碳纤维/酚醛树脂体系Z-pin加捻拉挤工艺及其性能

张向阳; 李勇; 褚奇奕; 李吻

doi:10.13224/j.cnki.jasp.2015.07.015

碳纤维/酚醛树脂体系Z-pin加捻拉挤工艺及其性能

doi: 10.13224/j.cnki.jasp.2015.07.015

南京航空航天大学材料科学与技术学院, 南京 210016

详细信息

作者简介:
张向阳(1987-),女,河北唐山人,博士生,主要从事复合材料三维增强技术研究.

中图分类号: V258;TB332
计量
- 文章访问数: 1170
- HTML浏览量: 117
- PDF量: 660
- 被引次数: 0
出版历程
- 收稿日期: 2014-01-20
- 刊出日期: 2015-07-28

Pultrusion and properties of the twisted carbon fiber/phenolic resin Z-pin

College of Material Science and Technology, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 为了解决碳纤维/酚醛树脂体系Z-pin拉挤制品中的孔隙缺陷,实现耐烧蚀复合材料三维增强体的制备,在分析孔隙的形成与酚醛树脂的固化过程基础上,利用纤维加捻提高酚醛树脂固化压力进而改善Z-pin中的孔隙缺陷.研究表明:一定范围内,随着纤维捻度的增加,孔隙缺陷的尺寸与数量明显减少,Z-pin中树脂质量分数及可植入深度逐渐降低,而Z-pin抗压性能先提高后降低;碳纤维捻度为80捻/m时,Z-pin制品质量较好,树脂质量分数约为32%,可满足后续超声植入,常温下最大植入深度可达10mm.
- 碳纤维 /
- 酚醛树脂 /
- Z-pin拉挤 /
- 加捻 /
- 力学性能
Abstract: The main goal is to solve the pore defect of the pultruded carbon fiber/phenolic resin Z-pin and obtain the three-dimensional reinforcement of ablation resistant composite. On basis of the analysis of the pore formation and phenolic resin curing process, the twisted yarn was utilized to elevate the resin's inner pressure to eliminate the pore defects in Z-pin. The results showed that, along with the increase of the twist number within the specific range, the size and amount of pores declined obviously, and also the phenolic resin mass fraction and maximum insertion depth decreased, while the compressive property arose firstly and declined afterwards. When the twist number was 80twist/m, Z-pin of good quality was obtained with approximately 32% phenolic resin mass fraction, which can be used for ultrasonic insertion, with the maximum insertion depth up to 10mm in room temperature.
- carbon fiber /
- phenolic resin /
- Z-pin pultrusion /
- twist /
- mechnaical performance

HTML

参考文献(17)

[1]	Mouritz A P.Review of Z-pinned composite laminates[J].Composites Part A:Applied Science and Manufacturing,2007,38(12):2383-2397.
[2]	Cartie D D R.Effect of Z-fibers TM on the delamination behavior of carbon fiber/epoxy laminates[D].Cranfield:Cranfield University,2000.
[3]	孙先念,郑长良.层合复合材料Z-pinning增强技术的力学进展[J].航空学报,2006,27(6):1194-1202. SUN Xiannian,ZHENG Changliang.Advances on modeling through-the-thickness reinforcement of laminated composite by Z-pinning[J].Acta Aeronautica et Astronautica Sinica,2006,27(6):1194-1202.(in Chinese)
[4]	Toral V J,Castanié B,Barrau J J,et al.Multi-level analysis of low-cost Z-pinned composite joints:Part 2 joint behavior[J].Composites Part A:Applied Science and Manufacturing,2011,42(12):2082-2092.
[5]	Byrd L W,Birman V.The estimate of the effect of Z-pins on the strain release rate,fracture and fatigue in a composite co-cured Z-pinned double cantilever beam[J].Composite Structures,2005,68(1):53-63.
[6]	Walker S P,Sullivan B J.Sharp refractory composite leading edges on hypersonic vehicles[R].AIAA 2003-6915,2003.
[7]	李仲平.防热复合材料发展与展望[J].复合材料学报,2011,28(2):1-9. LI Zhongping.Major advancement and development trends of TPS composites[J].Acta Material Composite Sinica,2011,28(2):1-9.(in Chinese)
[8]	赵梦熊.载人飞船返回舱的烧蚀防热[J].气动实验与测量控制,1996,10(3):1-9. ZHAO Mengxiong.Ablative thermal protection of capsule type re-entry vehicle[J].Aerodynamic Experiment and Measurement and Control,1996,10(3):1-9.(in Chinese)
[9]	袁海根,曾金芳,杨杰,等.防热抗烧蚀复合材料研究进展[J].化学推进剂与高分子材料,2006,4(1):21-25. YUAN Haigen,ZENG Jinmei,YANG Jie,et al.Research progress of high temperature themoprotective and ablation resistant composite materials[J].Chemical Propellants and Polymeric Materials,2006,4(1):21-25.(in Chinese)
[10]	李宁.Z-pin增强酚醛层合板制备工艺及性能研究[D].南京:南京航空航天大学,2012. LI Ning.Research on preparation process and mechanical properties of Z-pinned phenolic composite laminates[D].Nanjing:Nanjing University of Aeronautics and Astronautics,2012.(in Chinese)
[11]	Kardos J L,Dudukovi Dc' M P,Dave R.Void growth and resin transport during processing of thermosetting-matrix composites[M].Berlin:Springer,1986.
[12]	郭昕昕,刘永琪.拉挤用酚醛树脂固化过程的研究[J].纤维复合材料,1999,16(4):39-42. GUO Xinxin,LIU Yongqi.Research on the curing process of phenolic resin for pultrusion[J].Fiber Composites,1999,16(4):39-42.(in Chinese)
[13]	顾平,管辛.粘胶长丝加捻线的形态特征与数学模型[J].纺织学报,2005,26(2):33-36. GU Ping,GUAN Xin.Morphology features and mathematical model of viscose twisted filament threads[J].Journal of Textile Research,2005,26(2):33-36.(in Chinese)
[14]	Partridge I K,Cartie D D R,Bonnington T.Manufacture and performance of Z-pinned composites[M]//Shonaike G,Advani S.Advanced Polymeric Composites.Florida:CRC Press,2003.
[15]	王晓旭,陈利.复合材料Z-pin的压缩试验研究[J].航空材料学报,2011,31(4):90-95. WANG Xiaoxu,CHEN Li.Experimental studies on compressive properties of composite Z-pins[J].Journal of Aeronautical Materials,2011,31(4):90-95.(in Chinese)
[16]	Whitney J M.Geometrical effects of filament twist on the modulus and strength of graphite fiber-reinforced composites[J].Textile Research Journal,1966,36(9):765-770.
[17]	Rugg K L,Cox B N,Ward K E,et al.Damage mechanisms for angled through-thickness rod reinforcement in carbon-epoxy laminates[J].Composites Part A:Applied Science and Manufacturing,1998,29(12):1603-1613.
