喷注壁面楔状流层流边界层速度与温度相似解

赵国昌; 杜霞; 宋丽萍; 单龙; 孔敬儒; 彭大维

doi:10.13224/j.cnki.jasp.2015.07.001

喷注壁面楔状流层流边界层速度与温度相似解

doi: 10.13224/j.cnki.jasp.2015.07.001

1. 沈阳航空航天大学航空航天工程学部 (院), 沈阳 110136;
2. 沈阳航空航天大学科学技术协会, 沈阳 110136;
3. 沈阳航空航天大学航空航天工程学部 (院) 辽宁省航空推进系统先进测试技术重点实验室, 沈阳 110136

基金项目:

航空科学基金(20131954004)

辽宁省攀登学者基金(20132015)

详细信息

作者简介:
赵国昌(1964-),男,北京人,教授、博士生导师,博士,主要从事航空动力工程中的流动传热及热管理研究.

中图分类号: V211.1⁺9
计量
- 文章访问数: 1188
- HTML浏览量: 137
- PDF量: 834
- 被引次数: 0
出版历程
- 收稿日期: 2014-12-21
- 刊出日期: 2015-07-28

Velocity and temperature similarity solutions of wedge flow laminar boundary layer with wall injection

1. Faculty of Aerospace Engineering, Shenyang Aerospace University, Shenyang 110136, China;
2. Association of Science and Technology, Shenyang Aerospace University, Shenyang 110136, China;
3. Liaoning Key Laboratory of Advanced Measurement and Test Technology for Aviation Propulsion System, Faculty of Aerospace Engineering, Shenyang Aerospace University, Shenyang 110136, China

摘要

摘要: 建立了壁面有喷注的楔状流层流边界层冷却数学模型,求解经相似变换得到的描述无量纲流函数和无量纲温度的常微分方程,获得了楔状流层流边界层无量纲速度和温度的相似解,给出了考虑壁面喷注边界条件的形式简洁、物理意义明确的无量纲流函数拟合式;用Runge-Kutta法求解无量纲速度与温度的常微分方程,获得了壁面有喷注的楔状流层流边界层无量纲速度和温度随楔形角、吹风参数、冷却介质温度的变化规律.通过计算0°,18°和36°楔形角的楔状流层流边界冷却速度与温度分布得到以下结论:楔状流速度边界层和温度边界层厚度都随楔形角的增大而变小,随着吹风参数的增大而增大;当冷却介质温度越低、吹风参数越小、楔形角越大时,靠近壁面处楔状流层流边界层内温度梯度越大.
- 楔状流 /
- 层流边界层 /
- 喷注壁面 /
- 相似解 /
- 吹风参数
Abstract: The mathematical model of the wedge flow laminar boundary layer with wall injection boundary was established. Based on this model, the similarity solutions of dimensionless velocity and temperature distribution in the laminar boundary layer were obtained by solving the ordinary differential equations of the dimensionless stream function and dimensionless temperature. The ordinary differential equations were derived through similarity transformation from the partial differential equations describing the flow and heat transfer of wedge flow laminar boundary layer with wall injection. The curve fitting of dimensionless stream function derived takes into account the wall injection effect of cooling gas. The Runge-Kutta method was used to solve the ordinary differential equations of dimensionless stream function and dimensionless temperature in order to analyze the variations in the dimensionless velocity and temperature distributions in the wedge flow laminar boundary layer with wall injection with changes in wedge angle, blowing parameter, and cooling medium temperature. The results of the dimensionless velocity and temperature similarity solutions in the laminar boundary layer of wedge flows with wedge angles of 0°, 18° and 36° show that both the velocity boundary layer thickness and temperature boundary layer thickness of the laminar wedge flows with wall injection enlarge with the increase of blowing parameter and reduce with the increase of wedge angle; the boundary layer temperature gradient near the wall is larger with lower cooling media temperatures, smaller blowing parameters, and larger wedge angles.
- wedge flow /
- laminar boundary layer /
- wall injection /
- similarity solutions /
- blowing parameter

HTML

参考文献(17)

