are consistent with those of the basic flowfield at design point. The inlet has good compression efficiency and mass capture ratio with incoming Mach number varying from 4.0 to 7.0. At design point, the pressure ratio of the throat is 17.7 and the total pressure recovery coefficient is 0.729. The internal total drag coefficient decreases from 0.23 to 0.22 with incoming Mach number varying from 5.0 to 7.0.
- hypersonic inlet /
- basic flowfield /
- curved shock wave /
- center body /
- inverse design

HTML

参考文献(21)

[1]	Hank J M,Murphy J S,Mutzman R C.The X-51A scramjet engine flight demonstration program[R].AIAA-2008-2540,2008.
[2]	WANG Lei,ZHANG Kunyuan,NAN Xiangjun,et al.Optimization and experimental investigation of 2-D hypersonic curved shock compression inlet[R].AIAA-2012-5959,2012.
[3]	Colville J R,Starkey R P,Lewis M J.Extending the flight Mach number of the SR-71 inlet[R].AIAA-2005-3284,2005.
[4]	王翼,范晓樯,梁剑寒,等.三维侧压高超声速进气道不启动流场试验与数值模拟研究[J].宇航学报,2008,29(6):1927-1932. WANG Yi,FAN Xiaoqiang,LIANG Jianhan,et al.Experimental and numerical investigation on the unstart flowfield of a three-dimensional sidewall compression hypersonic inlet[J].Journal of Astronautics,2008,29(6):1927-1932.(in Chinese)
[5]	Mölder S,Szpiro J.Busemann inlet for hypersonic speeds[J].Journal of Spacecraft and Rockets,1966,3(8):1303-1304.
[6]	Van Wie D,Mölder S.Applications of Busemann inlets design for flight at hypersonic speeds[R].AIAA 92-1210,1992
[7]	Billig F S,Baurle R A,Tam C J,et al.Design and analysis of streamline traced hypersonic inlets[R].AIAA 99-4974,1999.
[8]	Smart M K.Experimental testing of a hypersonic inlet with rectangular-to-elliptical shape transition[J].Journal of Propulsion and Power,2001,17(2):276-283.
[9]	Matthews A J,Jones T V.Design and test of a modular waverider hypersonic intake[R].AIAA-2005-3379,2005
[10]	尤延铖,梁德旺.内乘波式进气道内收缩基本流场研究[J].空气动力学学报,2008,26(2):203-207. YOU Yancheng,LIANG Dewang.Investigation of internal compression flowfield for internal waverider-derived inlet[J].Acta Aerodynamica Sinica,2008,26(2):203-207.(in Chinese)
[11]	郭军亮,黄国平,尤延铖,等.改善内乘波式进气道出口均匀性的内收缩基本流场研究[J].宇航学报,2009,30(5):1934-1940. GUO Junliang,HUANG Guoping,YOU Yancheng,et al.Study of internal compression flow field for improving the outflow uniformity of internal waverider inlet[J].Journal of Astronautics,2009,30(5):1934-1940.(in Chinese)
[12]	贺旭照,周正,倪鸿礼.密切内锥乘波前体进气道一体化设计和性能分析[J].推进技术,2012,33(4):510-515. HE Xuzhao,ZHOU Zheng,NI Hongli.Integrated design methods and performance analysis of osculating inward turning cone waverider forebody inlet[J].Journal of Propulsion and Power,2012,33(4):510-515.(in Chinese)
[13]	南向军,张堃元,金志光,等.压升规律可控的高超声速内收缩进气道设计[J].航空动力学报,2011,26(3):518-523. NAN Xiangjun,ZHANG Kunyuan,JIN Zhiguang,et al.Investigation on hypersonic inward turning inlets with controlled pressure gradient[J].Journal of Aerospace Power,2011,26(3):518-523.(in Chinese)
[14]	南向军,张堃元,金志光,等.矩形转圆形高超声速内收缩进气道数值及实验研究[J].航空学报,2011,32(6):988-996. NAN Xiangjun,ZHANG Kunyuan,JIN Zhiguang,et al.Numerical and experimental investigation of hypersonic inward turning inlets with rectangular to circular shape transition[J].Acta Aeronautica et Astronautica Sinica,2011,32(6):988-996.(in Chinese)
[15]	李永洲,张堃元,南向军.基于马赫数分布规律可控概念的高超声速内收缩进气道设计[J].航空动力学报,2012,27(11):2484-2491. LI Yongzhou,ZHANG Kunyua,NAN Xiangjun.Design concept of controllable Mach number distribution hypersonic inward turning inlets[J].Journal of Aerospace Power,2012,27(11):2484-2491.(in Chinese)
[16]	李永洲,张堃元,罗蕾,等.高超声速内收缩进气道轴对称基准流场改进[J].航空动力学报,2013,28(11):2543-2552. LI Yongzhou,ZHANG Kunyuan,LUO Lei,et al.Modified axisymmetric basic flowfield for hypersonic inward turning inlets[J].Journal of Aerospace Power,2013,28(11):2543-2552.(in Chinese)
[17]	Javaid K H,Serghides V C.Airframe-propulsion integration methodology for waverider derived hypersonic cruise aircraft design concepts[R].AIAA-2004-1201,2004.
[18]	南向军,张堃元.采用新型基准流场的高超声速内收缩进气道性能分析[J].宇航学报,2012,33(2):254-259. NAN Xiangjun,ZHANG Kunyuan.Analysis of hypersonic inward turning inlets with innovative axisymmetric basic flowfield[J].Journal of Astronautics,2012,33(2):254-259.(in Chinese)
[19]	Henderson L F.Maximum total pressure recovery across a system of shock waves[J].AIAA Journal,1964,2(6):1138-1140.
[20]	Drayna T W,Nompelis I,Candler G V.Hypersonic inward turning inlets:design and optimization[R].AIAA-2006-297,2006.
[21]	李永洲,张堃元,王磊,等.马赫数分布可控的基准流场灵敏度分析与优化设计[J].航空动力学报,2013,28(4):765-774. LI Yongzhou,ZHANG Kunyuan,WANG Lei,et al.Sensitivity analysis and optimization design of the basic flowfield with controllable Mach number distribution[J].Journal of Aerospace Power,2013,28(4):765-774.(in Chinese)
