波瓣混合器喷流降噪技术实验

邵万仁; 何敬玉; 吴飞; 李晓东

doi:10.13224/j.cnki.jasp.2015.07.016

波瓣混合器喷流降噪技术实验

doi: 10.13224/j.cnki.jasp.2015.07.016

1. 北京航空航天大学能源与动力工程学院, 北京 100191;
2. 中国航空工业集团公司沈阳发动机设计研究所, 沈阳 110015

详细信息

作者简介:
邵万仁(1967-),男,辽宁开原人,研究员,博士生,主要从事航空发动机排气装置设计与研究.

中图分类号: V231
计量
- 文章访问数: 1482
- HTML浏览量: 193
- PDF量: 663
- 被引次数: 0
出版历程
- 收稿日期: 2014-08-03
- 刊出日期: 2015-07-28

Experiment of jet noise reduction technology using lobed mixer

1. School of Energy and Power Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China;
2. Shenyang Engine Design and Research Institute, Aviation Industry Corporation of China, Shenyang 110015, China

摘要

摘要: 在消声室内的喷流噪声实验台上,对大涵道比涡扇发动机混合式排气系统缩比模型进行了冷喷流噪声实验,以环形混合器为基准,研究了采用波瓣混合器的喷管喷流远声场频谱特性和降噪效果.研究结果表明:与采用环形混合器的基准型喷管相比,波瓣混合器喷管在低频段有很好的降噪效果但高频段的声压级有所升高,波瓣混合器喷管下游方向(θ=150°)的总声压级明显降低而中游方向和上游方向的总声压级升高.随着波瓣混合器出口处内外涵气流速度差的增大,波瓣混合器喷管低频段的降噪效果越来越明显但高频段声压级的升高也会不同程度地增大,在波瓣混合器喷管下游方向(θ=150°)的总声压级降低更加明显的同时中游方向和上游方向的总声压级也有所升高.
- 大涵道比涡扇发动机 /
- 混合式排气系统 /
- 波瓣混合器 /
- 缩比模型实验 /
- 喷流降噪
Abstract: On the basis of the baseline nozzle with annular mixer, the far field noise spectra performance and the noise reduction of the nozzle with lobed mixer were investigated under cold jet condition through scaled model experiments of high bybass ratio turbofan engine mixing exhaust system. The experiments were carried out on the jet noise experiment rig in the anechoic chamber. The experimental results show that, compared with the baseline nozzle with annular mixer, the nozzle with lobed mixer has better jet noise reduction at low frequencies, but the sound pressure level increases at high frequencies, while overall sound pressure level reduces at downstream(θ=150°)but increases at middlestream and upstream. With increased velocity differences between core exit flow and fan exit flow of lobed mixer, the nozzle with lobed mixer has better noise reduction at low frequencies, but the sound pressure level increases at high frequencies, while overall sound pressure level reduces at downstream(θ=150°)but increases at middlestream and upstream.
- high bypass ratio turbofan engine /
- mixing exhaust system /
- lobed mixer /
- scale model experiment /
- jet noise reduction

HTML

参考文献(23)

