接触特性对非连续性转子热致振动的影响

徐宁; 刘占生; 董延阳; 王震林; 王庆超

doi:10.13224/j.cnki.jasp.2015.07.013

接触特性对非连续性转子热致振动的影响

doi: 10.13224/j.cnki.jasp.2015.07.013

1. 哈尔滨工业大学能源科学与工程学院, 哈尔滨 150001;
2. 中国船舶重工集团公司第七〇三研究所, 哈尔滨 150078

基金项目:

国家高技术研究发展计划(2008AA05A302)

详细信息

作者简介:
徐宁(1983-),男,黑龙江哈尔滨人,工程师,博士生,从事燃气轮机结构设计、强度振动及转子动力学方面的研究.

中图分类号: V231.92;TB533
计量
- 文章访问数: 1214
- HTML浏览量: 150
- PDF量: 629
- 被引次数: 0
出版历程
- 收稿日期: 2015-02-15
- 刊出日期: 2015-07-28

Influence of contact characteristics on thermal induced vibration of non-continuous rotor

1. School of Energy Science and Engineering, Harbin Institute of Technology, Harbin 150001, China;
2. Harbin No.703 Research Institute, China Shipbuilding Industry Corporation, Harbin 150078, China

摘要

摘要: 针对燃气轮机转子的非连续性结构间存在的接触特性,根据微凸体理论引入接触刚度和接触热阻的等效模型,建立了某型燃气轮机非连续性转子的动力学模型,分析了接触参数对转子稳、瞬态动力学特性的影响,研究了螺栓松动引起的转子热变形及其对转子快速启动过程中振动特性的影响.结果表明:预紧力、接触面的表面粗糙度和螺栓个数对转子临界转速有一定的影响,螺栓松动导致转子在启动过程中瞬态热变形最大达到7μm,过1阶临界转速时引起的转子最大响应幅值增大约30μm.在非连续性转子系统的热致振动特性分析当中,不应忽视接触参数、接触刚度和接触热阻的影响.
- 燃气轮机 /
- 非连续性转子 /
- 接触刚度 /
- 接触热阻 /
- 热致振动 /
- 螺栓松动
Abstract: According to the contact characteristics of the non-continuous structure in gas turbine rotor and the asperity theory, the contact stiffness and contact thermal resistance equivalent model were introduced. Dynamic model for a non-continuous rotor of gas turbine was established. The influence of contact parameters on steady and transient state dynamic characteristic of rotor was analyzed.The thermal deformation of rotor caused by bolt looseness was studied, and the vibration characteristics of rotor based on fast start-up process were analyzed. Result shows that, the pre-tightening force, surface roughness of contact surface and bolt number have a certain influence on critical speeds of rotor, the maximum transient thermal deformation of rotor caused by bolt looseness in start-up process is up to 7μm, and the maximum response amplitude caused by rotor across the first critical speed is increased about 30μm. The influence of contact parameters, contact stiffness and contact thermal resistance of non-continuous rotor on thermally induced vibration characteristics analyze should not be ignored.
- gas turbine /
- non-continuous rotor /
- contact stiffness /
- contact thermal resistance /
- thermal induced vibration /
- bolt looseness
