一种宽马赫数变几何超声速进气道气动性能研究

赵昊; 谢旅荣; 郭荣伟; 王建勇; 张骏

doi:10.13224/j.cnki.jasp.2015.07.020

一种宽马赫数变几何超声速进气道气动性能研究

doi: 10.13224/j.cnki.jasp.2015.07.020

赵昊^1,2,3,
谢旅荣^1,3,
郭荣伟¹,
王建勇^1,3,
张骏²

1. 南京航空航天大学能源与动力学院江苏省航空动力系统重点实验室, 南京 210016;
2. 中国航空工业集团公司中国航空动力机械研究所, 湖南株洲 412002;
3. 先进航空发动机协同创新中心, 北京 100191

基金项目:

国家自然科学基金(11302101)

详细信息

作者简介:
赵昊(1990-),男,云南金平人,硕士生,主要从事超声速气动技术研究.

中图分类号: V231.3
计量
- 文章访问数: 1666
- HTML浏览量: 141
- PDF量: 645
- 被引次数: 0
出版历程
- 收稿日期: 2014-01-16
- 刊出日期: 2015-07-28

Study of variable geometry supersonic inlet aerodynamic performance in a wide Mach number range

1. Jiangsu Province Key Laboratory of Aerospace Power System, College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China;
2. China Aviation Powerplant Research Institute, Aviation Industry Corporation of China, Zhuzhou Hunan 412002, China;
3. Collaborative Innovation Center for Advanced Aero-Engine, Beijing 100191, China

摘要

摘要: 为了改善二元宽马赫数超声速进气道非设计点下的气动性能,设计了一种来流马赫数为2.0~4.5的变几何超声速进气道,对其气动性能开展了数值仿真研究,得出了性能较优的变几何方案,并与相应的定几何进气道进行了对比.研究结果表明:采用变几何方法可提高进气道在转级点的气动性能;随着来流马赫数的增大而增加进气道的楔角及内收缩比,可降低进气道的喉道马赫数;采用该变几何方法可有效提高进气道宽工作范围的气动性能,在某些状态下流量系数和总压恢复系数比定几何进气道分别高出19.4%和55.8%.
- 超声速进气道 /
- 变几何进气道 /
- 楔角 /
- 宽马赫数 /
- 气动性能
Abstract: In order to improve the off-design aerodynamic performance of supersonic inlet, a two-dimensional variable geometry inlet with the free stream Mach number from 2.0-4.5 was designed. Numerical simulation was applied to investigate the inlet aerodynamic performance, and a superior scheme of variable geometry was acquired. The aerodynamic performance was compared between variable geometry inlets and fixed ones. The results indicate that the variable geometry technique could improve the inlet aerodynamic performance at the starting Mach number; Mach number at the throat of variable geometry inlet decreases with the increase of the inlet ramp angle and contraction ratio when the free stream Mach number ascends. The variable geometry inlet has better aerodynamic performance during a wide range of Mach number, its mass flow rate and total pressure recovery coefficient are 19.4% and 55.8% respectively higher than the fixed ones in some states.
- supersonic inlet /
- variable geometry inlet /
- ramp angle /
- wide Mach number /
- aerodynamic performance

HTML

参考文献(17)

