喷油方位参数对航空直齿轮喷油润滑过程的影响

王延忠; 牛文韬; 唐文; 郭梅; 李国权

doi:10.13224/j.cnki.jasp.2015.07.010

喷油方位参数对航空直齿轮喷油润滑过程的影响

doi: 10.13224/j.cnki.jasp.2015.07.010

1. 北京航空航天大学机械工程及自动化学院, 北京 100191;
2. 中国航空工业集团公司沈阳发动机设计研究所, 沈阳 110015

基金项目:

国家自然科学基金(51275020)

国家高技术研究发展计划(SS2012AA040104)

预研基金

详细信息

作者简介:
王延忠(1963-),男,辽宁沈阳人,教授、博士生导师,博士,主要从事传动摩擦学理论与应用技术、先进精密传动加工技术、空间啮合曲面数字加工理论和技术等方面研究工作.

中图分类号: V232.8
计量
- 文章访问数: 1404
- HTML浏览量: 83
- PDF量: 834
- 被引次数: 0
出版历程
- 收稿日期: 2014-02-28
- 刊出日期: 2015-07-28

Influence of spray orientation parameters on spray lubrication process of aero spur gears

1. School of Mechanical Engineering and Automation, Beijing University of Aeronautics and Astronautics, Beijing 100191, China;
2. Shenyang Engine Design and Research Institute, Aviation Industry Corporation of China, Shenyang 110015, China

摘要

摘要: 通过对航空直齿轮喷油润滑过程的深入分析,对影响齿轮啮合点润滑初始条件的喷油方位参数进行了系统的定义,并在此基础上建立了喷油润滑过程的计算流体动力学(CFD)模型,分别对喷油角度、喷油点位置以及喷油距离3个喷油方位参数的喷油润滑过程进行了计算,得到了齿轮不同啮合瞬时的射流状态,并对不同喷油方位参数下齿轮啮合过程中接触点入口处的油气率与气液总压变化规律进行了比较.结果表明:当采用啮入侧喷油润滑时,为了得到更好的润滑效果,应该使喷油嘴向主动轮偏离一个小的角度,同时使喷油点位置向啮入侧偏离,而对于喷油距离,则应视结构、工况综合考虑而定,但并不是一般认为的越近越好.
- 喷油角度 /
- 喷油点位置 /
- 喷油距离 /
- 计算流体动力学 /
- 油气率 /
- 气液总压
Abstract: Spray orientation parameters influencing lubrication initial conditions of gear meshing point were systematic definied through the analysis of spray lubrication process of aero spur gears, then the computational fluid dynamics(CFD) method of spray lubrication process was established. Three kinds of spray parameter including spray angle, spray point position and spray distance were calculated, jet states were obtained with different meshing instantaneous of gears. The varying rules of the oil/air ratio and oil/air total pressure at the entrance of contact point were compared in the meshing process under different spray parameters.Result show that, nozzle should offset a small angle to driving wheel when spray lubrication using engaging-in side in order to get better lubricating effect,and spray point position should offset engaging-in side, spray distance should take into account the structure, working condition, not general idea that the closer the better.
- spray angle /
- spray point position /
- spray distance /
- computational fluid dynamics /
- oil/air ratio /
- oil/air total pressure

HTML

参考文献(18)

[1]	林基恕,张振波.21世纪航空发动机动力传输系统的展望[J].航空动力学报,2001,16(2):108-114. LIN Jishu,ZHANG Zhenbo.Prospects of aero-engine powertransmission system in the 21st century[J].Journal of Aerospace Power,2001,16(2):108-114.(in Chinese)
[2]	Biboulet N,Colin F,Lubrecht A A.Friction in starved hydrodynamically lubricated line contacts[J].Tribology International,2013,58:1-6.
[3]	Querlioz E,Ville F,Lenon H,et al.Experimental investigations on the contact fatigue life under starved conditions[J].Tribology International,2007,40:1619-1626.
[4]	Akbarzadeh S,Khonsari M M.Performance of spur gears considering surface roughness and shear thinning lubricant[J].Journal of Tribology,2008,130(2):021503.1-021503.8.
[5]	Wijnant Y H,Venner C H.Contact dynamics in starved elastohydrodynamic lubrication[J].Tribology Series,1999,36:705-716.
[6]	申永胜.机械原理教程[M].2版.北京:清华大学出版社,2005.
[7]	Hhn B R,Michaelis K,Otto H P.Minimised gear lubrication by a minimum oil/air flow rate[J].Wear,2009,266(3/4):461-467.
[8]	Brando J,Meheux M,Ville F,et al.Comparative overview of five gear oils in mixed and boundary film lubrication[J].Tribology International,2012,47:50-61.
[9]	Li S,Kahraman A.A transient mixed elastohydrodynamic lubrication model for spur gear pairs[J].Journal of Tribology,2010,132(1):011501.1-011501.9.
[10]	Bobach L,Beilicke R,Bartel D,et al.Thermal elastohydrodynamic simulation of involute spur gears incorporating mixed friction[J].Tribology International,2012,48:191-206.
[11]	Dowson D.Elastohydrodynamic and micro-elastohydrodynamic lubrication[J].Wear,1995,190(2):125-138.
[12]	Dhar S,Vacca A.A fluid structure interaction—EHD model of the lubricating gaps in external gear machines:formulation and validation[J].Tribology International,2013,62:78-90.
[13]	王福军.计算流体动力学分析[M].北京:清华大学出版社,2004.
[14]	Subramaniam S.Lagrangian-Eulerian methods for multiphase flows[J].Progress in Energy and Combustion Science,2013,39(2/3):215-245.
[15]	Enwald H,Peirano E,Almstedt A E.Eulerian two-phase flow theory applied to fluidization[J].International Journal of Multiphase Flow,1996,22(suppl.):21-66.
[16]	HE Zhixia,ZHONG Wenjun,WANG Qian,et al.Effect of nozzle geometrical and dynamic factors on cavitating and turbulent flow in a diesel multi-hole injector nozzle[J].International Journal of Thermal Sciences,2013,70:132-143.
[17]	Murphy J,Schmidt D,Wang S P,et al.Multi-dimensional modeling of multiphase flow physics:high-speed nozzle and jet flow-a case study[J].Nuclear Engineering and Design,2001,204(1/2/3):177-190.
[18]	王延忠,牛文韬,唐文,等.航空直齿轮喷油润滑油气两相流分析[J].航空动力学报,2013,28(2):439-444. WANG Yanzhong,NIU Wentao,TANG Wen,et al.Research on oil/air multiphase flow of spray lubrication of areo spur gears[J].Journal of Areospace Power,2013,28(2):439-444.(in Chinese)