[1]	Ford B.Ellipsoidal bubble diffusion in a turbulent shear layer[J].International Journal of Multiphase Flow,2000,26(3):503-516.
[2]	Glass D E,Arthur D.Numerical analysis of convection transpiration cooling[R].NASA/TM-1999-209828,1999.
[3]	Kays W M,Crawford M E.Convective heat and mass transfer[M].2nd ed.New York:McGraw Hill,1980.
[4]	时骏祥.发散冷却基础问题的理论研究[D].合肥:中国科学技术大学,2009. SHI Junxiang.Theoretic investigation on basic problems of transpiration cooling[D].Hefei:University of Science and Technology of China,2009.(in Chinese)
[5]	孟丽燕,姜培学,蒋方帅,等.孔隙及热流的非均匀性对发散冷却的影响[J].清华大学学报:自然科学版,2006,46(2):230-233. MENG Liyan,JIANG Peixue,JIANG Fangshuai,et al.Influence of porosity and heat flux non uniformities on transpiration cooling[J].Journal of Tsinghua University:Science and Technology,2006,46(2):230-233.(in Chinese)
[6]	Choi S H,Scotti S J,Song K D,et al.Transpiration cooling of a scramjet engine combustion chamber[R].AIAA 97-2576,1997.
[7]	Landis J A,Bowman J W.Numerical study of a transpiration cooled rocket nozzle[R].AIAA 96-2580,1996.
[8]	Lacy B P,Wilson D E,Varghese P L.Dissociative cooling effect on stagnation heat transfer of gas mixture injection [J].Journal of Spacecraft and Rockets,1995,32(5):777-782.
[9]	贾闪,王晓春,王建华.具有发散冷却功能的曲面结构边界层特实验和数值研究[J].航空动力学报,2010,25(2):336-342. JIA Shan,WANG Xiaochun,WANG Jianhua.Experimental and numerical investigations of boundary layer performances on curve structure surfaces with transpiration cooling function[J].Journal of Aerospace Power,2010,25(2):336-342.(in Chinese)
[10]	金韶山,姜培学,苏志华.钝体头锥发汗冷却对流换热实验研究[J].工程热物理学报,2009,30(6):1002-1004. JIN Shaoshan,JIANG Peixue,SU Zhihua.Experimental investigation of convection heat transfer in transpiration cooling for blunt nosecone[J].Journal of Engineering Thermophysics,2009,30(6):1002-1004.(in Chinese)
[11]	王补宣.工程传热与传质[M].北京:科学出版社,2002.
[12]	时骏祥,王建华.发散冷却最小冷却介质注射量的数值研究[J].航空动力学报,2007,22(2):223-227. SHI Junxiang,WANG Jianhua.A numerical investigation of the minimum coolant injection rate for transpiration cooling[J].Journal of Aerospace Power,2007,22(2):223-227.(in Chinese)
[13]	熊宴斌,姜培学,祝银海,等.冷端边界条件对发汗冷却解析解的影响[J].清华大学学报:自然科学版,2013,53(10):1452-1458. XIONG Yanbin,JIANG Peixue,ZHU Yinhai,et al.Effects of coolant side boundary condition on analytical transpiration cooling solutions[J].Journal of Tsinghua University:Science and Technology,2013,53(10):1452-1458.(in Chinese)
[14]	杨强生,蒲保荣.高等传热传质学[M].上海:上海交通大学出版社,1996.
[15]	陶智,徐国强.航空发动机燃烧学[M].北京:北京航空航天大学出版社,2005.
[16]	杨强生.对流传热与传质[M].北京:高等教育出版社,1985.
[17]	赵国昌,杜霞,宋丽萍,等.亚/超音速楔状流层流边界层温度数值解与拟合解[J].航空动力学报,2014,29(12):2633-2643. ZHAO Guochang,DU Xia,SONG Liping,et al.The numerical solution and fitting solution of Temperature in laminar boundary layer of subsonic and supersonic wedge flow[J].Journal of Aerospace Power,2014,29(12):2633-2643.(in Chinese)
