航空发动机限寿件批准寿命适航验证方法

王大伟; 孙丹; 王伟; 邹田春

doi:10.13224/j.cnki.jasp.2015.03.011

航空发动机限寿件批准寿命适航验证方法

doi: 10.13224/j.cnki.jasp.2015.03.011

中国民航大学天津市民用航空器适航与维修重点实验室, 天津 300300

基金项目:

民航科技创新引导资金(MHRD20130221)

详细信息

作者简介:
王大伟(1975-),男,黑龙江齐齐哈尔人,讲师,博士,主要从事航空发动机适航审定技术研究.

中图分类号: V231.95
计量
- 文章访问数: 2014
- HTML浏览量: 74
- PDF量: 1008
- 被引次数: 0
出版历程
- 收稿日期: 2014-05-19
- 刊出日期: 2015-03-28

Methods of airworthiness verification for approved life of aero-engine limited-life parts

Tianjin Key Laboratory for Airworthiness and Maintenance of Civil Aircraft, Civil Aviation University of China, Tianjin 300300, China

摘要

摘要: 以传统的安全寿命法为基础,研究了航空发动机限寿件批准寿命适航验证流程和审定要素.以限寿件适航要求和咨询通告符合性方法为指导,借鉴航空发动机通用规范对关键件的定寿管理方法,从计算分析验证和试验验证给出限寿件批准寿命适航符合性验证的流程和方法.以典型的民用航空发动机为例研究了限寿件的判定准则.从限寿件结构危险点的判定方法、载荷谱的处理和应力分析给出了限寿件批准寿命计算分析验证的关键技术;从试验条件、试验温度方案、试验应力系数和散度系数的获取给出了限寿件批准寿命试验验证的关键技术.为航空发动机限寿件批准寿命适航审定提供指导方法,也为中国民用航空局编制航空发动机限寿件适航咨询通告提供参考依据.
- 航空发动机 /
- 限寿件 /
- 安全寿命 /
- 批准寿命 /
- 适航验证
Abstract: Based on the traditional safe life method, studies on verification process and certification factors of airworthiness of approved life for aero-engine life-limited parts were conducted. Airworthiness requirements and compliance of advisory circular for life-limited parts were taken as a guide, and management methods of life-limited parts life determination in the general specification for aero-engine were used as a reference. The process and methods of the airworthiness compliance verification were given by calculation analysis and experimental verification. The criterion of life-limited parts was studied using typical civil aero-engines. The key technologies of the calculation and analysis verification for approved life of life-limited parts were given from the criterion, the processing of load spectrum and stress analysis of their structural dangerous points. The key technologies of the experimental verification were given by obtaining the experimental conditions, scheme of experimental temperature, experimental overstress factor and scatter factor. A method of guidance is provided for the airworthiness certification of approved life for aero-engine life-limited parts. The proposed methods provide an important reference for Civil Aviation Administration of China to draw up airworthiness advisory circular of aero-engine life-limited parts.
- aero-engine /
- life-limited parts /
- safe life /
- approved life /
- airworthiness verification

HTML

参考文献(16)

[1]	王大伟,苗学问,洪杰.某发动机涡轮叶片使用寿命可靠性分析[J].北京航空航天大学学报,2006,32(8):903-907. WANG Dawei,MIAO Xuewen,HONG Jie.Reliability lifetime analysis of the turbine blade of turbofan engine[J].Journal of Beijing University of Aeronautics and Astronautics,2006,32(8):903-907.(in Chinese)
[2]	杨俊,李承彬,谢寿生.涡轮盘多轴低循环疲劳寿命预测及试验验证[J].航空动力学报,2011,26(10):2220-2226. YANG Jun,LI Chengbin,XIE Shousheng.Multiaxial low cycle fatigue prediction and test verification for turbine disk[J].Journal of Aerospace Power,2011,26(10):2220-2226.(in Chinese)
[3]	牟园伟,陆山.轮盘低周疲劳概率寿命预估模型[J].推进技术,2012,33(2):288-292. MU Yuanwei,LU Shan.Low cycle fatigue probabilistic life prediction models for fan disk[J].Journal of Propulsion Technology,2012,33(2):288-292.(in Chinese)
[4]	US Department of Transportation,Federal Aviation Administration.CFR14 Part 33 airworthiness standards aircraft engines[S].Washington DC:FAA,2013:34-35.
[5]	US Department of Transportation,Federal Aviation Administration.Advisory circular 33.70-1 Guidance material for aircraft engine life-limited parts:requirements[S].Washington DC:FAA,2009.
[6]	US Department of Transportation,Federal Aviation Administration.Advisory circular 33.70-2 Damage tolerance of hole features in high-energy turbine engine rotors[S].Washington DC:FAA,2009.
[7]	US Department of Transportation,Federal Aviation Administration.Advisory circular 33.14-1 Damage tolerance for high energy turbine engine rotors[S].Washington DC:FAA,2001.
[8]	US Department of Transportation,Federal Aviation Administration.Advisory circular 33.75-1A Guidance material for 14CFR 33.75,safety analysis[S].Washington DC:FAA,2007.
[9]	European Aviation Safety Agency.CS-E Certification specification for engine[S].Koeln:European Aviation Safety Agency,2010:15-16.
[10]	中国人民解放军总装备部.GJB241A-2010 航空涡轮喷气和涡轮风扇发动机通用规范[S].北京:中国人民解放军总装备部,2010:23-28.
[11]	中国航空工业总公司.HB/Z281-95 航空发动机故障模式、影响及危害性分析指南[S].北京:航空工业出版社,1996:21-25.
[12]	UK Ministry of Defence.DEF STAN 00-970 Design and airworthiness requirements for service aircraft:Part 11 engines[S].London:UK Ministry of Defence,2006:A1-23.
[13]	US Department of Defense.JSSG 2007B Joint service specification guide engines,aircraft,turbine[S].Washington DC:US Department of Defense,2008:252-253.
[14]	US Department of Defense.JSGS 87231A Joint services guide specification,engines,aircraft,turbine[S].Washington DC:US Department of Defense,1995:308-309.
[15]	US Department of Defense.MIL-E-5007E Engines aircraft turbojet and turbofan general specification[S].Washington DC:US Department of Defense,1983:124-126.
[16]	US Department of Defense.MIL-HDBK-1783B Engine structural integrity program[S].Washington DC:US Department of Defense,2004:134-135.
