迎风面三维积冰过程中水膜流动的计算方法

曹广州; 吉洪湖; 斯仁

doi:10.13224/j.cnki.jasp.2015.03.019

迎风面三维积冰过程中水膜流动的计算方法

doi: 10.13224/j.cnki.jasp.2015.03.019

1. 南京航空航天大学无人机研究院, 南京 210016;
2. 南京航空航天大学能源与动力学院, 南京 210016

基金项目:

中央高校基本科研业务费专项资金(NS2015096)

详细信息

作者简介:
曹广州(1981-),男,江苏赣榆人,助理研究员,博士,主要从事航空发动机应用和传热传质研究.

中图分类号: V231.1
计量
- 文章访问数: 1473
- HTML浏览量: 86
- PDF量: 799
- 被引次数: 0
出版历程
- 收稿日期: 2014-07-01
- 刊出日期: 2015-03-28

Computational methodology of water film flow in three-dimensional ice accretion on upwind surface

1. Research Institute of Unmanned Aircraft, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China;
2. College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 对影响迎风面三维积冰过程的冰层表面水膜流动进行分析,建立描述其流动的数学模型,引入在流动前锋下游预设薄水膜的方法处理其在表面干区的流动推进过程,提出超过临界厚度的水膜被吹除的方法处理角状冰下游局部水膜被吹离表面的现象.通过对翼型-平板结构中翼型上的冰形对比和水膜流动规律分析,验证了该水膜流动数学模型的合理性和计算方法的可行性.研究表明:与Messinger模型相比,积冰模型中引入水膜流动后,可以较好地模拟三维明冰积冰,同时明冰极限的模拟结果也更接近试验值;冰层表面的水膜厚度约为10^-5m,流动速度约为10^-2m/s.
- 三维积冰 /
- 水膜流动 /
- 数学模型 /
- 流动前锋 /
- 水膜吹离
Abstract: The thin water film flow on the ice layer affecting the three-dimensional (3-D) ice accretion on the upwind surface was analyzed. A mathematic model for simulating the flow was developed. A very thin precursor water film beyond the contact line was introduced to deal with the film flow on the dry surface. To treat with the phenomenon that some water film was blew off the surface behind the ice horn, a computational methodology was introduced that the top part of the water film which exceeding the critical height was blew away. The ice shape contrast and water film flow analysis on the airfoil-plane indicates the rationality of the mathematic model and the feasibility of the computational methodology. The research indicates: icing model involving the water film flow can simulate 3-D glaze ice well and provide the ice layer boundary closer to the experimental result than Messinger model. The water film height on the ice layer is about 10^-5m and its velocity is about 10^-2m/s.
- three-dimensional ice accretion /
- water film flow /
- mathematic model /
- flow contact line /
- film blow off