[1]	Seddon J,GoldSmith E L.Intake aerodynamics[M].2nd ed.Oxford:Blackwell Science Ltd,1999.
[2]	王卫星.基于双模态燃烧的轴对称高超进气道方案与流动机理[D].南京:南京航空航天大学,2012. WANG Weixing.Scheme and flow mechanism of axisymmetric hypersonic inlet based on dualmode combustion[D].Nanjing:Nanjing University of Aeronautics and Astronautics,2012.(in Chinese)
[3]	Van Wie D M,Kwok F T,Walsh R F.Starting charateristics of supersonic inlets[R].AIAA 96-2914,1996.
[4]	Barber T J,Hiett D,Fastenberg S.CFD modeling of the hypersonic inlet starting problem[R].AIAA-2006-123,2006.
[5]	麻肖妃,谢旅荣,郭荣伟.双下侧布局带泄流腔二元进气道试验研究[J].航空动力学报,2010,25(8):1818-1824. MA Xiaofei,XIE Lürong,GUO Rongwei.Investigation of two-dimensional supersonic twin inlet with slot-coupled cavity in 90° configuration at venter[J].Journal of Aerospace Power,2010,25(8):1818-1824.(in Chinese)
[6]	袁化成,梁德旺.抽吸对高超声速进气道起动能力的影响[J].推进技术,2006,27(6):525-528. YUAN Huacheng,LIANG Dewang.Effect of suction on starting of hypersonic inlet[J].Journal of Propulsion Technology,2006,27(6):525-528.(in Chinese)
[7]	刘媛,金志光,张堃元,等.高超进气道自适应泄压槽的设计参数分析[J].航空动力学报,2013,28(6):1314-1321. LIU Yuan,JIN Zhiguang,ZHANG Kunyuan,et al.Parameters analysis of adaptive pressure relief slot in hypersonic inlet[J].Journal of Aerospace Power,2013,28(6):1314-1321.(in Chinese)
[8]	Bouchez M,Falempin F.Air breathing space launcher interest of a fully variable geometry propulsion system status in 1999[R].AIAA 99-2376,1999.
[9]	王亚岗,袁化成,郭荣伟.一种外并联型涡轮基组合循环发动机进气系统方案[J].航空动力学报,2013,28(8):1851-1857. WANG Yagang,YUAN Huacheng,GUO Rongwei.Over/under type inlet scheme for turbine-based combined cycle engine[J].Journal of Aerospace Power,2013,28(8):1851-1857.(in Chinese)
[10]	Falempi F.The french promethee program main goals and status in 1999[R].AIAA 99-4814,1999.
[11]	Hideyuki T,Hisao F,Kazuo S,et al.Design study on hypersonic engine components fortbcc space planes[R].AIAA-2003-7006,2003.
[12]	Ryan P S.Off-design performance characterization of a variable geometry scramjet[R].AIAA-2005-3711,2005.
[13]	滕健,袁化成.二元高超声速变几何进气道气动特性研究[J].航空动力学报,2013,28(4):775-782. TENG Jian,YUAN Huacheng.Research on aerodynamic characteristics of 2-D hypersonic inlet[J].Journal of Aerospace Power,2013,28(4):775-782.(in Chinese)
[14]	金志光,张堃元.宽马赫数范围高超声速进气道转动唇口变几何方案研究[J].航空动力学报,2010,25(7):1553-1560. JIN Zhiguang,ZHANG Kunyuan.Investigation of a variable geometry scramjet inlet with a rotating cowl operating in a large Mach number range[J].Journal of Aerospace Power,2010,25(7):1553-1560.(in Chinese)
[15]	苗海丰,谢旅荣,郭荣伟.一级锥可调变几何轴对称进气道初步研究[J].航空动力学报,2013,28(8):1843-1850. MIAO Haifeng,XIE Lürong,GUO Rongwei.Preliminary study on variable-geometry axisymmetric inlet with first cone pivoting[J].Journal of Aerospace Power,2013,28(8):1843-1850.(in Chinese)
[16]	滕健,袁化成.一种轴对称变几何进气道设计方法[J].航空动力学报,2013,28(1):96-103. TENG Jian,YUAN Huacheng.Design methodology of axisymmetric variable geometry inlet[J].Journal of Aerospace Power,2013,28(1):96-103.(in Chinese)
[17]	谢旅荣,郭荣伟.双下侧定几何二元混压式进气道的流场特征和气动性能分析[J].空气动力学报,2011,29(3):257-263. XIE Lürong,GUO Rongwei.Flow pattern and performance of fix-geometry two-dimensional mixed-compression supersonic inlets with 90° configuration at venter of the missile[J].Acta Aerodynamic Sinica,2011,29(3):257-263.(in Chinese)
