分布式动力系统尾缘射流与边界层抽吸的数值分析

段静瑶; 袁巍; 李秋实

doi:10.13224/j.cnki.jasp.2015.03.007

分布式动力系统尾缘射流与边界层抽吸的数值分析

doi: 10.13224/j.cnki.jasp.2015.03.007

北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室, 北京 100191

详细信息

作者简介:
段静瑶(1989-),女,陕西西安人,硕士生,研究方向为分布式动力系统.

中图分类号: V231.3
计量
- 文章访问数: 1457
- HTML浏览量: 145
- PDF量: 896
- 被引次数: 0
出版历程
- 收稿日期: 2013-08-31
- 刊出日期: 2015-03-28

Numerical investigation on trailing edge jet and boundary layer ingestion in distributed propulsion system

National Key Laboratory of Science and Technology on Aero-Engine Aero-thermodynamics, School of Energy and Power Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 为研究带有边界层抽吸的分布式动力系统尾缘射流对机身气动性能及推进效率的影响,将机身简化为二维翼型,并加入尾缘射流及边界层抽吸的作用,利用数值模拟的手段来研究来流攻角、射流偏转角、边界层抽吸对推进效率及气动性能的影响,为分布式动力系统的设计与应用提供初步的建议.结果表明在中、小来流攻角(2°及0.6°)的情况下尾缘射流及边界层抽吸能够提高升阻比,推进效率可超过80%;而在大来流攻角(4°)情况下射流偏转角增大使翼型的阻力大幅上升,对气动性能和推进效率产生极为不利的影响.
- 分布式动力 /
- 尾缘射流 /
- 边界层抽吸 /
- 计算流体动力学 /
- 推进效率
Abstract: In order to study the influence of boundary layer ingestion on airframe aerodynamic performance and propulsion efficiency of the distributed propulsion system with trailing edge jet, a two-dimensional airfoil with trailing edge jet and boundary layer ingestion, modeling the airframe, was studied numerically to discuss the influence of incoming angle of attack, jet angle and boundary layer ingestion on aerodynamic performance and propulsion efficiency. Some suggestions on design and application of the distributed propulsion system were carried out. Results show that trailing edge jet and boundary layer ingestion are able to improve the lift-drag ratio at medium/small incoming angle of attack (2° and 0.6°). Propulsion efficiency is able to reach the level over 80%. However, drag of airfoil rises significantly at high incoming angle of attack (4°) with jet angle increasing, resulting in adverse impact on both aerodynamic performance and propulsion efficiency.
- distributed propulsion /
- trailing edge jet /
- boundary layer ingestion /
- computational fluid dynamics /
- propulsive efficiency

HTML

参考文献(18)

[1]	Sehra A K,Whitlow W.Propulsion and power for 21st century aviation[J].Progress in Aerospace Sciences,2004,40(4):199-235.
[2]	Gohardani A S,Doulgeris G,Singh R.Challenges of future aircraft propulsion:a review of distributed propulsion technology and its potential application for the all electric commercial aircraft[J].Progress in Aerospace Sciences,2011,47(5):369-391.
[3]	Ko A,Leifsson L T,Schetz J A,et al.MDO of a blended-wing-body transport aircraft with distributed propulsion[R].AIAA-2003-6732,2003.
[4]	Kim H D,Brown G V,Felder J L.Distributed turbo-electric propulsion for hybrid wing body aircraft[C]//Proceedings of 2008 International Powered Lift Conference.London:Royal Aeronautical Society,2008:1-11.
[5]	Ko A,Schetz J A,Mason W H.Assessment of the potential advantages of distributed-propulsion for aircraft[R].International Society for Air Breathing Engines, ISABE Paper 2003-1094,2003.
[6]	Manti Dč-Lugo V,Doulgeris G,Gohardani A,et al.Computational analysis of the aerodynamic performance of a jet-flap airfoil in transonic flow[J].Journal of Aerospace Engineering,2012,226(6):664-678.
[7]	Schetz J A,Hosder S,Dippold Ⅲ V,et al.Propulsion and aerodynamic performance evaluation of jet-wing distributed propulsion[J].Aerospace Science and Technology,2010,14(1):1-10.
[8]	Schetz J A,Hosder S,Walker J,et al.Numerical studies of jet-wing distributed propulsion flow fields[R].International Society for Air Breathing Engines, ISABE Paper 2005-1123,2005.
[9]	Felder J L,Kim H D,Brown G.Turboelectric distributed propulsion engine cycle analysis for hybrid-wing-body aircraft[R].AIAA-2009-1132,2009.
[10]	Liebeck R H.Design of the blended wing body subsonic transport[J].Journal of Aircraft,2004,41(1):10-25.
[11]	Qin N,Vavalle A,Le Moigne A,et al.Aerodynamic considerations of blended wing body aircraft[J].Progress in Aerospace Sciences,2004,40(6):321-343.
[12]	李晓勇,张淼,鲁素芬,等.翼身融合飞机的空气动力学研究进展[J].飞机设计,2007,27(2):1-9. LI Xiaoyong,ZHANG Miao,LU Sufen,et al.Advances in aerodynamics for blended-wing-body aircraft[J].Aircraft Design,2007,27(2):1-9.(in Chinese)
[13]	Ko A.The multidisciplinary design optimization of a distributed propulsion blended-wing-body aircraft[D].Blacksburg:Virginia Polytechnic Institute and State University,2003.
[14]	Dippold Ⅲ V F.Numerical assessment of the performance of jet-wing distributed propulsion on blended-wing-body aircraft[D].Blacksburg:Virginia Polytechnic Institute and State University,2003.
[15]	Spalart P,Allmaras S.A one-equation turbulence model for aerodynamic flows[R].AIAA 92-0439,1992.
[16]	Harris C D.Two-dimensional aerodynamic characteristics of the NACA 0012 airfoil in the Langley 8-foot transonic tunnel[R].NASA TM-81927,1981.
[17]	廉筱纯,吴虎.航空发动机原理[M].西安:西北工业大学出版社,2008.
[18]	Hill P G,Peterson C R.Mechanics and thermodynamics of propulsion[M].New York:Addison-Wesley,1992.
