机匣造型设计对涡轮叶尖泄漏流损失的影响

魏佐君; 乔渭阳; 时培杰; 赵磊

doi:10.13224/j.cnki.jasp.2015.03.024

机匣造型设计对涡轮叶尖泄漏流损失的影响

doi: 10.13224/j.cnki.jasp.2015.03.024

西北工业大学动力与能源学院, 西安 710072

详细信息

作者简介:
魏佐君(1986-),男,江西赣州人,博士生,研究领域为高负荷涡轮端区流动机理及损失控制.stiven_wei@yahoo.com

中图分类号: V231
计量
- 文章访问数: 1777
- HTML浏览量: 171
- PDF量: 764
- 被引次数: 0
出版历程
- 收稿日期: 2013-10-24
- 刊出日期: 2015-03-28

Effect of contoured casing design on tip-leakage loss in a turbine

School of Power and Energy, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 针对带叶尖间隙的T106高负荷低压涡轮叶栅,基于耦合了Langtry-Menter转捩模型的Menter's SST (shear stress transport)两方程模型,数值研究了涡轮叶片全机匣造型和部分机匣造型对叶尖泄漏损失的影响.计算结果表明:机匣造型设计的引入重新组织了叶尖区域内的涡系结构及损失成分,且这一改变明显受到机匣造型圆弧高度的影响;叶尖间隙内靠近压力面分离泡的展向尺度增大,分离泡形成的堵塞效应降低了叶尖泄漏流动能;而部分机匣造型处理可以缓解叶片通道内因局部扩张而引起的横向流动,使得出口展向损失减小区域进一步扩大,从而造成叶栅出口损失的明显下降;相对原始机匣,最大降幅可达6.1%.间隙敏感性分析表明,两种机匣造型在一定的间隙范围内能够有效降低叶尖泄漏流损失,而且部分机匣造型具有更宽的有效间隙范围和更大损失减小量.
- 涡轮 /
- 机匣造型 /
- 轴对称机匣处理 /
- 叶尖泄漏流 /
- 叶尖泄漏流损失控制
Abstract: Based on Menter's SST (shear stress transport) turbulence model coupled with Langtry-Menter transition model, the effects of fully contoured casing and partial contoured casing on the tip-leakage loss was numerically investigated in the highly-loaded low-pressure turbine cascade T106 with tip clearance. The results show that: the contoured casing design changes the vortex structures and loss components in tip region, and such effect is obviously impacted by the height of contoured casing arc. The increase of the spanwise size of the pressure side/tip junction separation bubble leads to stronger blocking effect, thus reducing the kinetic energy of the tip-leakage flow. Partial contoured casing could reduce the additional cross flow near the endwall caused by the local divergence of blade passage, and lead to larger spanwise loss reduction area at outlet. Therefore the cascade outlet loss is reduced essentially, and the maximum is up to 6.1% compared with original casing. The tip-gap size sensitivity analysis shows that both kinds of contoured casings can effectively reduce the tip-leakage loss in a certain. Moreover, the partial contoured casing achieves broader effective tip-gap size and lower loss.
- turbine /
- contoured casing /
- axisymmetric-casing treatment /
- tip-leakage flow /
- tip-leakage loss control

HTML

参考文献(20)

[1]	Denton J D.The 1993 IGTI scholar lecture:loss mechanisms in turbomachines[J].Journal of Turbomachinery,1993,115(4):621-656.
[2]	Booth T C.Importance of tip clearance flows in turbine design[R].Von Karman Instite,VKI LS 1985-05,1985.
[3]	Yamamoto A.Interaction mechanisms between tip leakage flow and the passage vortex in a linear turbine rotor cascade[J].Journal of Turbomachinery,1988,110(3):329-338.
[4]	Moore J,Tilton J S.Tip leakage flow in a linear turbine cascade[J].Journal of Turbomachinery,1988,110(1):18-26.
[5]	Bindon J P.The measurement and formation of tip clearance loss[J].Journal of Turbomachinery,1989,111(4):257-263.
[6]	Yaras M I,Sjolander S A.Prediction of tip-leakage losses in axial turbines[J].Journal of Turbomachinery,1992,114(1):204-210.
[7]	Heyes F J G,Hodson H P.Measurement and prediction of tip clearance flow in linear turbine cascades[J].Journal of Turbomachinery,1993,115(3):376-382.
[8]	Key N L,Arts T.Comparison of turbine tip leakage flow for flat tip and squealer tip geometries at high-speed conditions[J].Journal of Turbomachinery,2006,128(2):213-220.
[9]	Krishnababu S K,Dawes W N,Hodson H P,et al.Aero-thermal investigations of tip leakage flow in axial flow turbines:Part Ⅱ effect of relative casing motion[R].ASME Paper GT2007-27957,2007.
[10]	Nho Y C,Park J S,Lee Y J,et al.Effects of turbine blade tip shape on total pressure loss and secondary flow of a linear turbine cascade[J].International Journal of Heat and Fluid Flow,2012,33(1):92-100.
[11]	Wisler D C,Beacher B F.Improved compressor performance using recessed clearance (trenches) over the rotor[R].AIAA 86-1745,1986.
[12]	Offenburg L S,Fischer J D,Hoek T.An experimental investigation of turbine case treatments[R].AIAA 87-1919,1987.
[13]	罗华玲,乔渭阳,许开富.一种大负荷低压涡轮叶型的气动性能[J].航空动力学报,2009,24(12):2711-2718. LUO Hualing,QIAO Weiyang,XU Kaifu.Aerodynamic performance of a highly-loaded low-pressure turbine profile[J].Journal of Aerosapce Power,2009,24(12):2711-2718.(in Chinese)
[14]	Krishnababu S,Newton P J,Dawes W N,et al.Aerothermal investigations of tip leakage flow in axial flow turbines:Part Ⅰ effect of tip geometry and tip clearance gap[R].ASME Paper GT2007-27954,2007.
[15]	Greitzer E M,Tan C S,Graf M B.Internal flow:concepts and applications[M].New York:Cambridge University Press,2004.
[16]	Hilderbrandt T,Fottner L.A numerical study of the influence of grid refinement and turbulence modeling on the flow inside a highly loaded turbine cascade[J].Journal of Turbomachinery,1999,121(4):709-716.
[17]	Duden A,Fottner L.Influence of taper,Reynolds number and Mach number on the secondary flow field of a highly loaded turbine cascade[J].Journal of Power and Energy,1997,211(4):309-320.
[18]	Jeong J,Hussain F.On the identification of a vortex[J].Journal of Fluid Mechanics,1995,285:69-94.
[19]	Wang H P,Olson S J,Goldstein R J,et al.Flow visualization in a linear turbine cascade of high performance turbine blades[J].Journal of Turbomachinery,1997,119(1):1-8.
[20]	Lattime S B,Steinetz B M.Turbine engine clearance control systems:current practices and future directions[R].AIAA-2002-3790,2002.
