连续旋转爆轰发动机参数特性的三维数值模拟

武丹; 刘岩; 王健平

doi:10.13224/j.cnki.jasp.2015.07.006

连续旋转爆轰发动机参数特性的三维数值模拟

doi: 10.13224/j.cnki.jasp.2015.07.006

武丹^1,2,
刘岩^1,2,
王健平^1,2

1. 北京大学工学院燃烧推进中心和应用物理技术研究中心, 北京 100871;
2. 北京大学工学院湍流与复杂系统国家重点实验室, 北京 100871

详细信息

作者简介:
武丹(1987-),女,河南商丘人,博士生,主要从事计算流体力学、爆轰波的数值模拟研究.

中图分类号: V430;O381
计量
- 文章访问数: 1546
- HTML浏览量: 113
- PDF量: 806
- 被引次数: 0
出版历程
- 收稿日期: 2014-01-24
- 刊出日期: 2015-07-28

Three-dimensional numerical simulation of the parametric properties of continuously rotating detonation engine

WU Dan^1,2,
LIU Yan^1,2,
WANG Jian-ping^1,2

1. Center for Combustion and Propulsion and Center for Application Physics Technology, College of Engineering, Peking University, Beijing 100871, China;
2. State Key Laboratory of Turbulence and Complex System, College of Engineering, Peking University, Beijing 100871, China

摘要

摘要: 采用一步化学反应模型,基于任意坐标系下Euler控制方程,对连续旋转爆轰发动机(CRDE)进行了三维数值模拟研究, 详细分析了来流总压对CRDE参数特性的影响.研究发现:随着来流总压的增大,爆轰波峰值随之增大,但是燃烧室头部Laval型喷注段的壅塞比基本不变.不同来流总压下,可燃气体在燃烧室头部均以亚声速入射.随着来流总压的增大,燃烧室内流场的平均压强增大,但是其平均轴向流速基本不变.CRDE的流量、推力和比冲均随着来流总压的增加而变大;但是,不同来流总压下,CRDE的流量与Laval型喷注段最大流量之比不变,并且此比值约等Laval型喷注段的壅塞比.Laval型喷注段最大流量与来流总压成正比,因此以上分析从理论上进一步解释了CRDE的流量与来流总压成正比的原因.
- 连续旋转爆轰发动机 /
- 参数特性 /
- 来流总压 /
- 三维数值模拟 /
- 壅塞比 /
- 平均轴向流速 /
- 推进性能
Abstract: Based on Euler equations with one-step chemical reaction model in generalized coordinates, three-dimensional numerical simulation of the continuously rotating detonation engine (CRDE) were performed to investigate the effect of inlet total pressure on its parametric properties. It is found that the peak value of the detonation wave increases with the inlet total pressure; however, the choking ratio of the injection Laval nozzle along the head end is not influenced by it. Across the whole head end of CRDE, combustible gas is injected into the combustion chamber subsonically for different inlet total pressures. With the increase of inlet total pressure, the average pressure inside the chamber increases obviously, but the average axial velocity changes little. The mass flux, force and specific impulse of CRDE increase with the inlet total pressure. However, the ratio of the mass flux of CRDE to the maximum mass flux of the injection Laval nozzle remains the same under different inlet total pressures, almost equal to the choking ratio of the injection Laval nozzle. As the maximum mass flux of the injection Laval nozzle has a linear growth with the inlet total pressure, the above analysis provides a theory explanation about why the mass flux of CRDE increases linearly with the inlet total pressure.
- continuously rotating detonation engine /
- parametric properties /
- inlet total pressure /
- three-dimensional numerical simulation /
- choking ratio /
- averaged axial velocity /
- propulsive performance

HTML

参考文献(20)

