飞翼无人机3种保形进气口进气道气动与隐身综合特性对比

张乐; 周洲; 许晓平; 王红波

doi:10.13224/j.cnki.jasp.2015.07.017

飞翼无人机3种保形进气口进气道气动与隐身综合特性对比

doi: 10.13224/j.cnki.jasp.2015.07.017

西北工业大学无人机特种技术重点实验室, 西安 710072

基金项目:

国家自然科学基金(11302178)

详细信息

作者简介:
张乐(1988-),男,江西抚州人,博士生,研究领域为飞行器总体设计、气动隐身一体化研究.

通讯作者:
周洲(1966-),女,湖北长沙人,教授、博士生导师,博士,研究领域为飞行器总体设计、飞行器力学与飞行控制. E-mail:zhouzhou@nwpu.edu.cn

中图分类号: V211.3
计量
- 文章访问数: 1489
- HTML浏览量: 108
- PDF量: 758
- 被引次数: 0
出版历程
- 收稿日期: 2014-04-16
- 刊出日期: 2015-07-28

Comparison on aerodynamic and stealthy performanceof flying wing unmanned aerial vehicle withthree conformal intake inlets

State Key Laboratory of UAV Special Technology, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 基于飞翼布局无人机隐身与结构装载布置要求,保形设计了3种进气口形状的背负式S弯进气道,按照进口投影截面形状上、下底之比顺序排列,分别为三角形、梯形和矩形.利用数值模拟方法对无人机内外流场耦合流动进行计算分析,且基于射线弹跳(SBR)法对进气道电磁散射特性进行仿真研究,获得了飞翼无人机3种进气道的气动与隐身综合特性.研究结果表明:①矩形进气道模型升阻和纵向力矩特性表现均最好;②3种进气道模型按顺序排列总压恢复系数逐渐增大,畸变指数逐渐减小,进气道沿程气流也逐渐顺畅,矩形进气道模型进气道内流特性最优;③0°迎角下3种进气道模型雷达散射截面(RCS)均值基本呈现先增大后减小的特征,进气道终端开放时矩形进气道模型隐身性能最好,而终端短路时三角形进气道模型隐身效果更优异.
- 飞翼无人机 /
- 保形进气口 /
- 进气道 /
- 气动 /
- 隐身 /
- 总压恢复系数 /
- 畸变指数 /
- 雷达散射截面
Abstract: Based on stealth and structural loading requirements of flying wing unmanned aerial vehicle (UVA), three dorsal S-shaped inlets with three conformal intakes were designed. According to the ratio of the upper and bottom of the sectional projection shape of the intake, three inlets, i.e.: triangular, trapezoidal and rectangular inlets, were named. The coupled numerical simulation was carried out on the inflow/outflow integrated for flying wing UAV, and the simulation method based on shooting and bouncing ray (SBR) was also performed to study the electromagnetic scattering of inlet. Then the aerodynamic and stealthy performance of flying wing UAV with three conformal inlets was obtained. Results indicate: (1) The lift/drag and the longitudinal moment characteristic of the model with rectangular inlet are the best.(2) As the three inlet models are arranged in previous order, the total pressure recovery coefficient increases gradually, and the distortion coefficient decreases; moreover, the airflow along the inlet becomes smooth gradually, and then, of course, the internal flow characteristic of the model with rectangular inlet shows the best.(3) At the attack angle 0° the mean value of the three inlet models radar cross-section (RCS) increases first and then decreases basically.The stealthy performance of the model with rectangular inlet is the best with the terminator open, but the model with triangular inlet shows better when the terminator is short-circuited.
- flying wing unmanned aerial vehicle (UAV) /
- conformal intake /
- inlet /
- aerodynamic /
- stealth /
- total pressure recovery coefficient /
- distortion coefficient /
- radar cross-section (RCS)

HTML

参考文献(19)

