Siren(旋笛式)激励系统的气动声学特性

丁志磊; 林宇震; 秦皓; 汤冠琼

doi:10.13224/j.cnki.jasp.2015.07.009

Siren(旋笛式)激励系统的气动声学特性

doi: 10.13224/j.cnki.jasp.2015.07.009

北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室, 北京 100191

详细信息

作者简介:
丁志磊(1989-),男,云南姚安人,硕士生,主要从事民用航空发动机燃烧不稳定性研究.

中图分类号: V231.2
计量
- 文章访问数: 1292
- HTML浏览量: 94
- PDF量: 775
- 被引次数: 0
出版历程
- 收稿日期: 2014-02-19
- 刊出日期: 2015-07-28

Aeroacoustic characteristic of siren incentive system

National Key Laboratory of Science and Technology on Aero-Engine Aero-thermodynamics, School of Energy and Power Engineering, Beijing University of Aeronautics of Astronautics, Beijing 100191, China

摘要

摘要: 基于siren(旋笛式)激励系统,理论推导了旋笛产生的非定常脉动速度和双传声器法获得的声质点振动速度之间的能量转换关系,并通过系统的气动声学特性实验考察了激励强度、频率、马赫数以及传感器间距对声质点振动速度的影响,验证了理论模型.结果表明:由旋笛产生的非定常脉动速度并不完全转换为声质点振动速度,这种转换关系主要与马赫数有关.且当流体为不可压缩气体,即马赫数小于0.3时,能量转换因子与马赫数的平方成正比,马赫数越大,能量转换因子越大,非定常流动转换为声能的效率越高.
- 旋笛式激励系统 /
- 气动声学特性 /
- 双传声器法 /
- 能量转换因子 /
- 燃烧不稳定性
Abstract: Based on siren incentive system, the energy transform relationship between unsteady flow fluctuation velocity brought by siren actuator and acoustic particle velocity got by the two-microphone technique was derived. And the effect of incentive intensity, frequency, Mach number and the sensor spacing on the acoustic particle velocity was studied through the aeroacoustic characteristic experiment, verifying the theoretical model. The results are as follows: acoustic particle velocity can't be fully converted by unsteady flow fluctuation velocity, the transform relationship between velocities mentioned above is related to Mach number. Under incompressible condition, Mach number less than 0.3, the energy transform factor is proportional to the square of Mach number, and the larger Mach number means, the larger energy transform factor, and the higher conversion efficiency of unsteady flow to acoustic energy.
- siren incentive system /
- aeroacoustic characteristic /
- two-microphone technique /
- energy transform factor /
- combustion instability

HTML

参考文献(18)

[1]	Lieuwen T C,Yang V.Combustion instabilities in gas turbine engines:operational experience,fundamental mechanisms and modeling[M].Reston:AIAA,2005:3-26.
[2]	Huang Y,Yang V.Dynamics and stability of lean-premixed swirl-stabilized combustion[J].Progress in Energy and Combustion Science,2009,35(4):293-364.
[3]	YI Tongxun,Santavicca D A.Flame transfer functions for liquid-fueled swirl-stabilized turbulent lean direct fuel injection combustion[J].Journal of Engineering for Gas Turbines and Power,2010,132(2):021506.1-021506.6.
[4]	Bellows B D,Bobba M K,Seitzman J M,et al.Nonlinear flame transfer function characteristics in a swirl-stabilized combustor[J].Journal of Engineering for Gas Turbines and Power,2007,129(4):954-961.
[5]	Lohrmann M,Büchner H,Zarzalis N,et al.Flame transfer function characteristics of swirl flames for gas turbine applications[R].ASME Paper GT-2003-38113,2003.
[6]	Schimek S,Moeck J P,Paschereit C O.An experimental investigation of the nonlinear response of an atmospheric swirl-stabilized premixed flame[R].ASEM Paper GT2010-22827,2010.
[7]	Schuermans B,Bellucci V,Guethe F,et al.A detailed analysis of thermo acoustic interaction mechanisms in a turbulent premixed flame[R].ASME Paper GT2004-53831,2004.
[8]	Pilatis N,Whiteman M,Madden P,et al.Forced combustion experiments on aero combustors[R].ASME Paper GT2011-45235,2011.
[9]	Eckstein J.On the mechanisms of combustion driven low-frequency oscillations in aero-engines[D].Munchen:Technischen Universitat Munchen,2004.
[10]	Peluso S,Quay B D,Lee J G,et al.Comparison between self-excited and forced flame response of an industrial lean premixed gas turbine injector[R].ASME Paper GT2011-46115,2011.
[11]	Schuermans B,Guyot D,Paschereit C O,et al.Thermoacoustic modeling of a gas turbine using transfer functions measured under full engine pressure[J].Journal of Engineering for Gas Turbines and Power,2010,132(11):111503.1-111503.9.
[12]	宁智轶,杜少辉,韩清凯,等.模拟叶片气激及涂层阻尼减振有效性研究[J].航空发动机,2013,39(5):14-17. NING Zhiyi,DU Shaohui,HAN Qingkai,et al.Study on validity of air-excited vibration and coating vibration damping of simulation lade[J].Aeroengine,2013,39(5):14-17.(in Chinese)
[13]	路斌,陈军.高声强流体动力式声源的研究现状与展望[J].石油机械,2002,30(4):45-48. LU Bin,CHEN Jun.Research situation of hydrodynamic high intensity sound source[J].China Petroleum Machinery,2002,30(4):45-48.(in Chinese)
[14]	LI Guoqiang,Gutmark E J.Geometry effects on the flow field and the spectral characteristcs of a triple annular swirler[R].ASME Paper GT-2003-38799,2003.
[15]	Accornero D,Caruggi M,Nilberto A,et al.Numerical and experimental investigations of combustion instability phenomena in gas turbine burners for heavy duty and aero-engine applications[R].ASME Paper GT-2011-46490,2011.
[16]	Bhayaraju U,Schmidt J,Kashinath K,et al.Effect of cooling liner on acoustic energy absorption and flame response [R].ASME Paper GT-2010-22616,2010.
[17]	杜功焕,朱哲民,龚秀芬.声学基础[M].2版.南京:南京大学出版社,2001.
[18]	乔渭阳.航空发动机气动声学[M].北京:北京航空航天大学出版社,2010.