[1]	US Environment Protection Agency.EPA 550/9-76-013,Noise standards for aircraft type certification:modification to FAR part 36[S].Washington DC:Enviroment Protection Agency,1994.
[2]	《高效节能发动机文集》编委会.高效节能发动机文集:第6分册排气混合器和短舱[M].北京:航空工业出版社,1991.
[3]	McCormick D C.Vertical and turbulent structure of a lobed mixer free shear layer[J].AIAA Journal,1994,32(9):1852-1859.
[4]	Simon C M,Yu J H Y,Jeffrey K L T.Velocity measurements downstream of a lobed-forced mixer with different trailing-edge configurations[J].Journal of Propulsion and Power,1995,11(1):87-97.
[5]	Simon C M,Yu T H Y,Liu C Y.The mixing characteristics of forced mixers with scalloped lobes[R].AIAA 96-0117,1996.
[6]	陈光.航空发动机结构设计分析[M].北京:北京航空航天大学出版社,2006.
[7]	Babbitt R R,Cohn J A.Advanced high bypass mixed-flow exhaust system design study[R].AIAA 91-2242,1991.
[8]	Abolfadl M A,Sehra A K.Experimental investigation of exhaust system mixers for a high bypass turbofan engine[R].AIAA 93-0022,1993.
[9]	Vinod G M,William N D.Lobed mixer design for noise suppression,acoustic and aerodynamic test data analysis[R].NASA-CR-210823,2002.
[10]	Tester B J,Fishe M J.A contribution to the understanding and prediction of jet noise generation in forced mixers[R].AIAA-2004-2897,2004.
[11]	刘友宏,樊超,谢翌,等.波瓣数对波瓣强迫混合排气系统性能影响[J].航空动力学报,2010,25(8):1683-1689. LIU Youhong,FAN Chao,XIE Yi,et al.Effect of lobe numbers on the performance of a lobed mixer in the forced mixing exhaust system[J].Journal of Aerospace Power,2010,25(8):1683-1689.(in Chinese)
[12]	李腾,刘友宏,谢翌,等.波瓣高宽比对波瓣强迫混合排气系统性能影响[J].航空动力学报,2013,28(8):1736-1743. LI Teng,LIU Youhong,XIE Yi,et al.Effect of ration of height to width of lobe on performance of forced mixing exhaust system[J].Journal of Aerospace Power,2013,28(8):1736-1743.(in Chinese)
[13]	丁玉林,刘友宏,谢翌,等.尾缘凹扇及综合修形对波瓣混合器性能影响[J].航空动力学报,2012,27(10):2236-2242. DING Yulin,LIU Youhong,XIE Yi,et al.Effect of serrated cut at trailing edge on performance of lobed mixer in forced mixing exhaust system[J].Journal of Aerospace Power,2012,27(10):2236-2242.(in Chinese)
[14]	刘友宏,张少鹏,杨旭,等.波瓣尾缘切角对涡扇发动机混合排气系统气动热力性能影响[J].推进技术,2013,34(6):734-740. LIU Youhong,ZHANG Shaopeng,YANG Xu,et al.Effects of cut angles at trailing edge of lobe on aerothermodynamic performance of forced mixing exhaust system in turbofan engine[J].Journal of Propulsion Technology,2013,34(6):734-740.(in Chinese)
[15]	刘友宏,杜力伟,谢翌,等.波瓣凹扇修形对波瓣强迫混合排气系统性能影响[J].科学技术与工程,2013,13(18):5226-5233. LIU Youhong,DU Liwei,XIE Yi,et al.Effect of elliptical cut at trailing edge of lobed mixer on aerodynamic and thermal performance of a turbofan forced mixing exhaust system[J].Science Technology and Engineering,2013,13(18):5226-5233.(in Chinese)
[16]	张正伟,张靖周,邵万仁,等.外涵偏轴分开排气喷管的流场和声场数值计算[J].航空动力学报,2012,27(5):1139-1145. ZHANG Zhengwei,ZHANG Jingzhou,SHAO Wanren,et al.Numerical caculation of flow and acoustics fields for separated exhaust nozzle with bypass offset[J].Journal of Aerospace Power,2012,27(5):1139-1145.(in Chinese)
[17]	SHAO Wanren,XU Xihai,HE Jingyu,et al.Experimental and numerical study of chevron nozzle for jet noise reduction[R].Asian Joint Conference on Propulsion and Power Report AJCPP2012-140,2012.
[18]	单勇,张靖周,邵万仁,等.冠状喷口抑制涡扇发动机喷流噪声试验和数值研究[J].航空学报,2013,34(5):1046-1055. SHAN Yong,ZHANG Jingzhou,SHAO Wanren,et al.Experimental and numerical research on jet noise suppression with chevron nozzle for turbofan engines[J].Acta Aeronautica et Astronautica Sinica,2013,34(5):1046-1055.(in Chinese)
[19]	乔渭阳.航空发动机气动声学[M].北京:北京航空航天大学出版社,2010.
[20]	Tam C K.Jet noise:since 1952[J].Journal of Fluid Dynamics,1998,10(4):393-405.
[21]	Crow S C,Champagne F H.Orderly structure in jet turbulence[J].Journal of Fluid Mechanics,1971,48(3):547-591.
[22]	Brown G L,Roshko A.On density effects and large structure in turbulent mixing layers[J].Journal of Fluid Mechanics,1974,64(4):775-816.
[23]	Karavosov R K,Kouznetsov V M,Vlasov Y V.Aeroacoustic characteristics of the jet issuing from bypass nozzle with multi-lobed mixer[R].AIAA 98-2258,1998.