[1]	Bratkovich T E,Aarnio M J,Willimams J T,et al.An introduction to pulse detonation rocket engineers(PDREs)[R].AIAA 97-2724,1997.
[2]	Bykovskii F A,Vedernikov E F.Continuous detonation of a subsonic flow of propellant[J].Combustion Explosion and Shock Waves,2003,39(3):323-334.
[3]	Bykovskii F A,Zhdan S A,Vedernikov E F.Continuous spin detonations[J].Journal of Propulsion and Power,2006,22(6):1204-1216.
[4]	Schwer D,Kailasanath K.Numerical investigation of physics of rotating-detonation-engines[J].Proceedings of the Combustion Institute,2011,33(2):2195-2201.
[5]	Davidenko D M.Numerical simulation of H₂/O₂ continuous spin detonation with a detailed chemical mechanism[R].California,US:21st International Colloquium on the Dynamics of Explosions and Reactive Systems,2011.
[6]	Hishida M,Fujiwara T,Wolanski P.Fundamentals of rotating detonations[J].Shock Waves,2009,19(1):1-10.
[7]	Kindracki J,Wolanski P,Gut Z.Experimental research on the rotating detonation in gaseous fuels-oxygen mixtures[J].Shock Waves,2011,21(2):75-84.
[8]	王健平,石天一,王宇辉,等.连续旋转爆轰发动机的实验研究[C]//第十四届全国激波与激波管学术会议论文集.黄山:中国力学学会,2010:181-184.
[9]	SHAO Yetao,WANG Jianping.Change in continuous detonation wave propagation mode from rotation detonation to standing detonation[J].Chinese Physics Letter,2010,27(3):034705.1-034705.4.
[10]	邵业涛,王健平,唐新猛,等.连续旋转爆轰发动机流场三维数值模拟[J].航空动力学报,2010,25(8):1717-1722. SHAO Yetao,WANG Jianping,TANG Xinmeng,et al.Three-dimensional numerical simulation of continuous rotating detonation engine flowfields[J].Journal of Aerospace Power,2010,25(8):1717-1722.(in Chinese)
[11]	SHAO Yetao,LIU Meng,WANG Jianping.Continuous detonation engine and effects of different types of nozzle on its propulsion performance[J].Chinese Journal of Aeronautics,2010,23(6):647-652.
[12]	周蕊,王健平.连续旋转爆轰发动机热力学性质的数值模拟[J].航空动力学报,2011,26(1):16-24. ZHOU Rui,WANG Jianping.Numerical investigation of thermodynamic performance on continuously rotating detonation engines[J].Journal of Aerospace Power,2011,26(1):16-24.(in Chinese)
[13]	唐新猛,王健平,邵业涛.连续旋转爆轰波在无内柱圆筒内的数值模拟[J].航空动力学报,2013,28(4):792-799. TANG Xinmeng,WANG Jianping,SHAO Yetao.3-D simulation of rotating detonation wave in combustion chambers without inner wall[J].Journal of Aerospace Power,2013,28(4):792-799.(in Chinese)
[14]	刘世杰,林志勇,孙明波,等.旋转爆轰波发动机二维数值模拟[J].推进技术,2010,31(5):634-640. LIU Shijie,LIN Zhiyong,SUN Mingbo,et al.Two-dimensional numerical simulation of rotating detonation wave engine[J].Journal of Propulsion Technology,2010,31(5):634-640.(in Chinese)
[15]	Liu S J,Lin Z Y,Liu W D,et al.Experimental and three-dimensional numerical investigations on H₂/Air continuous detonation wave[J].Proceedings of the Institution of Mechanical Enginners:Part G Journal of Aerospace Engineering,2013,227(2):326-341.
[16]	姜孝海,范宝春,董刚,等.旋转爆轰流场的数值模拟[J].推进技术,2007,28(4):403-407. JIANG Xiaohai,FAN Baochun,DONG Gang,et al.Numerical investigation on the flow field of rotating detonation wave[J].Journal of Propulsion Technology,2007,28(4):403-407.(in Chinese)
[17]	ZHANG Xudong,FAN Baochun,PAN Zhenhua,et al.Experimental and numerical study on detonation propagating in an annular cylinder[J].Combustion Science and Technology,2012,184(10/11):1708-1717.
[18]	马虎,封锋,武晓松,等.压力条件对旋转爆震发动机的影响[J].弹道学报,2012,24(4):94-98. MA Hu,FENG Feng,WU Xiaosong,et al.Effect of pressure condition on rotating detonation engine[J].Journal of Ballistics,2012,24(4):94-98.(in Chinese)
[19]	Ma F H,Choi J Y,Yang V G.Propulsive performance of airbreathing pulse detonation engines[J].Journal of Propulsion and Power,2006,22(6):1188-1203.
[20]	武丹,王健平.粘性及热传导对于爆轰波的影响[J].应用力学学报,2012,29(6):630-635. WU Dan,WANG Jianping.Influences of viscosity and thermal conductivity on detonation waves[J].Journal of Applied Mechanics,2012,29(6):630-635.(in Chinese)
