基于能量模型的三维穿透裂纹扩展研究

高潮; 伍黎明; 何宇廷; 张腾; 侯波

doi:10.13224/j.cnki.jasp.2015.03.014

基于能量模型的三维穿透裂纹扩展研究

doi: 10.13224/j.cnki.jasp.2015.03.014

空军工程大学航空航天工程学院, 西安 710038

基金项目:

国家自然科学基金(51201182)

详细信息

作者简介:
高潮(1986-),男,陕西咸阳人,博士生,主要从事飞机结构可靠性与安全性研究.

中图分类号: V216.3
计量
- 文章访问数: 1275
- HTML浏览量: 76
- PDF量: 719
- 被引次数: 0
出版历程
- 收稿日期: 2014-05-22
- 刊出日期: 2015-03-28

Study on three-dimensional through-thickness crack growth based on energy model

Aeronautics and Astronautics Engineering College, Air Force Engineering University, Xi'an 710038, China

摘要

摘要: 利用能量释放率与应力强度因子的关系,给出了裂纹尖端的有效能量释放率;裂纹稳定扩展时有效能量释放率恰好等于裂纹扩展阻力,利用裂纹尖端前沿各点的有效能量释放率相等关系,提出了一种基于能量模型的三维穿透裂纹扩展形貌计算方法,可以计算不同厚度试样的三维穿透裂纹扩展形貌,并通过不同厚度单侧裂纹板的有限元仿真计算和试验进行了验证.仿真与试验结果表明:利用基于能量模型的三维穿透裂纹扩展形貌计算方法可以确定三维结构的裂纹扩展形貌;随着单侧裂纹板厚度的增加,裂纹尖端“隧道效应”消失,裂纹扩展形貌转变为“马鞍”形;试样自由面处的裂纹扩展速率要小于中面处的裂纹扩展速率.
- 能量释放率 /
- 应力强度因子 /
- 三维穿透裂纹 /
- 裂纹扩展形貌 /
- 三轴应力约束
Abstract: The effective energy release rate at crack tip was given by using the relation between energy release rate and stress strength factor. The effective energy release rate was equal to crack growth resistance at the crack growth, and the calculation method of three-dimensional through-thickness crack growth profile based on energy model was presented according to the equality relation of effective energy release rate for the crack tip front edge; the three-dimensional through-thickness crack growth profile of different thickness specimens could be calculated by using this method, and the finite element simulation and tests for single edge crack plates of different thickness were conducted to validate the calculation method. The simulation and test results show that the method of three-dimensional through-thickness crack growth profile based on energy model can be used to calculate crack growth profile of three-dimensional structures. The "crack tunneling" of crack tip disappeares when the thicknesses of single edge crack plates increase, and the crack growth profile turns into "saddle shape". The crack growth rate at specimen surface is smaller than crack growth rate at specimen middle face.
- energy release rate /
- stress strength factor /
- three-dimensional through-thickness crack /
- crack growth profile /
- tri-axial stress constraint

HTML

参考文献(18)

[1]	涂文锋.16MnR钢疲劳裂纹扩展形貌和扩展路径试验研究与数值模拟[D].杭州:浙江工业大学,2009. TU Wenfeng.Experimental study and modeling of fatigue crack growth profile and cracking path for 16MnR steel[D].Hangzhou:Zhejiang University of Technology,2009.(in Chinese)
[2]	金江,盛季生.稳态裂纹扩展前缘形态的研究[J].工程力学,2005,22(增刊):62-66. JIN Jiang,SHENG Jisheng.A study of configuration of propagating crack front[J].Engineering Mechanics,2005,22(suppl.):62-66.(in Chinese)
[3]	Kwon S W,Sun C T.Characteristics of three-dimensional stress fields in plates with a through-the-thickness crack[J].International Journal of Fracture,2000,104(3):289-314.
[4]	Branco R,Antunes F V.Finite element modeling and analysis of crack shape evolution in mode:Ⅰ fatigue middle cracked tension specimens[J].Engineering Fracture Mechanics,2008,75(10):3020-3037.
[5]	Branco R,Rodrigues D M,Antunes F V.Influence of through-thickness crack profile on plasticity induced crack closure[J].Fatigue & Fracture of Engineering Materials & Structures,2008,31:209-220.
[6]	何宇廷,傅祥炯.铝合金CCT试样裂纹扩展三维尺寸效应金相分析[J].空军工程大学学报:自然科学版,2002,3(2):5-8. HE Yuting,FU Xiangjiong.Study of three-dimensional effect on crack of CCT aluminium alloy specimens by fractograph analysis[J].Journal of Air Force Engineering University:Natural Science Edition,2002,3(2):5-8.(in Chinese)
[7]	Klingbeil N W.A total dissipated energy theory of fatigue crack growth in ductile solids[J].International Journal of Fatigue,2003,25(2):117-128.
[8]	Fu D,Zhang L,Cheng J.An energy-based approach for fatigue crack growth[J].Key Engineering Materials,2006,324/325:379-382.
[9]	李锋.航空结构材料疲劳寿命预测模型研究[D].西安:空军工程大学,2007. LI Feng.Research on fatigue life prediction model for aeronautical structural materials[D].Xi'an:Air Force Engineering University,2007.(in Chinese)
[10]	HE Yuting,LI Feng,FAN Chaohua.An effective energy criterion on fatigue crack growth of metal materials[J].Key Engineering Materials,2007,353/354/355/356/357/358:85-88.
[11]	GUO Wanlin.Elastoplastic three-dimensional crack border field:Ⅲ fracture parameters[J].Engineering Fracture Mechanics,1995,51(1):51-57.
[12]	张田忠.三维破坏力学和纳米力学中的关键问题研究[D].西安:西安交通大学,2001. ZHANG Tianzhong.Research on some key problems in three-dimensional failure mechanics and nanomechanics[D].Xi'an:Xi'an Jiaotong University,2001.(in Chinese)
[13]	何宇廷.三维断裂准则及疲劳裂纹扩展模型研究[D].西安:西北工业大学,1997. HE Yuting.A study of three dimensional fracture criteria and fatigue crack propagation model[D].Xi'an:Northwestern Polytechnical University,1997.(in Chinese)
[14]	Newman J C.A crack opening stress equation for fatigue crack growth[J].International Journal of Fracture,1984,24(4):131-135.
[15]	American Society of Testing Materials.E561-08ε1 Standard test method for K-R curve determination[S].West Conshohocken,US:American Society of Testing Materials (ASTM),2009.
[16]	Chermahini R G,Shivakumar K N,Newman J C,et al.Three-dimensional aspects of plasticity-induced fatigue crack closure[J].Engineering Fracture Mechanics,1989,34(2):393-401.
[17]	WU Zhixue.On the through-thickness crack with a curve front in center-cracked tension specimens[J].Engineering Fracture Mechanics,2006,73(7):2600-2613.
[18]	American Society of Testing Materials.STP 410 Plane strain fracture toughness of high strength metallic materials[S].West Conshohocken,US:American Society of Testing Materials (ASTM),1966.