[1]	张航,谭慧俊,李湘萍.类X-47狭缝式进气道的流动特征与工作性能[J].航空学报,2009,30(12):2243-2249. ZHANG Hang,TAN Huijun,LI Xiangping.Flow structure and performance characteristics of X-47-like slot-shaped inlet[J].Acta Aeronautica et Astronautica Ainica,2009,30(12):2243-2249.(in Chinese)
[2]	SHI Lei,Guo R W.Serpentine inlet design and analysis[R].AIAA-2012-0839,2012.
[3]	钟易成,余少志,陈晓.带尖脊进气口的大S弯扩压器流动特性研究[J].航空动力学报,1996,11(4):385-388. ZHONG Yicheng,YU Shaozhi,HEN Xiao.Experimental investigation on performance of a large S-shaped diffuser with “caret” inlet[J].Journal of Aerospace Power,1996,11(4):385-388.(in Chinese)
[4]	Papadopoulos F,Valakos I M,Nikolos I K.Design of an S-duct intake for UAV applications[J].Aircraft Engineering and Aerospace Technology,2012,84(6):439-456.
[5]	Collie W V,Burgun R,Heinzen S N,et al.Advanced propulsion system design and integration for a turbojet powered unmanned aerial vehicle[R].AIAA-2003-415,2003.
[6]	郭文彦,朱颜填,李海涛.飞机进气道的高频散射特性及 RCS计算[J].哈尔滨工业大学学报,1999,31(1):123-129. GUO Wenyan,ZHU Yanzhen,LI Haitao.HF electromagnetic scattering properties and RCS calculation of the airplane’s inlet[J].Journal of Harbin Institute of Technology,1999,31(1):123-129.(in Chinese)
[7]	余安远,郭荣伟,孙姝,等.三种不同的进气道与弹体组合体雷达散射截面特性[J].南京航空航天大学学报,2002,34(6):517-521. YU Anyuan,GUO Rongwei,SUN Shu,et al.Radar cross section characteristics of three different inlet-body missile models[J].Journal of Nanjing University of Aeronautics and Astronautics,2002,34(6):517-521.(in Chinese)
[8]	万顺生,罗屹洁,郭荣伟.采用SBR法研究飞机进气道的雷达散射截面[J].航空动力学报,2006,21(6):1033-1036. WAN Shunsheng,LUO Yijie,GUO Rongwei.Research on RCS of airplane duct based on SBR method[J].Journal of Aerospace Power,2006,21(6):1033-1036.(in Chinese)
[9]	石磊,郭荣伟.蛇形进气道的电磁散射特性[J].航空学报,2007,28(6):1296-1301. SHI Lei,GUO Rongwei.Electromagnetic scattering characteristics of serpentine inlet[J].Acta Aeronautica et Astronautica Sinica,2007,28(6):1296-1301.(in Chinese)
[10]	Lee D S,Gonzalez L F,Srinivas K,et al.Aerodynamic/RCS shape optimization of unmanned aerial vehicles using hierarchical asynchronous parallel evolutionary algorithms[R].AIAA-2006-3331,2006.
[11]	Johansson M.Propulsion integration in an UAV[R].AIAA-2006-2834,2006.
[12]	Lee C C.Subsonic diffuser design and performance for advanced fighter aircraft[R].AIAA 85-3073,1985.
[13]	Lee B J,Kim C.Automated design methodology of turbulent internal flow using discrete adjoint formulation[J].Aerospace Science and Technology,2007,11(2):163-173.
[14]	Harloff G J,Reichert B A,Wellborn S R.Navier-Stokes analysis and experimental data comparison of compressible flow in a diffusing S-duct[R].AIAA-92-2699-CP,1992.
[15]	Ahrabi B R,Sreenivas K,Webster R S.Computational investigation of compressible flow in a diffusing S-duct[R].AIAA-2013-3601,2013.
[16]	Ling H,Zhou R C,Lee S W.Shooting and bouncing rays:calculating the RCS of an arbitrary shaped cavity[J].1989,37(2):194-205.
[17]	Yun Z,Iskander M F,Zhang Z.Development of a new shooting-and-bouncing ray (SBR) tracing method that avoids ray double counting[R].Boston,MA:Antennas and Propagation Society International Symposium,2001.
[18]	Savides T,Dwolatzky B.Radar simulation using the shooting and bouncing ray technique[R].[S.l.]:Canadian Conferce on Electrical and Computer Engineering,IEEE,2003.
[19]	李天,郭荣伟,张考,等.飞行器外形隐身设计初步指南[R].北京:航空航天工业部科学技术研究院,1991.
