流构耦合作用下柱状薄膜充气过程的流场

王从磊; 孙建红; 许常悦; 侯斌

doi:10.13224/j.cnki.jasp.2015.07.018

流构耦合作用下柱状薄膜充气过程的流场

doi: 10.13224/j.cnki.jasp.2015.07.018

南京航空航天大学航空宇航学院, 南京 210016

基金项目:

航空科学基金(20142952026)

江苏高校优势学科建设工程资助项目

江苏省自然科学基金(BK2011723)

国家自然科学基金(11202100)

详细信息

作者简介:
王从磊(1978-),男,江苏南京人,博士生,主要从事可压缩流动的直接数值模拟与大变形结构的流构耦合作用研究.

中图分类号: V244
计量
- 文章访问数: 962
- HTML浏览量: 63
- PDF量: 595
- 被引次数: 0
出版历程
- 收稿日期: 2014-11-05
- 刊出日期: 2015-07-28

Flow field of cylindrical membrane inflation under the fluid-structure interaction

College of Aerospace Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 采用Euler-Lagrangian方法,重点研究了柱状薄膜充气过程的流场特性.研究表明:在入口气流速度为50~90m/s,入口气流压力为1.0~1.4MPa条件下,柱状薄膜在充气初始阶段,两端会出现上下摆动的鼓包现象.通过分析柱状薄膜内部流场中的气流组织、涡量输运以及旋涡与激波相互作用,发现气流在充气口附近形成弧形激波,使流动发生偏转.偏转气流在充气口两侧形成旋涡,和激波相互作用形成局部超声速区.另一方面,对柱状薄膜应力分布的研究发现,充入气流造成柱状薄膜顶部与两端的局部应力集中,是影响稳定性与安全性的重要因素.不同入口气流压力与速度条件下柱状薄膜应力分布与摆动情况表明,入口气流压力的变化对安全性的影响相对重要,而入口气流速度对稳定性的影响更加显著.
- 柱状薄膜 /
- 流构耦合 /
- 可压缩流动 /
- 充气 /
- 旋涡 /
- 激波
Abstract: Numerical research on the flow field characteristics of the cylindrical membrane inflation was performed by the Euler-Lagrangian method. The results show that bumps are formed at two ends of the cylindrical membrane, swinging vertically during the inflation within inlet velocity range (50-90m/s) and inlet pressure range (1.0-1.4MPa). With the analysis on the flow structure, vorticity transportation and the mechanism of vortex/shock interaction in the flow field inside the cylindrical membrane, it is found that there is a cured shock adjacent to the inlet tube, making flow deflection. Vortexes formed by the deflected flow interact with shock, resulting in local supersonic zones. Based on the discussion about cylindrical membrane stress distribution, the local stress concentrations at the top and two ends of the cylindrical membrane are considered as important factors influencing the safety and stability. Comparing the results of different inlet pressures and velocities, it is found that the influence on safety caused by the inlet velocity is less than the inlet pressure, and the influence on stability caused by the inlet velocity is greater than the inlet pressure.
- cylindrical membrane /
- fluid-structure interaction /
- compressible flow /
- inflation /
- vortex /
- shock

HTML

参考文献(21)

[1]	Anwar H O.Inflatable dams[J].Journal of the Hydraulics Division,1967,93:99-119.
[2]	Hsieh J C,Plaut R H,Yucel O.Vibrations of an inextensible cylindrical membrane inflated with liquid[J].Journal of Fluids and Structures,1989,3(2):151-163.
[3]	Habler M,Schweizerhof K.On the static interaction of fluid and gas loaded multi-chamber systems in large deformation finite element analysis[J].Computer Methods in Applied Mechanics and Engineering,2008,197(19):1725-1749.
[4]	Ghavanloo E,Daneshmand F.Analytical analysis of the static interaction of fluid and cylindrical membrane structures[J].European Journal of Mechanics:A Solids,2010,29(4):600-610.
[5]	王晓冬,张金换,黄世霖.气囊模拟计算技术综述[J].汽车技术,2000(9):4-7. WANG Xiaodong,ZHANG Jinhuan,HUANG Shilin.Summary of simulation calculation techniques for airbag[J].Automobile Technology,2000(9):4-7.(in Chinese)
[6]	代小芳,宗智,王喜军,等.折叠气囊展开过程CV和ALE数值模拟方法对比研究[J].汽车工程,2008,30(8):676-680. DAI Xiaofang,ZONG Zhi,WANG Xijun,et al.A comparative study on the CV and ALE methods for simulation folded airbag deployment[J].Automotive Engineering,2008,30(8):676-680.(in Chinese)
[7]	Morano E,Arienti M,Hung P,et al.A level set approach to Eulerian-Lagrangian coupling[J].Journal of Computational Physics,2003,185(1):213-251.
[8]	Grob A,Fasel H F.High-order WENO schemes based on the Roe approximate Riemann solver[R].AIAA-2002-2735,2002.
[9]	Zienkiewicz O C,Taylor R L.The finite element method:Volume 2 solid mechanics[M].Oxford:Butterworth-Heinemann,2000.
[10]	Osher S,Fedkiw R P.Level set methods:an overview and some recent results[J].Journal of Computational Physics,2001,169(2):463-502.
[11]	Fedkiw R P,Aslam T,Merriman B,et al.A non-oscillatory Eulerian approach to interfaces in multimaterial flows:the ghost fluid method[J].Journal of Computational Physics,1999,152(2):457-472.
[12]	刘儒勋,王志峰.数值模拟方法和运动界面追踪[M].合肥:中国科学技术大学出版社,2001.
[13]	Grétarsson J T,Fedkiw R.Fully conservative leak-proof treatment of thin solid structures immersed in compressible fluids[J].Journal of Computational Physics,2013,245:160-204.
[14]	Cirak F,Radovitzky R.A Lagrangian-Eulerian shell-fluid coupling algorithm based on level sets[J].Computers and Structures,2005,83(6):491-498.
[15]	WANG Conglei,SUN Jianhong,XU Changyue.Numerical investigation of bumps and oscillation in the cylindrical membrane inflation[J].Applied Mechanics and Materials,2014,444/445:1335-1339.
[16]	Hoffmann J,Freisinger M,Schmehl R.CFD analysis of the flow from an airbag inflator module[R].Bordeaux,France:International Pyrotechnic Automotive Safety Symposium,2007.
[17]	Van der Veen W A,Sadeghi R S.Simulation of a compartment airbag deployment using an explicit,coupled Euler/Lagrang e method with adaptive Euler domains[R].Florida,US:16th Annual Symposium Science and Engineering,2003.
[18]	郝莉,马天宝,王成.爆炸冲击波绕流的三维数值模拟研究[J].力学学报,2010,42(6):1042-1049. HAO Li,MA Tianbao,WANG Cheng.Three dimensional numerical simulation study on the flow of the explosion shock wave around the wall[J].Chinese Journal of Theoretical and Applied Mechanics,2010,42(6):1042-1049.(in Chinese)
[19]	许常悦.圆柱可压缩绕流机器流动控制的大涡模拟研究[D].合肥:中国科技大学,2009. XU Changyue.Large eddy simulation of the compressible flow past a circular cylinder and its flow control[D].Hefei:University of Science and Technology of China,2009.(in Chinese)
[20]	Sun J H,Zhao L Q,Hsu C T.Experimental and numerical study on the flapping motion of submerged turbulent plane jet[J].Science China Technological Sciences,2013,56(10):2391-2397.
[21]	孙建红,周涛,李名琦,等.直升机应急气囊充气及冲击着水过程数值分析[J].南京航空航天大学学报,2012,44(5):713-717. SUN Jianhong,ZHOU Tao,LI Mingqi,et al.Numerical analysis of emergent airbag deployment and ditching crashworthiness process[J].Journal of Nanjing University of Aeronautics and Astronautics,2012,44(5):713-717.(in Chinese)
